MATERIAL SAFETY DATA SHEET

Lithium Polymer Rechargeable Battery

Model: 643463AP-1500mAh-2S

Prepared by Approved by

Jianyong Li Wangmei Zhang

Date：Dec. 07 ，2012 Date：Dec. 07，2012

Page 2 of 9

The information and recommendations set forth are made in good faith and believed to be accurate as of the date of preparation.

SPRINGPOWER TECHOLOGY SHENZHEN CO.,LTD. makes no warranty, expressed or implied, with respect to this information and

disclaims all liabilities from reliance on it --- File No./Rev.: SP-MSDS-036/E00

Material Safety Data Sheet

-C

SP Lithium-Ion Polymer battery

Norminal Voltage ：3.7 V

Norminal Capacity ：3000mAh

Equivalent Lithium content ：11.1Wh

Testing Period ：Dec. 03，2012 To Dec. 06，2012

SPRINGPOWER TECHOLOGY SHENZHEN CO.,LTD

Chaoshun Industrial Zone, Renmin Road, Fumin, Guanlan, Baoan, Shenzhen, Guangdong, China

Postcode ：518110

Telephone ：+86-755- 61862699-818

Fax ：+86-755-29522241

E-mail ：jyli@highpowertech.com

-C

Chemical Composition

Molecular F

ormula

Weight%

CAS No

OSHA

(PEL)

ACGIH

(TLV)

Lithium Cobalt Oxide LiCoO235～38% 12190-79-3 N/A N/A

Graphite powder C 23～25% 7782-42-5 N/A N/A

Electrolyte LiPF6 C3H4O3

C4H6O3 C3H10O312～15% 21324-40-3 N/A N/A

Polyethylene （C2H4）n 0.5～1% 9002-88-4 N/A N/A

Cu Cu 5～10% 7440-50-8 N/A N/A

Nickel Nickel 2～3% 7440-02-0 N/A N/A

Polyvinylidene fluoride （CH2CF2）n 0.5～2% 24937-79-9 N/A N/A

Polypropylene （C3H6）n 2～5% 9003-07-0 N/A N/A

Aluminum foil Al 7～10% 7429-90-5 N/A N/A

Silicon Si 1～2% 7440-21-3 N/A N/A

Epoxy Resin EP 1.5～2% 38891-59-7 N/A N/A

Fibre glass 1.5～2% 65997-17-3 N/A N/A

PVC (C2H3Cl)x 0.2～0.5%9002-86-2 N/A N/A

Gold Au 0.2～0.5%7440-57-5 N/A N/A

Sn Sn 0.05～0.1% 7440-31-5 N/A N/A

-C

Page 3 of 9

The information and recommendations set forth are made in good faith and believed to be accurate as of the date of preparation.

SPRINGPOWER TECHOLOGY SHENZHEN CO.,LTD. makes no warranty, expressed or implied, with respect to this information and

disclaims all liabilities from reliance on it --- File No./Rev.: SP-MSDS-036/E00

-H

Preparation

hazards and

classification

Not dangerous with normal use. Do not dismantle, open or shred Li-ion Battery.

Exposure to the ingredients contained within or their ingredients products could be harmful.

Appearance,

Color, and

Odor

Solid object with no odor, no color.

Primary

Route(s) of

Exposure

These chemicals are contained in a sealed stainless steel enclosure. Risk of exposure occurs

only if the cell is mechanically, thermally or electrically abused to the point of

compromising the enclosure. If this occurs, exposure to the electrolyte solution contained

within can occur by Inhalation, Ingestion, Eye contact and Skin contact.

Potential

Health

Effects:

ACUTE (short term): see Section 8 for exposure controls In the event that this battery has

been ruptured, the electrolyte solution contained within the battery would be corrosive and

can cause burns.

Inhalation: Inhalation of materials from a sealed battery is not an expected route of

exposure. Vapors or mists from a ruptured battery may cause respiratory irritation.

Ingestion: Swallowing of materials from a sealed battery is not an expect

ed route of

exposure. Swallowing the contents of an open battery can cause serious chemical burns of

mouth, esophagus, and gastrointestinal tract.

Skin: Contact between the battery and skin will not cause any harm. Skin contact with

contents of an open battery can cause severe irritation or burns to the skin.

