Sony Ericsson Mobile phone User manual

This is the Internet version of the user's guide. © Print only for private use.

Contents 1

Contents

Getting to know your phone 4

Key functions, quick keys, entering letters.

Personalizing your phone 16

Download settings or choose from the phone.

Calling 24

Use the Phonebook, voice control, call options.

Messaging 43

Multimedia messaging, chat and e-mail.

Camera 51

Use the camera.

Setting up WAP and e-mail 54

All you need to know about setting up WAP and e-mail.

Using WAP 62

WAP browser, bookmarks.

Transferring and exchanging information 64

Bluetooth wireless technology, synchronization.

More features 69

Calendar, alarm clock, stopwatch, timer, games.

Security 76

SIM card lock, phone lock.

Troubleshooting 77

Why doesn’t the phone work the way I want?

Additional information 79

Safe and efficient use, warranty, declaration of conformity.

Icons 86

What do the icons mean?

Index 92

This is the Internet version of the user's guide. © Print only for private use.

2 Contents

Sony Ericsson

GSM 900/1800/1900

Third edition (May 2003)

This manual is published by Sony Ericsson Mobile

Communications AB, without any warranty.

Improvements and changes to this manual

necessitated by typographical errors, inaccuracies

of current information, or improvements to programs

and/or equipment, may be made by Sony Ericsson

Mobile Communications AB at any time and without

notice. Such changes will, however, be incorporated

into new editions of this manual.

©Sony Ericsson Mobile Communications AB, 2002

Publication number: EN/LZT 108 6460 R3A

Please note:

Some of the services in this manual are not supported

by all networks. This also applies to the GSM

International Emergency Number 112.

Please contact your network operator or service

provider if you are in doubt whether you can use a

particular service or not.

Please read the Guidelines for safe and efficient use

and the Limited warranty chapters before you use

your mobile phone.

The BLUETOOTH trademarks are owned by

Bluetooth SIG, Inc.

T9™ Text Input is a trademark or a registered

trademark of Tegic Communications.

T9™ Text Input is licensed under one or more of

the following: U.S. Pat. Nos. 5,818,437, 5,953,541,

5,187,480, 5,945,928, and 6,011,554; Canadian Pat.

No. 1,331,057, United Kingdom Pat. No. 2238414B;

Hong Kong Standard Pat. No. HK0940329; Republic

of Singapore Pat. No. 51383; Euro.Pat. No. 0 842

463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE,

GB; and additional patents are pending worldwide.

Java and all Java based trademarks and logos are

trademarks or registered trademarks of Sun

Microsystems, Inc. in the U.S. and other countries.

End-user license agreement for Sun™ Java™

J2ME™.

This is the Internet version of the user's guide. © Print only for private use.

Contents 3

1. Restrictions: Software is confidential copyrighted

information of Sun and title to all copies is retained by

Sun and/or its licensors. Customer shall not modify,

decompile, disassemble, decrypt, extract, or

otherwise reverse engineer Software. Software may

not be leased, assigned, or sublicensed, in whole or

in part.

2. Export Regulations: Software, including technical

data, is subject to U.S. export control laws, including

the U.S. Export Administration Act and its associated

regulations, and may be subject to export or import

regulations in other countries. Customer agrees to

comply strictly with all such regulations and

acknowledges that it has the responsibility to obtain

licenses to export, re-export, or import Software.

Software may not be downloaded, or otherwise

exported or re-exported (i) into, or to a national or

resident of, Cuba, Irak, Iran, North Korea, Libya,

Sudan, Syria (as such listing may be revised from

time to time) or any country to which the U.S. has

embargoed goods; or (ii) to anyone on the U.S.

Treasury Department's list of Specially Designated

Nations or the U.S. Commerce Department's Table of

Denial Orders.

3. Restricted Rights: Use, duplication or disclosure by

the United States government is subject to the

restrictions as set forth in the Rights in Technical Data

and Computer Software Clauses in DFARS 252.227-

7013(c) (1) (ii) and FAR 52.227-19(c) (2) as

applicable.

SyncML initiative Ltd. (1999-2002). All rights

reserved.

Other product and company names mentioned herein

may be the trademarks of their respective owners.

Any rights not expressly granted herein are reserved.

This is the Internet version of the user's guide. © Print only for private use.

4 Getting to know your phone

Getting to know your phone

About this user’s guide

The “Getting to know your phone” chapter gives a

quick overview of the main functions of the phone,

shortcuts and general information.

More information and software downloads are

available at www.SonyEricsson.com/.

Available services

Some services and functions described in this user’s

guide are network or subscription-dependent, which

means that all menus may not be available in your

phone.

