Sony XPERIA X PERFORMANCE User manual
Introduction
Thank you for purchasing this product.
Before You Begin
Guide Usage Notes
Screenshots & Key Labels
Accessing Guide on Handset
Before You Begin
SoftBank Xperia X Performance is referred to as "handset" in this guide.
Read "Safety Precautions" and this guide thoroughly beforehand for proper usage.
Accessible services may be limited by contract conditions.
Unauthorized copying of any part of this guide is prohibited.
Guide content subject to change without prior notice.
Guide Usage Notes
Most operation descriptions are based on default settings.
Unless noted otherwise, descriptions are for Home Screen.
Some operation descriptions may be omitted.
In this guide, microSDTM/microSDHCTM/microSDXCTM Card is referred to as "SD Card."
Screenshots & Key Labels
Screenshots and Key labels are provided for reference only. Actual handset windows, menus, etc.
may differ in appearance.
Accessing Guide on Handset
Use Guide application to learn touch operations or making settings.
In Home Screen, (SoftBank) (Guide)
Guide top window opens.
When opening for the first time, Usage notes and Auto Update confirmation appear. Follow
onscreen instructions.
Package Contents
Package Contents
Package Contents
Handset (Xperia X Performance)
TV Antenna Cable (SODAB1)
クイックスタート (Japanese)
お願いとご注意 (Japanese)
Warranty (Japanese)
Parts & Functions
Front/Top/Bottom
Handset Keys
CE mark and FCC ID
Front/Top/Bottom
Part
Description
Headphone Port Connect commercially
available headphones.
This port supports
tetrapolar headset that
conform to the CTIA
standard.
Second Mic Reduces noise for
calling.
FeliCa Mark Hold mark up to
reader/writer to use
NFC/Osaifu-Keitai®
feature.
Front Camera
Capture yourself.
Earpiece/Speaker Hear the other party's
voice here.
Notification Lamp Flashes for incoming
transmissions. Lights
while charging.
Proximity/Light
Sensor
Detects surrounding
brightness to
automatically adjust
Display or backlight
and prevent
Touchscreen
misoperation during a
call.
Display
Handset uses a
touchscreen-type
Display. Operate with
your fingers on
Display.
Speaker
Speak here.
Item
Description
Camera Capture still images
and videos.
Internal
Antenna/GPS
Antenna Area
Internal Antenna for
calls, data
communication and
GPS.
Flash/Photo Light Use as camera flash in
a dark place.
Wi-Fi/Bluetooth®
Antenna Area
Internal Antenna for
Wi-Fi and Bluetooth®
feature.
Nameplate CE mark, FCC ID,
IMEI information
printed sticker is
attached. Do not
remove nameplate.
Internal Antenna
Area
Internal Antenna for
call and data
communication.
SIM Card/SD Card
Slot
Insert SIM Card/SD
Card.
Mic
External Device
Port
Connect commercially
available Micro USB
Cable etc.
Handset Keys
Part
Description
Power
Key/Screen
Lock
Key/Fingerpr
int Sensor
( )
Long Press for power on/off.
Press for sleep mode on/off.
Or, use Fingerprint
authentication.
Volume/Zoo
m Up/Down
Key
Adjust Volume.
Adjust Zoom while using
Camera.
Camera
Key ( )
Use as Camera shutter.
Long Press to launch Camera.
CE mark and FCC ID
Open the slot cover, and insert a fingernail into the hook at the edge of the label tray,
then pull it out straight.
SIM Card Installation
SIM Card is an IC card containing phone number and other customer information.
Inserting SIM Card
Removing SIM Card
Inserting SIM Card
Always unmount SD Card beforehand. For details, see "Unmounting SD Card."
Open Slot Cover using groove
Draw Tray out using the tab
Set SIM Card into Tray with IC chip facing up
Check SIM Card orientation by notch.
Insert Tray with SIM Card into handset
Check Tray orientation.
Close Slot Cover and press it down where indicated ○, and make sure there are no
gaps
Removing SIM Card
Always unmount SD Card beforehand. For details, see "Unmounting SD Card."
Open Slot Cover using groove
Draw Tray out using the tab
Remove SIM Card from Tray