Eye: Contact between the battery and the eye will not cause any harm. Eye contact with

contents of an open battery can cause severe irritation or burns to the eye.

CHRONIC (long term): see Section 11 for additional toxicological data

Medical

Conditions

Aggravated

Exposure

Not applicable

Reported as

carcinogen

Not applicable

-F

-a

Inhalation If contents of an opened battery are inhaled, remove source of contamination or move victim

to fresh air. Obtain medical advice.

Skin contact If skin contact with contents of an open battery occurs, as quickly as possible remove

contaminated clothing, shoes and leather goods. Immediately flush with lukewarm, gently

flowing

water for at least 30 minutes. If irritation or pain persists, seek medical attention.

-H

-F

-a

Page 4 of 9

The information and recommendations set forth are made in good faith and believed to be accurate as of the date of preparation.

SPRINGPOWER TECHOLOGY SHENZHEN CO.,LTD. makes no warranty, expressed or implied, with respect to this information and

disclaims all liabilities from reliance on it --- File No./Rev.: SP-MSDS-036/E00

Completely decontaminate clothing, shoes and leather goods before reuse or discard.

Eye contact If eye contact with contents of an open battery occurs, immediately flush the contaminated

eye(s) with lukewarm, gently flowing water for at least 30 minutes while holding the eyelids

open. Neutral saline solution may be used as soon as it is available. If necessary, continue

flushing during transport to emergency care facili

ty. Take care not to rinse contaminated

water into the unaffected eye or onto face. Quickly transport victim to an emergency care

facility.

Ingestion

If ingestion of contents of an open battery occurs, never give anything by mouth if victim is

rapidly los

ing consciousness, or is unconscious or convulsing. Have victim rinse mouth

thoroughly with water. DO NOT INDUCE VOMITING. Have victim drink 60 to 240 mL

(2-

8 oz.) of water. If vomiting occurs naturally, have victim lean forward to reduce risk of

aspiratio

n. Have victim rinse mouth with water again. Quickly transport victim to an

emergency care facility.

Flammable

Properties

In the event that this battery has been ruptured, the electrolyte solution contain within the

battery would be flammable. L

ike any sealed container, battery cells may rupture when

exposed to excessive heat; this could result in the release of flammable or corrosive

materials.

Suitable

extinguishing

Media

Use extinguishing media suitable for the materials that are burning.

Unsuitable

extinguishing

Media

Not available

Explosion

Data

Sensitivity to Mechanical Impact: This may result in rupture in extreme cases

Sensitivity to Static Discharge: Not Applicable

Specific

Hazards

arising from

the chemical

Fires involving Li-

ion Battery can be controlled with water. When water is used, however,

hydrogen gas may evolve. In a confined space, hydrogen gas can form an explosive mixture.

In this situation, smothering agents are recommended to extinguish the fire

Protective

Equipment

and

precautions

for firefighters

As for any fire, evacuate the area and fight the fire from a safe distance. Wear a

pressure-demand, self-contained breathing apparatus and full protective gear.

Fight fire from a protected locatio

n or a safe distance. Use NIOSH/MSHA approved

full-face self-contained breathing apparatus(SCBA) with full protective gear.

NFPA Health: 0 Flammability: 0 Instability: 0

-F

Page 5 of 9

The information and recommendations set forth are made in good faith and believed to be accurate as of the date of preparation.

SPRINGPOWER TECHOLOGY SHENZHEN CO.,LTD. makes no warranty, expressed or implied, with respect to this information and

disclaims all liabilities from reliance on it --- File No./Rev.: SP-MSDS-036/E00

-A

Personal Precautions, protective equipment, and

emergency procedures

Restrict access to area until completion of

clean-up. Do not touch t

he spilled material. Wear

adequate personal protective equipment as

indicated in Section 8.

Environmental Precautions

Prevent material from contaminating soil and

from entering sewers or waterways.

Methods and materials for Containment

Stop the leak if safe to do so. Contain the spilled

liquid with dry sand or earth. Clean up spills

immediately.

Methods and materials for cleaning up Absorb spilled material with an inert absorbent (dry

sand or earth). Scoop contaminated absorbent into an

acceptable waste container.

