Smarteh LOC-1 User manual
USER MANUAL
Additional equipment
LOC-1
Occupancy sensor
Version 1
SMARTEH d.o.o. / Poljubinj 114 / 5220 Tolmin / Slovenia / Tel.: +3 6(0) 3 44 00 / e-mail: inf[email protected] / www.smarteh.si
Additional equipment LOC-1
Written by SMARTEH d o o
Copyright © 2016, SMARTEH d o o
User Manual
Document Version: 1
September, 2016
i
Additional equipment LOC-1
STANDARDS AND PROVISIONS: Standards, recommendations,
regulations and provisions of the country in which the devices will
operate, must be considered while planning and setting up electrical
devices Work on 100 230 V AC network is allowed for authorized
personnel only
DANGER WARNINGS: Devices or modules must be protected from
moisture, dirt and damage during transport, storing and operation
WARRANTY CONDITIONS: For all modules LONGO LPC-2 – if no
modifications are performed upon and are correctly connected by
authorized personnel – in consideration of maximum allowed
connecting power, warranty of 24 months is valid from the date of
sale to the end buyer, but not more than 36 months after delivery
from Smarteh In case of claims within warranty time, which are based
on material malfunctions the producer offers free replacement The
method of return of malfunctioned module, together with description,
can be arranged with our authorized representative Warranty does
not include damage due to transport or because of unconsidered
corresponding regulations of the country, where the module is
installed
This device must be connected properly by the provided connection
scheme in this manual Misconnections may result in device damage,
fire or personal injury
Hazardous voltage in the device can cause electric shock and may
result in personal injury or death
NEVER SERVICE THIS PRODUCT YOURSELF!
This device must not be installed in the systems critical for life (e g
medical devices, aircrafts, etc )
If the device is used in a manner not specified by the manufacturer,
the degree of protection provided by the equipment may be impaired
Waste electrical and electronic equipment (WEEE) must be collected
separately!
LONGO LPC-2 complies to the following standards:
•EMC: EN 61000-6-3:2007 + A1:2011, EN 61000-6-1:2007, EN 61000-3-
2:2006 + A1:2009 + A2: 2009, EN 61000-3-3:2013
•LVD: IEC 61010-1:2010 (3rd Ed ), IEC 61010-2-201:2013 (1st Ed )
Smarteh d o o operates a policy of continuous development
Therefore we reserve the right to make changes and improvements to
any of the products described in this manual without any prior notice
MANUFACTURER:
SMARTEH d o o
Poljubinj 114
5220 Tolmin
Slovenia
ii
Additional equipment LOC-1
Additional equipment LOC-1
1 ABBREVIATIONS 1
2 DESCRIPTION 2
3 FEATURES 3
4 INSTALLATION 4
4 1 Connection scheme 4
4 2 Mounting instructions 7
4 3 Module labeling 9
5 TECHNICAL SPECIFICATIONS 10
6 SPARE PARTS 11
7 CHANGES 12
8 NOTES 13
iii
Additional equipment LOC-1
1 ABBREVIATIONS
Sorted by order of appearance in document:
LED Light emitting diode
1
Additional equipment LOC-1
DESCRIPTION
The LOC-1 is a 4 wire occupancy sensor used in combination with the input modules (e g , LPC-2 I16,
LPC-2 DI1, LPC-2 DI5, LPC-2 R01, LPC-2 R02) to detect moving person or object
LOC-1 uses PIR sensor for occupancy sensing and current protected bipolar transistor as a switching
element
2
Additional equipment LOC-1
4 INSTALLATION
4.1 Connection scheme
Figure : Connection scheme with Smarteh modules
Power Supply = 5 32 V AC/DC
Figure 3: Connection scheme with pull-up resistor
Option 1:
+U = 10 32 V DC R = 3 20 kΩ Power Supply = 5 32 V AC/DC
No moving person or object present: voltage drop on sensor > 95 % Vcc
Moving person or object present: voltage drop on sensor < 2 V
Option 2:
+U = 5 V DC R = 1 20 kΩ Power Supply = 5 32 V AC/DC
No moving person or object present: voltage drop on sensor > 4 V
Moving person or object present: voltage drop on sensor < 1 V
2 Smarteh input modules (e g , LPC-2 I16, LPC-2 DI1, LPC-2 DI5, LPC-2 R01, LPC-2 R02)
4
Additional equipment LOC-1
Figure 4: Connection scheme with pull-down resistor
Option 1:
+U = 10 32 V DC R = 3 20 kΩ Power Supply = 5 32 V AC/DC
No moving person or object present: voltage drop on sensor > 95 % Vcc
Moving person or object present: voltage drop on sensor < 2 V
Option 2:
+U = 5 V DC R = 1 20 kΩ Power Supply = 5 32 V AC/DC
No moving person or object present: voltage drop on sensor > 4 V
Moving person or object present: voltage drop on sensor < 1 V
Figure 5: Connection scheme for single or multiple sensors3
3 Maximum allowed number of multiple sensors is 4
5
Additional equipment LOC-1
Figure 6: Connection scheme
Table : Flying lead wires
Yellow 5 32 V AC/DC4Power supply
Brown GND Ground
Green 5 32 V DC (positive) NO voltage free contact
White 0 V DC (negative) NO voltage free contact
Table 3: LEDs
LED1: green No moving person or object
presence indication
ON: no moving person or object present
- voltage free contact opened
OFF: moving person or object present –
voltage free contact closed, power
supply missing or power off
LED2: red Moving person or object
presence indication
ON: moving person or object present -
voltage free contact closed
OFF: no moving person or object present
– voltage free contact opened, power
supply missing or power off
4 In case of 5 10 V DC power supply, use of stabilized power supply is mandatory
