Sonim XP STRIKE Specification sheet
Get
Started
All you need to know to get going.
Thanks for choosing Sprint. This booklet introduces you to the
basics of getting started with Sprint and your Sonim XP STRIKE IS.
ReadyNow – For more help in getting up and running with your
new phone, take advantage of exclusive Ready Now resources
at sprint.com/readynow. You can even schedule a one-on-one
appointment at a Sprint Store near you.
For ongoing support and resources, visit sprint.com/support.
There, you’ll find guides, tutorials, and more to help you get the
most out of your phone.
Note: Available applications and services are subject to change at any time.
Using This Guide
Get Ready − page 1 − Find out
what you need to do before you use
your phone the first time, including
inserting the battery and activating
Sprint service on your phone.
Use Your Phone − page 3 − Take
advantage of your phone’s features
and Sprint services, from the basics
(making calls) to the more advanced
(pairing with Bluetooth devices).
Get the Most Out of Sprint Direct
Connect − page 10 − Learn the basics
of using Sprint Direct Connect, which
lets you connect to other Sprint Direct
Connect users with the push of a button.
Tools & Resources − page 15 − Find
useful tips for your phone and discover
resources and other helpful Sprint
information. For additional information
including the full User Guide, videos,
tutorials, and community forums, visit
sprint.com/support.
Using This Guide
This Get Started guide is designed to help you set up and use your new
Sonim XP STRIKE IS. It’s divided into four sections to help you find the
information you need quickly and easily.
Your Sonim XP STRIKE IS
Earpiece
Navigation arrows
Talk/Call Key
Menu Key
Clear Key
Keypad
Left Selection Key
Right
Selection
Key
Back Key
Power/End
call Key
Loudspeaker
Charger/
Accessory Jack
Battery
cover
screws
Battery &
battery
cover
Torch button
QChat/
Direct
Connect
button
Volume
buttons
Torch
Headset Port
Get Ready
visit sprint.com/readynow for more information to get your phone up and running 1
Install the Battery
1. Insert the battery and push it into the battery
compartment (in the back of the phone) such
that the three metallic contacts at the bottom of
the battery are aligned with the metallic
contacts within the battery compartment.
2. Using the screwdriver provided, rotate the
battery cover screws in clockwise direction.
Ensure not to over tighten the screws.
Charge the Battery
1. Insert the charger plug into a power outlet.
2. The charger port is located on the left side of
the phone. To access the charger port, lift the
cover with the USB sign. Insert the 3.5mm jack/
connector of the charger into the port.
IMPORTANT: Charge the battery for a minimum
of 4 hours before initial use.
Turn the Phone On
►Press and hold to switch ON your phone.
Turn the Phone Off
►Press and hold to switch OFF your phone.
Get Your Phone Ready
Before you start: Visit sprint.com/readynow to
learn about transferring contacts, calendars,
and more from your old phone.
2
Activate Your Phone
If you purchased your phone at a Sprint
Store, it is probably activated and ready
to use.
If you received your phone in the mail,
and it is a new Sprint account or a new
phone number, your phone is designed
to activate automatically when you first
turn it on. You will see a Contacting
Network screen at startup. Follow the
onscreen instructions to continue. To
confirm your activation, make a
phone call.
Activate Your Phone
If you received your phone in the mail
and it is going to be activated on an
existing number (you’re swapping
phones), go to sprint.com/activate and
follow the instructions. When you have
finished, make a phone call to confirm
your activation.
When you have finished, if your phone is still not
activated or you do not have access to the
Internet, contact Sprint Customer Service at
1-888-211-4727 for assistance.
Use Your Phone
visit sprint.com/support for guides, tutorials and more 3
Set Up Your Voicemail
All unanswered calls are automatically transferred
to your voicemail, even if your phone is in use or
turned off. You should set up your voicemail and
personal greeting as soon as your phone is
activated:
1. Press and hold from standby mode.
2. Follow the voice prompts to create your
password and record your name and greeting.
Sprint strongly recommends setting a voicemail
password. Without a password, anyone who has
access to your phone can access your
messages.
Retrieve Your Voicemail
►Press and hold from standby mode.
From any other phone:
1. Dial your wireless phone number.
2. When your voicemail answers, press *.
Use Your Phone: Voicemail
4
Make a Phone Call
1. Enter a number from standby mode. You can
press to delete one or more digits.
2. Press to call the number you entered.
3. Press when you are finished.
Answer an Incoming Call
►Press to answer an incoming call.
In-Call Options
Pressing Options (left selection key) during a call
displays a list of available in-call features. To select
a specific option, highlight the option and press
Select (Menu key ).
• Loudspeaker/Handset to route the sound
to the loudspeaker or earpiece.
• New call to start a new call.
• End call to end the current call.
• Send touch tones to send your touch tones
to the other caller.
• Phonebook to access your contacts.
• Menu to access the phone’s main menu while
remaining in the call.
Phone Calls
Use Your Phone
visit sprint.com/support for guides, tutorials and more 5
View Contacts
1. Press Contacts (right selection key) > All
Contacts from the standby screen.
2. Use the navigation key to scroll through the list
to view your contacts.
Add a New Contact
1. From standby mode, press Contacts (right
selection key) > All Contacts > Options (left
selection key) > Add new contact.
2. Enter your contact’s details.
3. Press Save (Menu key ) to save your
changes.
Edit Contacts
1. From standby mode, press Contacts (right
selection key).
2. Highlight the entry you want to edit and press
Options (left selection key) > Edit Contact.
3. Add or edit the information.
4. Press Save (Menu key ) to save your
changes.
Delete a Contacts Entry
1. From standby mode, press Contacts (right
selection key)
> All Contacts
.
2. Highlight an entry you want to delete.
3. Press Options (left selection key) > Delete
contact.
4. Press Yes (Menu key ).
Contacts
6
Messages
Send a Message
1. From standby mode, press Menu (left selection
key) > Messaging.
2. Select Text message or Multimedia message.
3. Select Write message.
4. Enter your desired recipient in the To field. Press
Add (Menu key ) to select a contact from your
contacts list to add as a recipient.
5. If you selected Multimedia message, navigate
down to highlight the Subject field and enter the
subject line of your message.
6. Navigate down to highlight the Message field
and enter your message.
7. If you selected Multimedia message and wish
to add an attachment, press Options (left
selection key) > Add object > [Image / Video /
Sounds / Attachments / Slide] and choose an
object to attach to the message.
8. When finished, press Send (Menu key ) to
send your message.
Read a Message
►When you receive a message, your phone will
display a notification message. Press the Menu
key to view it. You can also find it in your
message inbox. To navigate to your message
inbox, from standby mode press Menu (left
selection key) > Messaging > Select the
message type > Inbox.
