Smeg P755SB User manual
25
Contents
THESE INSTRUCTIONS ARE VALID ONLY FOR THE DESTINATION COUNTRIES
WHOSE IDENTIFYING SYMBOLS ARE INCLUDED ON THE COVER OF THIS
MANUAL. THIS IS A CLASS 3 BUILT-IN HOB.
INSTRUCTIONS FOR THE USER: these contain user advice, the description
of the controls and the correct procedures for cleaning and maintenance of
the appliance.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified
technician who must install the appliance, set it functioning and carry out
an inspection test.
1. INSTRUCTIONS FOR USE .............................................................. 26
2. SAFETY PRECAUTIONS ................................................................. 28
3. ENVIRONMENTAL RESPONSIBILITY............................................. 30
4. DESCRIPTION OF CONTROLS ...................................................... 31
5. USING THE HOB.............................................................................. 32
6. CLEANING AND MAINTENANCE.................................................... 36
7. POSITIONING IN THE COUNTER TOP .......................................... 38
8. ELECTRICAL CONNECTION........................................................... 40
9. GAS CONNECTION ......................................................................... 41
10. ADAPTATION TO DIFFERENT TYPES OF GAS ........................... 43
General instructions
26
1. INSTRUCTIONS FOR USE
THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. IT MUST BE KEPT IN ITS
ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF
THE HOB. WE ADVISE YOU TO READ THIS MANUAL AND ALL THE INFORMATION IT
CONTAINS CAREFULLY BEFORE USING THE HOB. ALSO KEEP THE SERIES OF
NOZZLES PROVIDED. INSTALLATION MUST BE CARRIED OUT BY QUALIFIED
PERSONNEL IN ACCORDANCE WITH THE REGULATIONS IN FORCE. THIS
APPLIANCE IS INTENDED FOR HOUSEHOLD USE AND COMPLIES WITH THE EEC
DIRECTIVES CURRENTLY IN FORCE. THE APPLIANCE HAS BEEN BUILT TO CARRY
OUT THE FOLLOWING FUNCTION: COOKING AND HEATING FOODS; ALL OTHER
USES ARE TO BE CONSIDERED IMPROPER.
THE MANUFACTURER CANNOT BE HELD LIABLE FOR USE OTHER THAN AS
INDICATED.
IF THE APPLIANCE IS INSTALLED ON BOATS OR IN CARAVANS, DO NOT USE IT AS
A ROOM HEATER.
DO NOT USE THIS APPLIANCE FOR HEATING ROOMS.
THIS APPLIANCE IS MARKED ACCORDING TO EUROPEAN DIRECTIVE 2002/96/EC
ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE).
THIS DIRECTIVE DETERMINES THE STANDARDS FOR THE COLLECTION AND
RECYCLING OF WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT APPLICABLE
THROUGHOUT THE EUROPEAN UNION.
BEFORE THE APPLIANCE IS PUT INTO OPERATION, ALL PROTECTIVE FILMS
MUST BE REMOVED.
SUITABLE HEAT-PROOF GLOVES SHOULD BE WORN FOR ALL OPERATIONS.
DO NOT USE STEEL SPONGES AND SHARP SCRAPERS AS THEY WILL
DAMAGE THE SURFACE.
USE NORMAL NON-ABRASIVE PRODUCTS, INCLUDING WOODEN OR
PLASTIC UTENSILS IF NECESSARY. RINSE THOROUGHLY AND DRY
USING A SOFT CLOTH OR A MICROFIBRE CLOTH.
DO NOT LEAVE THE APPLIANCE UNATTENDED DURING COOKING OPERATIONS
WHERE FATS OR OILS COULD BE RELEASED.
FATS AND OILS MAY CATCH FIRE.
General instructions
27
ALWAYS CHECK THAT THE CONTROL KNOBS ARE IN THE (OFF) POSITION
WHEN YOU FINISH USING THE HOB.
NEVER PLACE PANS WITH BOTTOMS WHICH ARE NOT PERFECTLY FLAT AND
SMOOTH ON THE COOKING HOB RACKS.
NEVER USE CONTAINERS WHICH PROJECT BEYOND THE OUTSIDE EDGE OF THE
HOB.
General instructions
28
2. SAFETY PRECAUTIONS
REFER TO THE INSTALLATION INSTRUCTIONS FOR THE SAFETY REGULATIONS
FOR ELECTRIC OR GAS APPLIANCES AND VENTILATION FUNCTIONS.
IN YOUR INTERESTS AND FOR YOUR SAFETY IT HAS BEEN ESTABLISHED BY LAW
THAT THE INSTALLATION AND SERVICING OF ALL ELECTRICAL APPLIANCES IS TO
BE CARRIED OUT BY QUALIFIED PERSONNEL IN ACCORDANCE WITH THE
REGULATIONS IN FORCE.