This symbol indicates that a service

or function is network or subscription-

dependent.

Please consult your network operator for

more information about your subscription.

Assembly

Before you can use your phone you need to:

• Insert the SIM card.

• Attach and charge the battery. See “SIM card and

battery information” on page 5.

Note: Always turn off the phone and detach the

charger before you insert or remove a SIM card.

The SIM card

When you register as a subscriber with a network

operator, you get a SIM (Subscriber Identity Module)

card. The SIM card contains a computer chip that

keeps track of your phone number, the services

included in your subscription, and your Phonebook

information, among other things.

Tip: Check if your information is saved to the SIM

card before you remove it from another phone. For

example, Phonebook entries may be saved in the

phone memory.

This is the Internet version of the user's guide. © Print only for private use.

Getting to know your phone 5

SIM card and battery information

It may take up to 30 minutes before an icon

appears when charging.

1. Insert the SIM card. Slide the silvery holder over the

SIM card to lock it in place.

2. Place the battery on the back of the phone with the

connectors facing each other.

3. Place the back cover as shown in the picture and

slide it into place.

4. Connect the charger to the phone at the flash symbol.

The flash symbol on the charger plug must face

upwards.

5. It may take up to 30 minutes before the battery

charging icon appears in the display.

6. Wait approximately 4 hours or until the icon indicates

that the battery is fully charged. If you do not see the

battery icon after this time, press any key or the joystick

to activate the display.

7. Remove the charger by tilting the plug upwards.

Note: You have to insert the SIM card and charge

the battery before you can use the phone.

30 min.

4 h.

This is the Internet version of the user's guide. © Print only for private use.

6 Getting to know your phone

Turning the phone on

To turn on the phone

Press the on/off button on the top of the phone.

Note: The first time you turn on the phone it takes up

to 40 seconds to begin operating.

• Enter your PIN (Personal Identity Number), if you

have one for your SIM card.

Your PIN is provided by your network operator.

If you make a mistake while entering your PIN,

delete the wrong number by pressing .

If your PIN starts with the same digits as an emergency

number, for example 112, the digits are not hidden with

an * when you enter them. This is so that you can see

and call an emergency number without entering a PIN.

See “Making emergency calls” on page 24.

Note: If you enter the wrong PIN three times in a

row, the SIM card is blocked and the message PIN

blocked appears. To unblock it, you need to enter

your PUK (Personal Unblocking Key). Your PUK

is provided by your network operator.

To turn off the phone

Press and hold the on/off button at the top of the phone.

on/off

Wel

This is the Internet version of the user's guide. © Print only for private use.

Getting to know your phone 7

Navigating the menus

The main menus are shown as icons on the desktop.

To go to the desktop, press the joystick.

Example

To set an alarm

1. Use the joystick to scroll to Organizer, and press the

left key to select it.

2. Use the joystick to scroll down to Alarms, and press

the left key to select this function. Press the left

key again to select Alarm.

3. Enter the time and press the left key to save

your entry.

Throughout this user’s guide instructions such as

those above will be given in a shorter form, as follows:

To set an alarm

1. Scroll to Organizer, Alarms, Alarm.

2. Enter the time, Save.

To make and receive calls from standby

• Enter the area code and phone number, press Call.

• Press End call to end the call.

• When the phone rings, press Yes to answer the call.

Desktop

Press to go back

one level in the

menus.

Press and hold to

return to standby.

Press to go to

the desktop.

Move up,

down, left,

right through

menus.

Press to select

highlighted

items.

Press to select

the options shown

above these keys in

the display.

This is the Internet version of the user's guide. © Print only for private use.

8 Getting to know your phone

Key functions

Press once to activate camera

function. Press again to take

a picture.

Volume keys increase/decrease

the earpiece volume during a

call. Enter the Status menu in

standby. Press twice to reject

an incoming call. Press once

to turn off the ring signal

when receiving a call.

Press to select the options

that appear in the display

immediately above these keys.

Press once to go back one level

in the menus. Press and hold to

return to standby.

Enter *. Shift between

lower upper case.

Infrared port.

Press and hold to switch the

phone on or off.

Press to go directly

to Vodafone live!

Move through the menus,

lists and texts.

Delete numbers, letters or

an item from a list. Press

and hold to turn off the

microphone (during calls)

or turn off sound.

1-9, 0 Enter digits, 0–9, and letters.

Press and hold to enter

the international prefix +.

Enter # or a space.

Press to go directly to

Vodafone live!

This is the Internet version of the user's guide. © Print only for private use.

Getting to know your phone 9

Quick keys

Useful key combinations are described below.

