SONY

3-753-183-21

(1)

Stereo

Power

Amplifier

XM-5540F

Operating

Instructions

pasce2

Before

operating

the

unit,

please

read

this

manual

thoroughly

and

retain

it

for

future

reference.

Mode

d’emploi

page

14

Avant

la

mise

en

service

de

l'appareil,

lire

attentivement

ce

mode

d'emploi

et

le

conserver

pour

toute

référence

ultérieure.

©1991

by

Sony

Corporation

|

English

|

BE-le)(-We)M@e)

ah

21a

cs

Features...

Precautions

Installation

........

Deda

sates

os

Location

and

function

of

controls

..

Connections...

hisecteeets

:

Connection

of

a

4-speaker

system

.....

Connection

of

a

3-speaker

system

.....9

Connection

of

a

2-speaker

system

...10

Level

adjustment

control..

Owner's

Record

The

model

and

serial

numbers

are

located

on

the

bottom.

Record

the

seria!

number

in

the

space

provided

below.

Refer

to

them

whenever

you

call

upon

your

Sony

dealer

regarding

this

product.

Model

No.

XM-5540F

Serial

No.

Features

*

Provided

with

a

built-in

crossover

network

with

the

High

Pass

Filter

(HPF=80

Hz}

and

Low

Pass

Filter

(LPF=80

Hz).

*

Maximum

power

output

of

100

watts

per

channel

*

Power

output

of

55

watts

per

channel

(20-

20,000

Hz,

0.08%,

4

ohms)

Ad

Hoc

Committee

standard

*

Wide

dynamic

range

and

low

distortion

(less

than

0.005%)

*

A

protection

circuit

is

provided.

*

Pulse

power

supply"

for

stable,

regulated

output

power

*

Pulse

power

supply

This

amplifier

employs

pulse

techniques

in

its

power

supply

section.

The

use

of

this

original

light-weight

power

supply

system

provides

a

high-voltage,

a

high-efficiency

power

supply.

That

is

highly

regulated

under

variations

in

the

automobile's

electrical

voltage

Precautions

*

This

unit

is

designed

for

negative

ground

12

V

DC

operation

only.

*

The

nameplate

indicating

operating

voltage,

etc.

is

located

on

the

bottom

exterior.

*

Use

speakers

with

an

impedance

of

2

to

8

ohms.

*

Avoid

installing

the

unit

where:

—

It

would

be

subject

to

high

temperatures,

such

as

from

direct

sunlight

or

from

hot

air

from

the

heater.

—

lt

would

be

exposed

to

rain

or

moisture.

—

It

would

be

subject

to

dust

or

dirt.

*

If

your

car

is

parked

in

direct

sunlight

and

there

is

a

considerable

rise

in

temperature

inside

the

car,

allow

the

unit

to

cool

off

before

operating.

*

When

instailing

the

unit

vertically,

make

sure

that

the

fins

of

the

heat

sink

are

vertical

to

the

O

This

way

*

When

installing

the

unit

horizontally,

be

sure

not

to

cover

the

fins

with

the

floor

carpet

and

soon.

If

this unit

is

placed

too

close

to

the

car

radio,

an

interference

may

occur.

In

this

case,

separate

the

amplifier

from

the

car

radio.

lf

no

power

is

being

supplied

to

the

cassette

player

or

tuner,

check

the

connections.

*

This

power

amplifier

employs

a

protection

circuit*

to

protect

the

transistors

and

speakers

if

the

amplifier

malfunctions.

Do

not

attempt

to

test

the

protection

circuits

by

covering

the

heat

sink

or

connecting

improper

loads.

{f

you

have

any

questions

or

problems

concerning

your

unit

that

is

not

covered

in

this

manual,

please

consult

your

nearest

Sony

deater.

Fuse

Replacement

—

If

the

fuse

blows,

check

the

power

connection

and

replace

the

fuse.

If

the

fuse

blows

again

after

replacement,

there

may

be

an

internal

malfunction.

In

this

case,

consult

your

nearest

Sony

dealer.

Warning

Use

the

specified

ampere

fuse.

Use

of

a

higher

amperage

fuse

may

cause

serious

damage.

SMELL

“Protection

circuit

This

amplifier

is

provided

with

a

protection

circuit

which

operates

in

the

following

cases:

*

the

unit

is

overheated

*

a

DC

current

is

generated

*

the

speaker

terminals

are

short

circuited

When

a

protection

circuit

activates,

the red

indicator

lights

up

and

there

will

be

an

abrupt

loss

of

sound

trom

the

speakers.

If

this

happens,

turn

off

the

connected

equipment

and

take

out

the

cassette

tape

or

disc

and

determine

the

cause

of

the

malfunction.

If

the

amplifier

becomes

overheated,

wait

until

the

unit

cools

off.