Collect all contaminated absorbent and dispose of

according to directions in Section 13. Scrub the area

with detergent and water; c

ollect all contaminated

wash water for proper disposal.

Handling

Don’t handling Li-ion Battery with metalwork. Do not

open, dissemble, crush or burn battery.

Ensure good ventilation/ exhaustion at the workplace.

Prevent formation of dust. Inf

ormation about

protection against explosions and fires: Keep ignition

sources away- Do not smoke.

Storage

If the Li-ion Battery are subject to storage for such a

long term as more than 3 months, it is recommended

to recharge the Li-ion Battery periodically.

3 months: -10 ℃~+40 ℃

, 45 to 85%RH And

recommended at 0℃~+35℃

for long period storage.

The capacity recovery rate in the delivery state (50%

capacity of fully charged) after storage is assumed to

be 80% or more. The voltage for a long time storage

shall be 3.7V~4.2V range.

-H

-A

Page 6 of 9

The information and recommendations set forth are made in good faith and believed to be accurate as of the date of preparation.

SPRINGPOWER TECHOLOGY SHENZHEN CO.,LTD. makes no warranty, expressed or implied, with respect to this information and

disclaims all liabilities from reliance on it --- File No./Rev.: SP-MSDS-036/E00

Do not storage Li-ion Battery haphazardly in a box or

drawer where they may short-circuit each other or be

short-circuited by other metal objects.

Keep out of reach of children.

Do not expose Li-ion Battery to heat or fire.

Avoid storage in direct sunlight.

Do not store together with oxidizing and acidic

materials.

-E

Engineering Controls

Use local exhaust ventilation or other engineering

controls to control sources of dust, mist, fumes and

vapor. Keep away from heat and open flame. Store in

a cool, dry place.

Personal Protective Equipment Respiratory Protection: Not necessary under

normal conditions.

Skin and body Protection: Not necessary under

normal conditions, Wear neoprene or nitrile rubber

gloves if handling an open or leaking battery.

Hand protection: Wear neoprene or natural rubber

material gloves if handling an open or leaking

battery.

Eye Protection: Not necessary under normal

conditions, Wear safety glasses if handling an open or

leaking battery.

Other Protective Equipment

Have a safety shower and eye wash fountain readily

available in the immediate work area.

Hygiene Measures

Do not eat, drink, or smoke in work area.

Maintain good housekeeping.

-P

Physical

State

Form: Solid

Color: White

Odour: Monotony

Change in condition:

-E

-P

Page 7 of 9

The information and recommendations set forth are made in good faith and believed to be accurate as of the date of preparation.

SPRINGPOWER TECHOLOGY SHENZHEN CO.,LTD. makes no warranty, expressed or implied, with respect to this information and

disclaims all liabilities from reliance on it --- File No./Rev.: SP-MSDS-036/E00

pH, with indication of the concentration

Not applicable

Melting point/freezing point Not available.

Boiling Point, initial boiling point and Boiling

range:

Not available.

Flash Point Not available.

Upper/lower flammability or explosive limits Not available.

Vapor Pressure: Not applicable

Vapor Density: (Air = 1) Not applicable

Density/relative desity Not available.

Solubility in Water: Insoluble

n-octanol/water partition coefficient Not available.

Auto-ignition temperature 130℃

Decomposition temperature Not available.

Odout threshold Not available.

Evaporation rate Not available.

Flammability (soil, gas) Not available.

Viscosity Not applicable

Stability The product is stable under normal conditions.

Conditions to Avoid (e.g. static discharge, shockor

vibration)

Do not subject Li-ion Batteryto mechanical shock.

Vibration encoutered during transportation does not

cause leakage, fire or explosion.

Do not disassemble, crush, sh

ort or install with

incorrect polarity. Avoid mechanical or electrical

abuse.

Incompatible Materials Not Available

Hazardous Decomposition Products This material may release toxic fumes if burned

or exposed to fire

Possibility of Hazardous Reaction Not Available

Page 8 of 9

The information and recommendations set forth are made in good faith and believed to be accurate as of the date of preparation.

SPRINGPOWER TECHOLOGY SHENZHEN CO.,LTD. makes no warranty, expressed or implied, with respect to this information and

disclaims all liabilities from reliance on it --- File No./Rev.: SP-MSDS-036/E00

-T

Irritation

Risk of irritation occurs only if the cell is

mechanically, thermally or electrically abused to the

point of compromising the enclosure. If this occurs,

irritation to the skin, eyes and respiratory tract may

occur.