To... When in standby:

make an emergency call enter the emergency

number and press Call

enter Call contact press

enter Favourites press

voice dial press and hold a volume

key or say your magic word

enter Call list press Calls

call your voice mail press and hold

enter the +sign press and hold

turn off the ring signal

when receiving a call press , or press a

volume key once

set the phone to silent press , Turn on silent

reach a contact beginning

with a specific letter press and hold any of

the keys -

reach a phone number

at a specific position. press the position number

and

speed dial press any of the number

keys - and

Call

write a new text message press

enter the main menu press or press the

centre of the joystick

enter the menu to see

today’s date, the profile

in use and the model

name of the phone

press a volume key once

change the language

to Automatic

press 8888

change the language

to English press 0000

reject a call quickly press a volume key

twice when receiving a call

or press No

To... During a call:

put a call on hold press Hold

retrieve a call press Retrieve

turn off the microphone press and hold

enter a quick options menu press More

To... When in the menus:

move through menus or lists press (and hold) a volume

key or use the joystick

delete an item press and hold

when in lists

go back to standby press and hold

To... When in standby:

This is the Internet version of the user's guide. © Print only for private use.

10 Getting to know your phone

To... When entering letters

using multitap text input:

reach the second letter

or character of a key press the volume

key and press any of

the number keys

reach the third letter

or character of a key press the volume

key and press any of

the number keys

shift between capital

and lower-case letters press , then the letter

enter numbers press and hold any of the

number keys

enter a space press

delete letters and numbers press

shift between multitap

or T9 Text input methods press and hold

shift between input

languages (including

character or numeric)

press and hold

To... When entering letters

using T9 Text Input:

view alternative words press or

accept a word and add

aspace press

enter a full stop press

shift between capital

and lower-case letters press , then the letter

enter numbers press and hold any of the

number keys

delete letters and numbers press

shift between multitap or

T9 Text input methods press and hold

shift between input

languages (including

character or numeric)

press and hold

To... When entering letters

using T9 Text Input:

Table of contents

Other Sony Ericsson Cell Phone manuals

Sony Ericsson

Sony Ericsson S312 User manual

Sony Ericsson

Sony Ericsson K500i User manual

Sony Ericsson

Sony Ericsson T610 User manual

Sony Ericsson

Sony Ericsson K770 User manual

Sony Ericsson

Sony Ericsson Naite Quick reference guide

Sony Ericsson

Sony Ericsson K800i User manual

Sony Ericsson

Sony Ericsson C903U Cyber-shot User manual

Sony Ericsson

Sony Ericsson W910 User manual

Sony Ericsson

Sony Ericsson P1c User manual

Sony Ericsson

Sony Ericsson T68ie Quick reference guide

Sony Ericsson

Sony Ericsson J108i Service manual

Sony Ericsson

Sony Ericsson T658 User manual

Sony Ericsson

Sony Ericsson T637 User manual

Sony Ericsson

Sony Ericsson FOMA SO905iCS User manual

Sony Ericsson

Sony Ericsson K530i User manual

Sony Ericsson

Sony Ericsson W660 User manual

Sony Ericsson

Sony Ericsson W205a Walkman User manual

Sony Ericsson

Sony Ericsson T707 User manual

Sony Ericsson

Sony Ericsson P910i User manual

Sony Ericsson

Sony Ericsson K770 User manual

Sony Ericsson

Sony Ericsson K310i User manual

Sony Ericsson

Sony Ericsson Cyber-Shot K770 Owner's manual

Sony Ericsson

Sony Ericsson Xperia Mini Pro User manual

Sony Ericsson

Sony Ericsson Walkman W600I User manual

Popular Cell Phone manuals by other brands

Zte

Zte BLADE A520 quick start guide

Nokia

Nokia Lumia 620 user guide

Blackbe;rry

Blackbe;rry KEYone Safety and product information

Bea-fon

Bea-fon X5 Premium quick guide

Blackbe;rry

Blackbe;rry 8707 Series user guide

Blackbe;rry

Blackbe;rry Storm Troubleshooting

LG LM-X420QN user guide

LifeWatch

LifeWatch V user guide

Bea-fon

Bea-fon SILVER LINE SL860 user guide

IKI Mobile

IKI Mobile KF4.5i user manual

Hitech

Hitech HT-850 user guide

Yezz

Yezz Fashion F10 user manual

Point Mobile

Point Mobile PM60 user manual

Blackbe;rry

Blackbe;rry Q10 user guide

Blackbe;rry

Blackbe;rry Bold 9900 user guide

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 user guide

LG LM-K420EMW user guide

ISAFE MOBILE

ISAFE MOBILE IS655.2 operating manual