PROTECTOR

indicator

(red)

POWER

indicator

(green)

Tatsyeclirctiteyal

|

Moyer-1ielamclacem

ml

Ulaveli(olame)m@xelaline)

i)

Before

Installation

*

Choose

the

mounting

location

carefully

so

that

the

unit

will

not

interfere

with

the

normal

driving

functions

of

the

driver

and

that

the

unit

will

not

be

exposed

to

direct

sunlight

or

hot

air

from

the

heater.

*

Do

not

install

the

unit

under

the

floor

carpet,

where

the

heat

dissipation

from

the

unit

will

be

considerably

impaired.

Trunk

installation

Prepare

a

suitable

mounting

board

to

install

the

unit

securely

1

Mark

the

four

bolt

holes

on

the

mounting

board

using

the

template

(printed

on

the

carton),

then

drill

the

holes

(3

mm

dia.).

Temptate

3

Secure

the

board

in

the

trunk

compartment.

INPUT

MODE

C(MONO)/A(MONO):

monaural

mode

for

the

2-speaker

system

ST:

stereo

mode

for

the

4-speaker

system

or

the

3-speaker

system

C+D/A+B:

mix

mode

for

mixing

A(C)

and

B(D)

channels

FILTER

(Crossover

network

switch)

OFF:

High

Pass

filter

and

Low

Pass

filter

are

off.

HP:

High

Pass

filter

is

on.

LP:

Low

Pass

filter

is

on.

PROTECTOR

(Protection

circuit

indicator)(red)

POWER

(Power

supply

indicator)

(green)

To

indicate

that

power

is

supplied.

LEVEL

(Level

adjustment

control)

Connections

Caution

*

Before

making

connections,

disconnect

the

ground

terminal

of

the

car

battery

to

avoid

short

circuits.

*

Connect

the

red

power

input

lead

only

after

all

other

leads

have

been

connected.

*

Be

sure

to

connect

the

ground

wire

of

the

unit

securely

to

a

metal

point

of

the

car.

A

loase

connection

may

cause

a

malfunction

oft

the

amplifier.

*

Be

sure

to

use

speakers

with

adequate

power

handling

capacities.

H

you

use

speakers

with

small

capacity,

they

will

be

damaged.

*

Do

not

connect

the

—

terminal

of

the

speaker

system

with

the

car

chassis,

and

do

not

connect

the

~

terminal

of

the

right

speaker

with

that

of

the

left

speaker.

*

If

your

car

is

equipped

with

computer

system

for

navigation

or

some

other

purposes,

be

sure

not

to

remove

the

ground

wire

fram

the

car

bettery.

If

you

disconnect

the

wire,

the

memory

of

the

computer

may

be

erased.

To

avoid

short

circuits

when

making

connections,

try

to

connect

the

+12

V

power

input

lead

only

after

all

other

leads

have

been

connected

Make

terminal

connections

as

illustrated

below.

Loosen

the

screw

of

the

terminal

and

wind

the

stripped

cord

around

the

screw.

Tighten

the

screw

down

with

a

screwdriver.

Make

sure

that

the

cord

cannot

be

pulled

out.

Connection

of

a

4-speaker

System

Before

making

connections,

remember

that

the

input

signal

to

each

jack

(A,

8,

C,

D)

is

output

from

the

corresponding

speaker

terminals.

Car

stereo

Remote

contro!

lead

id

Front

Sub

woofers

speakers

To

a

metal

point

of

the

car

.

‘a

Fuse

Example

of

switch

positions

(at

least

60A)

Speaker

maximum,

INPUT

MODE

L

FILTER

power

output

A

Bete

aie

iGo.

W

12V

car

battery

coreg

ca

C/D

CHANNEL

INPUT

MODE

FALTER

a

STA+B

ore

we

a

acae

wa-n)

AB

CHANNEL

INPUT

MODE

mee

+

Use

the

power

connecting

cord

with

the

fuse

Notes

on

the

4-speaker

connection

attached

{at

least

60

A).

=

In

a

4-speaker

system,

set

both

INPUT

MODE

switches

to

the

ST

position.

Then

set

the

filter

switches

to

the

desired

positions

and

connect

the

speaker

cords

to

the

terminals

marked

+

-A-—,

~-B-

+.

+

-C-~

and

~-D-

tas

shown

above.

+

Make

sure

to

connect

the

remote

control

lead

of

the

car

Stereo

to

the

REMOTE

terminal.

Connections

Connection

of

a

4-speaker

System

Remote

control

lead

Example

of

switch

positions

To

a

metat

point

of

the

speakers

speakers

Fuse

y

(atleast

60A)

~~

Speaker

maximum

|

INPUT

MODE

FILTER

power

output

12V

car

battery

CJMONO}

St

_C.«

0.

