StarTech.com ICUSB232FTN System manual

1 Port USB to Null Modem RS232 DB9 Serial DCE Adapter Cable with FTDI

StarTech ID: ICUSB232FTN

The ICUSB232FTN FTDI USB to Null Modem Serial Adapter Cable (1-Port) converts an available USB 1.1 or

2.0 port into an RS232 Null Modem serial DB9 port, solving DCE/DTE conflicts directly, without requiring

additional cross-wired serial cables or adapters.

This compact adapter features COM retention, allowing the same COM port value to automatically be re-

assigned to the port if the cable is disconnected and re-connected to the host computer, or if the system is

rebooted. The integrated FTDI chipset supports additional customization, advanced features, and compatibility

not necessarily offered by other solutions.

The USB to Null Modem adapter is compatible with a broad list of operating systems including Windows®,

Windows CE, Mac OS and Linux, making it easier to integrate into mixed environments.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Applications

Perfect for IT Administrators looking to add legacy functionality to newer notebooks, PCs and servers that

lack an integrated RS232 port

Connect, monitor and control industrial/automotive sensors and equipment

Connect bar code scanners, receipt printers and other point of sale devices

Connect and program LED and Digital signage boards with serial communication ports

Connect a satellite receiver, serial modem, or PDU

Features

USB to Null Modem (Cross-Wired) RS232 Serial Adapter

Integrated FTDI USB UART Chip

Baud Rate up to 921.6Kbps

COM Port assignments maintained across reboot

USB-powered - no external power adapter required

Compatible with USB 1.1 or 2.0 Ports

Compatible with Windows®, Mac OS and Linux

Single cable design for portability

Technical Specifications

Warranty 2 Years

Ports 1

Interface USB 1.1

Interface USB 2.0

Bus Type USB 2.0

Chipset ID FTDI - FT232RL

Connector Type(s) 1 - DB-9 (9 pin; D-Sub) Female

Connector Type(s) 1 - USB A (4 pin) Male

Serial Protocol RS-232

Max Baud Rate 921.6 Kbps

Data Bits 7, 8

FIFO 256 byte Transmit, 128 byte Receive buffer

Parity None, Odd, Even, Mark, Space

Stop Bits 1, 2

OS Compatibility Windows® 7 (32/64bit), Vista(32/64), XP(32/64), 2000, CE(4.2+)

Windows® Server 2008 R2/ 2003(32/64)

Mac OS 9.x, 10.x

Linux

Color Black

Enclosure Type Plastic

Cable Length 3.3 ft [1 m]

Product Length 7 in [179 mm]

Product Width 1.3 in [33.5 mm]

Product Height 0.6 in [16.5 mm]

Product Weight 3.1 oz [88 g]

Power Adapter Included USB Powered

Operating Temperature 0°C to 55°C (32°F to 131°F)

Storage Temperature -20°C to 85°C (32°F to 185°F)

Humidity 5~95% RH

System and Cable Requirements One available USB 1.1 (or better) port

Shipping (Package) Weight 0.5 lb [0.2 kg]

Included in Package 1 - USB to RS-232 Null Modem Adapter

Included in Package 1 - Driver CD

Included in Package 1 - Instruction Manual

Certifications, Reports and Compatibility