OUR APPROVED INSTALLERS GUARANTEE A SATISFACTORY JOB.
GAS OR ELECTRICAL APPLIANCES MUST ALWAYS BE DISCONNECTED BY
SUITABLY SKILLED PEOPLE.
BEFORE CONNECTING THE APPLIANCE TO THE POWER GRID, CHECK THE DATA
ON THE PLATE AGAINST THE DATA FOR THE GRID ITSELF.
THE IDENTIFICATION PLATE CONTAINING THE TECHNICAL DATA, SERIAL NUMBER
AND BRAND NAME IS IN A VISIBLE POSITION UNDER THE CASING.
DO NOT REMOVE THE PLATE ON THE CASING FOR ANY REASON.
BEFORE CONNECTING THE APPLIANCE, ENSURE THAT IT IS SET TO THE TYPE
OF GAS THAT IT WILL BE SUPPLIED WITH, CHECKING THE LABEL APPLIED UNDER
THE CASING.
BEFORE CARRYING OUT INSTALLATION/MAINTENANCE WORK, MAKE SURE THAT
THE APPLIANCE IS NOT CONNECTED TO THE POWER GRID.
THE PLUG TO BE CONNECTED TO THE POWER SUPPLY CABLE AND ITS SOCKET
MUST BE OF THE SAME TYPE AND CONFORM TO THE REGULATIONS IN FORCE.
THE SOCKET MUST BE ACCESSIBLE AFTER THE APPLIANCE HAS BEEN BUILT IN.
NEVER DISCONNECT THE PLUG BY PULLING ON THE CABLE.
IF THE POWER SUPPLY CABLE IS DAMAGED, CONTACT THE TECHNICAL
SUPPORT SERVICE IMMEDIATELY AND THEY WILL REPLACE IT.
IT IS OBLIGATORY FOR ALL ELECTRICAL EQUIPMENT TO BE EARTHED
ACCORDING TO THE METHODS LAID DOWN BY SAFETY REGULATIONS.
IMMEDIATELY AFTER INSTALLATION, CARRY OUT A BRIEF INSPECTION TEST,
FOLLOWING THE INSTRUCTIONS BELOW. SHOULD THE APPLIANCE NOT
FUNCTION, DISCONNECT IT FROM THE POWER SUPPLY AND CALL THE NEAREST
TECHNICAL SUPPORT CENTRE.
NEVER ATTEMPT TO REPAIR THE APPLIANCE.
DURING USE THE APPLIANCE BECOMES VERY HOT. TAKE CARE NOT TO TOUCH
THE HEATING ELEMENTS.
THE USE OF THIS APPLIANCE IS NOT PERMITTED TO PEOPLE (INCLUDING
CHILDREN) OF REDUCED PHYSICAL AND MENTAL ABILITY, OR LACKING IN
EXPERIENCE IN THE USE OF ELECTRICAL APPLIANCES, UNLESS THEY ARE
SUPERVISED OR INSTRUCTED BY ADULTS OR PEOPLE RESPONSIBLE FOR THEIR
SAFETY.
General instructions
29
DO NOT LET CHILDREN GO NEAR THE APPLIANCE WHEN IT IS IN OPERATION OR
PLAY WITH IT AT ANY TIME.
DO NOT INSERT POINTED METAL OBJECTS (CUTLERY OR UTENSILS) INTO THE
SLITS IN THE APPLIANCE.
DO NOT USE STEAM JETS FOR CLEANING THE APPLIANCE.
THE STEAM COULD REACH THE ELECTRONICS, DAMAGING THEM AND CAUSING
SHORT-CIRCUITS.
DO NOT MODIFY THIS APPLIANCE.
DO NOT SPRAY ANY SPRAY PRODUCTS NEAR THE ELECTRICAL APPLIANCE
WHILE IT IS IN OPERATION.
DO NOT USE SPRAY PRODUCTS WHILE THE PRODUCT IS STILL HOT.
The manufacturer declines all responsibility for damage to persons or things
caused by non-observance of the above prescriptions or by interference with any
part of the appliance or by the use of non-original spare parts.
Instructions for disposal
30
3. ENVIRONMENTAL RESPONSIBILITY
3.1 Our environmental responsibility
Pursuant to Directives 2002/95/EC, 2002/96/EC and 2003/108/EC relating to
the reduction of the use of hazardous substances in electrical and electronic
appliances, as well as to the disposal of refuse, the crossed out bin symbol on
the appliance indicates that the product, at the end of its useful life, must be
collected separately from other refuse. Therefore, the user must consign the
product that has reached the end of its working life to the appropriate selective
collection centres for electrical and electronic refuse, or deliver it back to the
retailer when purchasing an equivalent product, on a one for one basis.