OFF

HP

LP

f

[mj

a

C/D

CHANNEL

INPUT

MODE

FILTER

A(MONO)

ST

A+

B

OFF

HP

LP

“th

|

ET

1/8

CHANNEL

INPUT

MODE

FILTER

Remote

control

lead

Front

speakers

Example

of

switch

positions

INPUT

MODE

‘|

FILTER

Speaker

maximum

C/O

CHANNEL

power

output

£

ST

C+O

OFF

HP

LP

“CE

|

20w

(INPUT

MODE

FILTER

AMONG}

ST

A+

8

OFF

He

LP

100

W

INPUT

MODE

FUER

100

W

A/B

CHANNEL

Sub

woofers

To

a

metat

point

of

the

car

Fuse

(at

least

60A)

12V

car

battery

Notes

on

the

3-speaker

connection

+

In

a

3-speaker

system,

use

the

A.

B,

C

and

D

input

jacks

and

set

one

of

tha

INPUT

MODE

switches

to

the

ST

position

for

the

2-speaker

connection

and

the

other

INPUT

MODE

switch

to

the

A+B

or

C+D

position

for

the

1-speaker

connection.

Then

set

one:

of

the

filter

switches

to

the

HP

position

for

the

2-

Speaker

connection

and

the

other

filter

switch

to

the

LP

position

for

the

1-speaker

connection.

For

example,

connect

the

speaker

cords

to

the

terminals

marked

“

-A-@,

—

-B-

*

and

+

—C+D

—

~

as

shown

above.

+

Make

sure

to

connect

the

remote

control

lead

of

the

car

stereo

to

the

REMOTE

terminal.

+

Use

the

power

connecting

cord

with

the

fuse

attached

(at

least

60

A).

Connections

Car

stereo

Connection

of

a

2-speaker

System

Remote

controt

lead

Sub

woofers

Example

of

switch

positions

INPUT

MODE

FILTER

power

output

‘Speaker

maximum.

(MONO)

ST.

C40

‘OFF

HP

LP

St

=

Ce

|

zx0w

INPUT

MODE

FILTER

AIMOMO)

ST

A+

@

OFF

MP

LP

=

“Ce

|

eaw

To

a

metal

point

of

the

Fuse

cer

(at

least

60A)

12V

car

battery

C/O

CHANNEL

A/B

CHANNEL

Level

Adjustment

Control

The

input

level

can

be

varied

with

this

control.

Use

it

to

adjust

the

input

sound

level

when

using

source

equipment

of

other

manufacturers.

Be

sure

to

set

the

control

to

SONY

STD

if

the

unit

is

connected

to

a

SONY

car

stereo.

Turn

it

to

0.1

V

when

the

input

level

of

the

cassette

car

stereo

or

CD

player

seems

low.

Notes

on

the

2-speaker

connection

+

Use

the

A

and

C

input

jacks

only

and

set

both

INPUT

MODE

switches

to

the

C(MONO)

position

and

the

A

{MONO)

position

respectively.

Then

set

the

filter

switches

to

the

desired

positions

and

cpnnect

the

speaker

cords

to

the

terminals

marked

+

—

A(MONO)

and

+

—

C(MONO}—

—

als

shown

above.

10

«

Make

sure

to

connect

the

remote

control

lead

of

the

ar

sterea

to

the

REMOTE

terminal.

+

Use

the

power

connecting

cord

with

the

fuse

attached

(at

least

60

A)

11

Specifications

AUDIO

POWER

SPECIFICATIONS

POWER

OUTPUT

AND

TOTAL

HARMONIC

DISTORTION

55

watts

per

channel

minimum

continuous

average

power

into

4

ohms,

both

channels

driven

from

20-20,000

Hz

with

no

more

than

0.08%

total

harmonic

distortion

per

Car

Stereo

Ad

Hoc

Committee

standards.

Power

supply

system

Pulse

power

supply

circuitry

Input

Car

stereo

input

(phono

jack)

Outputs

Speaker

outputs

Speaker

impedance

2-8

ohms

Maximum

power

output

4

ch:

100

watts

x

4

at

4

ohms

3

ch:

100

watts

x

2

+

220

watts

at

4

ohms

2

ch:

220

watts

x

2

at

4

ohms

Frequency

response:

8

Hz-100

kHz

*3

dB

(4

ohms)

Crossover

frequency

High

Pass

Fitter

80

Hz

Low

Pass

Filter

80

Hz

Crossover

slope

High

Pass

Filter

18

dB/oct

Low

Pass

Filter

18

dB/oct

12

Harmonic

distortion

0.005%

Input

level

adjustment

range

0.1-2V

Power

requirements

12

V

DC

car

battery

(negative

ground)

Current

drain

36

A

(at

rated

output)

Input

remote

current

5mA

Dimensions

Approx.

360

x

57

x

240

mm

(w/h/d)

(141

/a

x

2*/4

x

9¥/2

inches)

Weight

Approx.

4.9

kg

(10

tb.

13

02.)

Accessories

supplied

Mounting

screws

(4)

Design

and

specifications

subject

to

change

without

notice.