Sensitization Not Available

Neurological Effects Not Available

Teratoaenicitv Not Available

Reproductive Toxicity Not Available

Mutagenicity (Genetic Effects) Not Available

Toxicologically Synergistic Materials Not Available

General note: Water hazard class 1(Self-assessment): slightly

hazardous for water.

Do not allow undiluted product or large quantities

of it to reach ground water, water course or

sewage system.

Anticipated behavior of a chemical product in

environment/possible environmental

impace/ecotoxicity

Not Available

Mobility in soil

Not Available

Persistence and Degradability Not Available

Bioaccumulation potential Not Available

Other Adverse Effects Not Available

-D

Product disposal recommendation: Observe local, state and federal laws and regulations. Packaging disposal

recommendation: Be aware discarded batteries may cause fire, tape the battery terminals to insulate them. Don’t

disassembly the battery. Completely discharge containers(no tear drops, no powder rest, scraped arefully). Containers

may be recycled or re-used. Observe local, state and federal laws and regulations.

-E

-D

-T

Page 9 of 9

The information and recommendations set forth are made in good faith and believed to be accurate as of the date of preparation.

SPRINGPOWER TECHOLOGY SHENZHEN CO.,LTD. makes no warranty, expressed or implied, with respect to this information and

disclaims all liabilities from reliance on it --- File No./Rev.: SP-MSDS-036/E00

-T

The battery models listed have aggregate equivalent lithium content is not more than 100Wh.And shipment contains

no item listed under IATADGR Special Provision A154 and meets all requirements under UN Manual of Tests and

Criteria Part III, subsection 38.3.

No ITEMS RESULT REMARKS

1 Altitude simulation Pass

Test 1 to 5 must be conducted in sequence on the same

cell or battery

2 Thermal test Pass

Vibration

Pass

4 Shock Pass

5 External short circuit Pass

6 Impact Pass

7 Overcharge Pass Only battery do need this test item

The product is not classified as dangerous Goods according to the current edition of IATA Dangerous Goods

Regulations. And not regulated by IATADGR. This product fully conforms to IATA Shipping PI 965, section Ⅱ. Do

not damage or mishandle this package. If package is damaged, batteries must be quarantined, inspected, and repacked.

For emergency information, call: +86-755-61862699.

The Li-ion Battery according to NEW PACKING INSTRUCTION 965~967 of IATA DGR 53 rd Edition for

transportation.

-R

OSHA hazard communication standard (29 CFR 1910.1200)

Hazardous V Non-hazardous

-O

This information is not effective to all the batteries manufactured by SPRINGPOWER. This information comes

from reliable sources, but no warranty is made to the completeness and accuracy of information contained.

SPRINGPOWER doesn’t assume responsibility for any damage or loss because of misuse of batteries. Users should

grasp the correct use method and be responsible for the use of batteries.

-O

-R

-T

Other SPRINGPOWER Camera Accessories manuals

SPRINGPOWER

SPRINGPOWER 18500AY-1400mAh-2S User manual

Popular Camera Accessories manuals by other brands

Viltrox

Viltrox EF-NEX Mount instructions

Calumet

Calumet 7100 Series CK7114 operating instructions

Ropox

Ropox 4Single Series User manual and installation instructions

Cambo

Cambo Wide DS Digital Series Main operating instructions

Samsung

Samsung SHG-120 Specification sheet

Ryobi

Ryobi BPL-1820 Owner's operating manual

Aegis

Aegis ABL-36020P user manual

Pentax

Pentax Data Back Fc operating manual

Fantasea

Fantasea EyeGrabber F Series instruction manual

Honeywell

Honeywell HDZ20HD user manual

EGO

EGO BA1400T Operator's manual

Sima

Sima SRW-62 user guide

Shape

Shape A7SSMKIT Assembly manual

Slide Kamera

Slide Kamera HST-2 user manual

Power works

Power works 2902613 Original instructions

SES

SES SE-2047-2 user manual

Olympus

Olympus PT-EP05L instruction manual

Starlite

Starlite OctoDome nxt instructions