Adequate differentiated collection for the subsequent forwarding of the
decommissioned product to recycling, processing and ecologically compatible
disposal contributes to avoiding possible negative effects on the environment
and on health, and promotes recycling of the appliance's constituent materials.
The illicit disposal of the product by the user results in the application of
administrative sanctions.
The product does not contain substances in quantities sufficient to be
considered hazardous to health and the environment, in accordance with
current European directives.
3.2 Your environmental responsibility
Our product's packaging is made of non-polluting materials, therefore
compatible with the environment and recyclable. Please help by disposing of the
packaging correctly. You can obtain the addresses of collection, recycling and
disposal centres from your retailer or from the competent local organisations.
Do not discard the packaging or any part of it, or leave it unattended. It can
constitute a suffocation hazard for children, especially the plastic bags.
Your old appliance also needs to be disposed of correctly.
Important: hand over your appliance to the local agency authorised for the
collection of household appliances no longer in use. Correct disposal enables
intelligent recovery of valuable materials.
Before disposing of your appliance it is important to remove doors and leave
shelves in the same position as for use, to ensure that children cannot
accidentally become trapped inside during play. It is also necessary to cut the
connecting cable to the power supply, removing it along with the plug.
Instructions for the user
31
4. DESCRIPTION OF CONTROLS
4.1 Control zone
All the hob controls are grouped together at the centre front.
CONTROL ZONE
KNOB DESCRIPTION
To light the flame, press the knob and, at the same time, turn it
anticlockwise to the maximum flame symbol .
To adjust the flame, turn the knob to the zone between the
maximum and minimum settings.
To turn off the burner, turn the knob to the zero position to the
symbol.
Instructions for the user
32
5. USING THE HOB
Make sure that the burners, flame-spreader crowns and
racks are fitted correctly.
The notches Aof the flame-spreader crowns must be
inserted into the housings Bof the burner. The igniter
and thermocouple on the hob should fit into the 2 holes
on the burner.
5.1 Positioning the racks
The racks are provided unassembled on the hob. To position each rack correctly
on its burner, follow the instructions below:
Each rack must be positioned on the corresponding burner in order to guarantee
proper operation. Be very careful to match the different central diameters of the
racks to the flame-spreader crowns.
Instructions for the user
33
All the racks have two reference notches (A).
To position the racks correctly, align the reference notches (A) with the cavities
(B) on the hob.
After positioning, check that the rack feet are all resting on the same level.
Make sure that the racks are simply centred on their respective burners,
without forcing the burners to be raised or tilted. If they are, repeat the
positioning procedure.
INCORRECT INCORRECT CORRECT
Instructions for the user
34
5.2 Lighting the burners using a safety device
The appliance is equipped with electronic ignition. Simply press the knob and
simultaneously turn it anticlockwise to the minimum flame symbol , until it
lights. Hold down the knob for about 2 seconds to keep the flame lit and to
activate the safety device. The burner may go out when the knob is released. If
this happens, repeat the procedure, holding the knob down for longer.
If the burners should go out accidentally, after about 20 seconds a safety device
will be tripped, cutting off the gas supply, even if the gas tap is open.
5.3 Practical tips for using the burners
For better burner performance and minimum gas
consumption, pans with flat, even bases and with lids should
be used, and their size should be in proportion to the burner
(see “5.4 Pan diameters”).
During cooking, in order to avoid burns or damage to the hob
top, all pans or griddles must be positioned inside the outer
edge of the hob and at a minimum distance of 5-7 cm must be
maintained from the knobs.
If the burner flame accidentally goes out, turn off the control
knob and wait at least 1 minute before trying to re-light the
burner.
This manual suits for next models
5
Table of contents
Other Smeg Hob manuals
Smeg
Smeg SE97CXG User manual
Smeg
Smeg SE232TD1 User manual
Smeg
Smeg HOBD472D User manual
Smeg
Smeg SE644ID User manual
Smeg
Smeg SI0644X User manual
Smeg
Smeg CBE66MF User manual
Smeg
Smeg SI1M4854D User manual
Smeg
Smeg Glass Ceramic Induction Hob 225678 N71 Instruction Manual
Smeg
Smeg SIM562D User manual
Smeg
Smeg SI1F7635B User manual
Smeg
Smeg SE2320ID1 User manual
Smeg
Smeg P1752XBN User manual
Smeg
Smeg SR 864 OGH User manual
Smeg
Smeg PTS727 User manual
Smeg
Smeg Hob Instruction Manual
Smeg
Smeg SE035 Technical manual
Smeg
Smeg PTV64ES User manual
Smeg
Smeg Dual Fuel Range Cooker A3A-5 User manual
Smeg
Smeg P755AB1 User manual
Smeg
Smeg SE2320ID User manual
