Sony Style Cover Touch User manual
User guide
Style Cover Touch
SCR56
Contents
Getting started............................................................................... 3
Introduction........................................................................................3
Overview............................................................................................3
Pairing................................................................................................4
Charging............................................................................................ 5
Learning the basics........................................................................7
Using your phone with the Style Cover Touch.................................. 7
Dimming and waking up the screen.................................................. 9
Disabled smartphone features...........................................................9
General settings...........................................................................10
Customizing the Style Cover settings..............................................10
Legal information..........................................................................11
2
This is an Internet version of this publication. © Print only for private use.
Getting started
Introduction
The Style Cover Touch is a smart cover for your Xperia™ smartphone, that lets you
use your phone with a closed cover. The front cover lid is see-through, so you can
see and use your phone’s entire display, even when the cover is closed. For example,
you can launch apps, browse the internet, take a selfie or reply to messages.
Overview
1 NFC™ detection area
2 Front cover lid
3
This is an Internet version of this publication. © Print only for private use.
Pairing
Pair the Style Cover Touch with your phone
1Open the front cover lid and find the NFC™ detection area.
2Make sure that the NFC™ function on the phone is enabled and that the
screen is active and unlocked.
3Touch the NFC™ area of your phone against the NFC™ detection area of the
accessory, as indicated in the illustration.
If you touch the NFC™ detection area again, the pairing will be undone. To pair again, simply
repeat the steps listed above.
4
This is an Internet version of this publication. © Print only for private use.
To attach the Style Cover Touch to your phone
Make sure that the back of the phone is clean.
1Position the phone over the corresponding part of the accessory so that the
camera lens is aligned with the camera lens hole of the cover.
2First insert the right side of the phone, then the left, and then firmly press down
all edges of the phone into the cover so that it is securely attached.
To detach the Style Cover Touch from your phone
1Position the fingernail of your thumb in the gap between the cover and phone
at the left edge of the phone.
2Lift the phone up gently with your other thumb until you can remove the phone
from the cover.
Charging
Before you attach the Style Cover Touch to your phone and use it for the first time,
make sure that the battery is charged.
5
This is an Internet version of this publication. © Print only for private use.
To charge your phone while using the Style Cover Touch
1Plug one end of the charger cable into the charging dock, then plug the other
end into the USB port of a computer or a phone charger. If you are using a
phone charger, plug the charger into a power outlet.
2Insert the required attachment into the charging dock.
3Place your phone in the dock so that the charging dock connector on the
phone makes contact with the connector in the dock.
If you aren't sure of the location of the charging dock connector on your phone, refer to the
relevant phone User guide.
6
This is an Internet version of this publication. © Print only for private use.
Learning the basics
Using your phone with the Style Cover Touch
Once the Style Cover Touch is set up and attached to your phone, you can interact
with your phone’s display through the front cover lid. For example, you can swipe,
flick or tap on the screen cover to navigate around.
Swiping
•Swipe to navigate or reveal more options
Tapping
•Tap to open or select an item
7
This is an Internet version of this publication. © Print only for private use.
Scrolling
•Drag or flick your finger in the direction you want to scroll
Flicking
•Flick to navigate
Pinching
•Pinch-in or pinch-out to zoom in or out
8
This is an Internet version of this publication. © Print only for private use.
Touching and holding
•Touch and hold to move items or reveal more options
Dimming and waking up the screen
When the Style Cover Touch is attached to your phone and left idle for a certain
period of time, the screen dims automatically. You can also dim or wake up the
screen manually at any time.
To dim or wake up the window screen manually
•Briefly press the power key.
Disabled smartphone features
The Glove mode and Tap to wake up features do not work when the front cover lid is closed.
For more information about these features, refer to the User guide for your phone.
9
This is an Internet version of this publication. © Print only for private use.
General settings
Customizing the Style Cover settings
View and change your Style Cover Touch settings using the Style Cover application.
The Style Cover application is accessible from the Application screen.
To open the Style Cover application
1From your Home screen, tap .
2Find and tap Style Cover.
To increase screen brightness when the cover is closed
1From your Home screen, tap .
2Find and tap Style Cover > Brightness increase when the cover is closed.
3Select an option.
10
