StarTech.com SAT2510U2F System manual

2.5in USB FireWire SATA External Hard Drive Enclosure

StarTech ID: SAT2510U2F

The SAT2510U2F External Hard Drive Enclosure supports both USB 2.0 and FireWire 400 (IEEE1394a) host

connections, providing the compatibility needed to create a convenient and versatile external SATA storage

solution for desktop computers as well as MacBooks® and Windows® based laptops. Large capacity drives

(tested with up to 1TB) can be used to greatly enhance your computer's storage/backup capabilities.

The USB/FireWire enclosure features a slim, lightweight aluminum design and includes a 6-pin FireWire cable

simplifying the option to connect through IEEE 1394a, as well as a USB to Power adapter and USB 2.0 Y-cable

which can be used to ensure sufficient power delivery for higher capacity/higher power consumption hard drives

(HDD) or solid state drives (SSD).

Applications

Create a fast, portable external storage solution for desktops, laptops or netbooks

Add-on extra storage to almost any USB enabled computer system

Backup important data to an external storage device

Share large files between computers quickly and securely without a network

Retrieve data from old SATA drive, or turn the unused drive into additional external storage space

intrl.startech.com

Features

IEEE 1394a compliant (FireWire 400) host interface, with supported transfer rates up to 400Mbps

High Speed USB 2.0 host interface, with supported transfer rates up to 480 Mbps

Powered directly from the USB or FireWire port

Light-weight and durable aluminum chassis

Power/Activity LED indicator

Compatible with SATA revision 1/2/3 (1.5/3.0/6.0 Gbps) drives

Supports 2.5" form factor SATA hard drives (HDD) or solid state drives (SSD)

Plug-and-Play and Hot-Swap compatible

intrl.startech.com

Technical Specifications

Warranty 2 Years

Interface USB 2.0 & Firewire

Number of Drives 1

Drive Size 2.5in

Drive Type SATA

Drive Installation Fixed

Fan(s) No

Chipset ID Initio INIC-1615 FW802C

Drive Connectors 1 - SATA Data & Power Combo (7+15 pin) Receptacle

Host Connectors 1 - Firewire 400 (6 pin; IEEE 1394a) Female

Host Connectors 1 - USB Mini-B (5 pin) Female

Type and Rate FireWire 400 IEEE-1394a - 400 Mbit/s

Type and Rate USB 2.0 - 480 Mbit/s

RAID No

Max Drive Capacity Currently tested with up to 1TB 5400 RPM hard drives

OS Compatibility Windows XP (32/64-bit)/ Server 2003 (32/64-bit)/ Server 2008 R2/ Vista (32/64-bit)/ 7

(32/64-bit)/ 8 (32/64-bit)

Mac OS 10.4/ 10.5/ 10.6/ 10.7/ 10.8

Linux

Color Silver

Enclosure Type Aluminum

Max Drive Height 0.4 in [9.5 mm]

Product Length 5.4 in [137 mm]

Product Width 3.1 in [80 mm]

Product Height 0.7 in [17 mm]

Product Weight 4.1 oz [115 g]

LED Indicators 1 - Green - Solid: Power, Blinking: Activity

Power Adapter

Included

Input Voltage 110 ~ 240 AC

Output Voltage 5 DC

Output Current 0.5A

Center Tip Polarity Positive

Plug Type H

Operating 0°C to 40°C (32°F to 104°F)

intrl.startech.com

Temperature

Storage Temperature -20°C to 60°C (4°F to 140°F)

Humidity 0~90% RH

Shipping (Package)

Weight

12.4 oz [350 g]

Included in Package 1 - 2.5" SATA Hard Drive Enclosure

Included in Package 1 - 6-pin Firewire Cable

Included in Package 1 - USB to Power (Barrel Connector) cable

Included in Package 1 - USB Y Cable

Included in Package 2 - Mounting Screw

Included in Package 1 - Instruction Manual

Certifications, Reports and Compatibility

intrl.startech.com
