SIRUI A100B User manual
A100B Bi-Color Inflatable Balloon
LED Light
User Manual
SR-PL7 A100B Bi-Color Automatic Inflatable LED Balloon Video Light
The A100B Bi-Color Inflatable Balloon LED Light is a soft continuous light
that is suitable for almost all shooting occasions (portraits, products,
interviews, etc.) with great portability and easy operation.
（1）All-in-one design.
（2）Foldable for easy storage and transport.
（3）Multiple setup solutions.
（4）Soft and even lights.
What's in the Box
Foreword
Features
Light Body*1
Carrying Case*1 Crab Clamp*1Power cable*1
Stand Bracket*1Controller*1
Names of Parts
1
2
3
4
5
6
7
8
9
10
Power Cord
Pump/Vent
Main Body
Metal Ring
Magnet
Power Line Port
Control Line Port
Power Switch
Lanyard
Power Controller
Battery Compartment
11
Fabric Grid
12
1. Adapter Power Supply
Input: 100-240V, 50/60Hz
2. Battery Power Supply
Load a v-mount battery (non-rechargeable) into the battery
compartment.
Power Management
Operation
1. Power On/Off
When powered by the adapter, press the switch to the left (I) to turn
on the light and return the switch to the middle to turn off the light.
When powered by the battery, press the switch to the right (II) to turn
on the light and return the switch to the middle to turn off the light.
Turn on the light to start inflation (make sure the valve is well plugged).
Inflation stops when the light is fully inflated.
Remove the valve plug to deflate the light.
2. Setup Options
3. Mode Selection: Hit the M button to select CCT/FX mode
2.1 Stand adapter: stick the adapter to the magnetic block. You can handheld
the adapter for run-and-gun shooting or insert it into a stand for stable
shots. Press and hold the upper and lower buttons to remove the adapter.
2.2 Magnetic absorption: absorb the light onto metallic surfaces.
2.3 Metal rings: hang the light from different positions.
CCT
100%
2800K
Color Temperature Brightness
3.2 FX Mode
3.2.1 Hit the M button to select FX mode. Press the FN button to adjust
Effect/Speed/Intensity.
3.2.2 Turn the dial to adjust the intensity in at least 1% increments from
0% to 100%.
3.2.3 There are 12 situational special effects for your choice:
FX
100%A
Special Effect Speed Brightness
No.
1
Flash Flash Press
Conference
Discontinuous Frequent Sustainable
Discontinuous Frequent Sustainable
Discontinuous Frequent Sustainable
Discontinuous Frequent Sustainable
Frequent Sustainable
Discontinuous
Brief Continuous Show
Firewood Campfire Fire Hazard
Paparazzi
Slow Medium Quick
Slow Medium Quick
Slow Medium Quick
Slow Medium Quick
Broken Bulb
TV
Candle
Fire
Firework
Impulse
Blast
RGB Cycle
Welding
SOS
2
3
4
5
6
7
8
9
10
11
12
Display DisplayA DisplayB DisplayCSituation
Lightning
3.1 CCT Mode.
3.1.1CCT adjustment: Turn the dial to adjust the CCT in at least 100K
increments from 2800K to 8500K.
3.1.2 Intensity adjustment: Turn the DIM dial to adjust the intensity in
at least 1% increments from 0% to 100%.
5. Installation
5.1 You can mount the light to a stand, attach the light to a metal surface,
or fix the light to a specific position via the metal rings on the back.
5.2 Grid Installation
5.2.1 Unfold the grid and spread it over the light.
5.2.2 Hook the grid to the light via the 4 metal rings.
5.2.3 Make sure the edge of the grid is aligned with the light body.
4. APP Control
4.1 Press and hold the M button to turn on Bluetooth. (Press and hold
the M button again to turn off Bluetooth.)
4.2 Scan the QR code to download the "SIRUI Light" App.
4.3 Turn on Bluetooth on the smartphone and enter the "SIRUI Light"
App. Select the device you want from the list.
For detailed steps, please refer to the APP instruction manual.
Scan the QR code to download
the App.
SIRUI Light
Specifications
15m
APP
-10℃-45℃
96
98
Max 1900lux at 1m
2800K~7000K
Max 100W
Light Body: 1613g, Controller: 1497g
685*500*100mm
A100B
12
Cautions
1. The product should be kept in a cool, dry and ventilated place.
2. Avoid using the light in humid, dusty, overheated environments.
3. Using an unauthorized power adapter can damage the product and void the
warranty.
* Product design and specifications are subject to change without notice.
Model
Size
Weight
Power
Color Temperature Range
Special Effect
100% Illuminance (LUX)
TLCI
CRI
Working Temperature
Control Method
Wireless Bluetooth
Control Distance
Maintenance
1. If there is something wrong with the light when it is working, please turn it
off first.
2. It is normal that the light gets a bit hot when it is working.
3. Maintenance must be performed by the authorized maintenance department
which can provide original accessories.
4. This product, except for consumables, supports a one-year warranty.
5. Unauthorized service will void the warranty.
6. If the product had failures or was wetted, do not use it until it is repaired by
professionals.
7. Changes made to the specifications or designs may not be reflected in this
manual.
思锐A100B 双色温自动充气摄影灯
使用手册
标配物品
前 言
主 要 特 点
双色温自动充气摄影灯A100B是一款柔性发光设计的长亮摄影灯，是针对传统灯光
使用复杂携带不方便的痛点创新设计，能让摄影师在不同场景的使用，携带方便。
适用于静物拍摄、人物拍摄、视频拍摄、直播等场景。
（1）去繁从简，柔性创新体。
（2）可折弯，携带更方便。
（3）多种安装方式，更自由。
（4）光线均匀柔和。
灯体* 1
便携包*1
安装支架*1 控制器*1
蟹钳夹*1电源线*1
