SMC Networks EZ Switch SMCFS26 User manual

OVERVIEW

This EZSwitch™ standalone ethernet switch offers 24 10/100Mbps ports plus 2 10/100/1000Mbps ports.

Designed speciﬁcally for small ofﬁce applications, this switch features auto-negotiation and auto-MDIX

on all ports for easy network expansion and provides full bandwidth capability on each port. With

auto-negotiating 10/100 and 10/100/1000 ports, the speed and duplex modes of attached devices are

instantly detected, allowing the switch to auto conﬁgure for optimal performance.

These switches offer ﬂexibility for any business while ensuring feature-rich and value-added support. Every

port can automatically adjust and link to either a PC or another switch, with no need for crossover cables.

The gigabit ports offer high speed links to local servers or to the rest of the LAN. Rack mounted or on a

desktop, these switches are ideal for any ofﬁce and are great additions to existing network workgroups.

www.smc.com

SMCFS26

EZSwitch™ 10/100 24-Port 10/100 Unmanaged Switch plus 2 10/100/1000 ports

10G FIBER

1G FIBER

10G COPPER

1G COPPER

10/100

PoE

WIRELESS

LEGEND

JD:=J)-

J\im\i

NfibjkXk`fej

APPLICATION DIAGRAM

KEY FEATURES

2 Gigabit Links Sturdy Metal Chassis

With 2 gigabit Ethernet ports, this switch is capable of gigabit

speed server connections.

The sturdy, rack mountable metal chassis is ideal for desktop or

rack mounting applications. In addition, the lack of fans ensures

silent operation.

Auto-MDIX ports LED indicators

No crossover cables required, pure plug and play for easy operation. Simple, at-a-glance LEDs to see port status and for simple trouble-

shooting.

SWITCHES VDSL WIRELESS VOIP STORAGE BROADBAND ADAPTERS

PHYSICAL CHARACTERISTICS

• 24 10/100BASE-T ports

• 2 10/100/1000BASE-T ports

SWITCH FABRIC

• Backplane Capacity: 8.8Gbps

• Forwarding Rate: 6.5Mpps

• Mac Address Table Size: 4K

SIZE

• 17.3x6.8x1.7 In

• 44x17.2x4.3 cm

TEMPERATURE

• Operating: 0 to 45 °C (32 to 113 °F)

• Storage: -40 to 70 °C (-40 to 158 °F)

HUMIDITY

• Operating: 10% to 90% (non-condensing)

AC INPUT

• 100 to 240 V, 50-60 Hz, 0.75A

COMPLIANCES

• CE Mark

• FCC Class A

SAFETY

• IEC 60950-1

WARRANTY

• Please check www.smc.com for the warranty

terms in your country/region

CONTACT

North America

20 Mason

Irvine, CA 92618

1-800-SMC-4YOU

24/7 Technical Support

Europe/Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despí

Barcelona, Spain

Check www.smc.com for your local country

contact information

of SMC Networks in the United States or other countries. Other trademarks

or registered trademarks are the property of their respective owners.

2/2009

www.smc.com

TECH SPECS - SMCFS26

SWITCHES VDSL WIRELESS VOIP STORAGE BROADBAND ADAPTERS
