Speed Queen ATSA0AWN User manual

Frontload Washers

CTSA0A (Front Control)

ATSA0A (Rear Control)

ATSA5A (Rear Control)

Laundry — it’s all we do.

Model CTSA0A ATSA0A ATSA5A

Appeara ce

Color: White ✔✔✔

3.3 cu.ft.* Stainless ✔✔✔

Steel Washtub

3 Stainless Steel Baffles ✔✔✔

Stainless Steel Outer ✔✔✔

Draintub

15 1/2" Door Opening ✔✔✔

10" Stainless Steel Hinge ✔✔✔

Galvanized Steel Cabinet ✔✔✔

Front Controls ✔

Rear Controls ✔✔

Tech ical I formatio

Tub Volume - cu. ft.* 3.3 3.3 3.3

Overall Dimensions - 41 3/8" x 26 7/8" x 28" 43" x 26 7/8" x 28" 43" x 26 7/8" x 28"

H x W x D

Cabinet Height - in 41 3/8" 36" 36"

Approximate Shipping 260 250 250

Weight - lb

Electrical Requirements - 120V/60 HzAC 120V/60 HzAC 120V/60 HzAC

Breaker Size 15 Amp 15 Amp 15 Amp

Motor Horsepower 3/4 3/4 3/4

Water Pressure - psi (bar) 20 - 120 20 - 120 20 - 120

Spin Speed 500, 650, 1000 500, 650, 1000 500, 650, 1000

Performa ce/Features

ENERGY STAR®Qualified

Boosted Heat - 140° ✔

ADA Compliant ✔✔✔

300 G-Force High Speed ✔✔✔

Water Extraction

Variable Speed ✔✔✔

Induction Motor

4,912 Cylinder Holes ✔✔✔

Extra Rinse Option ✔✔✔

Cycle Indicator ight ✔✔✔

Tuff Guard Coated Top ✔✔✔

Three Compartment Solution ✔✔✔

Dispenser

Wash Cycles

Cycles 888

Average Water 13.9 13.9 13.9

Consumption - Gallons

Agency Approvals U U U

www.speedquee .com

AR07-212

Speed Queen washers can be raised on an optional 8"pedestal.

(Sold separately. Part number PDR108W)

Speed Quee Warra ty

Speed Queen brings to you the industry’s best

warranty on all of our washers and dryers.

3 years on parts and labor.

5 years on the motor.*

5 years on the cabinet.*

5 years on bearings and seal assembly.*

Lifetime on all stainless steel washtubs and outer draintubs.*

* imited. See Speed Queen warranty bond for details.

CTSA0A (Shown on front) -8Cycles, ADA Compliant, ENERGY STAR®

Qualified, Front Control

ATSA0A -8Cycles, ADA Compliant, ENERGY STAR®Qualified,

Rear Control

Since 1908, Speed Queen laundry equipment has set the standard for commercial durability, a record

exemplified daily in coin laundries worldwide. Our products for the home deliver the same American-built

reliability and unparalleled performance that have made us an industry leader. Laundry — it’s all we do.

For the most accurate information the installation guide should be used for all design and construction

purposes. Due to continuous product improvements, design and specifications are subject to change

without notice. The quality management systems at all Alliance aundry Systems’ Ripon facilities are

registered to ISO 9001:2000.

Printed in the U.S.A.

Printed on paper manufactured with virgin pulp from certified sources and a minimum of 10%

post-consumer recovered fiber.

* Based on IEC Rating.

ATSA0ACTSA0A

ATSA5A -8Cycles, ADA Compliant, ENERGY STAR®Qualified,

Rear Control, Boosted Heat
