Simrad SimNet Quick start guide

INSTALLATION & USE

Electronics

Flyer Gran Turismo 34 and 38

UNDERSTAND ..................................... Page 4

SimNet

Flyer GT & Simrad

INSTALL ............................................. Page 16

Autopilot

Additional devices

AIS Class-B: NAIS300

Entertainment: SonicHub

Communication: RS82

Radar: Broadband Radar 3G

USE ..................................................... Page 30

dVHF Radio System - RS82

Multifunction Display - NSS8

REPAIR .............................................. Page 42

SimNet Tool - ST10

After Sales Service Process

Web portal

Connections

3-way SimNet joiner

7-way SimNet joiner

SimNet cables - Comes in different lenghts

(0.30 - 2 - 5 - 20 meters)

SimNet power supply cable without termina-

tor (Yellow)

SimNet power supply cable with terminator

(Red)

Terminator

Joiner

AT10 - SimNet / NMEA0183 Converter

SIMNET - NETWORK COMPONENTS

SimNet (Simrad Intelligent Marine Network) a complete intelligent network system

for easy installation and integration of Simrad marine electronics.

• Based on CAN bus / NMEA2000

• Up to 50 products in one system

• Signal rate 250 kbit/sec - 50 times faster than NMEA0183

• Maximum total SimNet cable length: 150 meters.

• Maximum current: 5 Amps

• Automatic source selection

• 2x2 twisted pair (Data pair 0.24 mm2; Power pair 0.5 mm2)

• Thin cables with small 9 mm plugs

• Watertight: IP66

SimNet must be powered with 12 V power supply

SIMNET - NETWORK COMPONENTS

Devices

Device with integrated SimNet

cable. For a shunt in the network

(eg: RC42, RF25) - The cable

must not be lengthened or short-

ened.

Device with one SimNet connec-

tor (eg: NSS). For a shunt in the

network - Use SimNet drop cable

(6 m Max).

Device with two SimNet connec-

tors (eg: IS20 Instruments). For a

series connection in the network

(Daisy Chain) - Use SimNet drop

cable (6 m Max).

Device ﬁtted with a Micro-C con-

nector (eg: DST800, NSS). For a

shunt in the network - Supplied

with an adapter cable SimNet /

Micro-C.

NMEA0183 device (eg: RS25).

For a shunt in the network with the

AT10 converter.

SimNet must be powered with 12 V power supply DC. 12V DC

SIMNET - RULES

To make the SimNet backbone operative it must be termi-

nated at each end (impedance: 60 Ώ). The wind vane is

fitted with an internal terminator.

Do not cut the SimNet cables. The 9 mm diameter connec-

tors are designed to go through the deck.

Bad, or non conform connections will result in network

instability.

12V DC

Max: 6 m

Sensor with integrated cables (eg: compass, rudder)

have a deﬁned length (≈5 m)

They must not be shortened,

or lengthened.

Avoid long drop cables (max 6 m) and multi derivation installations.

Failure to follow these rules will result in network instability.

SIMNET - EXAMPLES

12V DC

Example 1: SimNet with one terminator (or IS20 masthead unit) on each extremity and pow-

ered with SimNet power cable without terminator (yellow).

Example 2: SimNet with one terminator (or IS20 masthead unit) on one extremity and powered

with SimNet power cable with terminator (red) at the other extremity.

Example 3: SimNet with different type connections and "Daisy Chain".

12V DC

Daisy Chain

FLYER GT & SIMRAD - MAIN PACKS

Ambition

Electronic Pack

FLYER GT & SIMRAD - MAIN PACKS

P79

• Depth / Speed

• In hull - Plastic / Frequency 50/200 kHz

• RMS 600 W

NSS8 MFD

• 8” LED multifunction color display with embedded

cartography of Europe

• Integrated Pilot control (optional)

• Ethernet and SimNet

• Compatible with Broadband radar, Broadband

Sonder, Structure Scan, Sonic Hub

SonicHub

• Marine audio server with waterproof dock - SimNet

• Full iPod, iPhone and MP3 compatibility, FM receiver

included

• Dock provides a safe waterproof spot and full opera-

tional control

• Music control for up to 3 individual zones

SG05

• Autopilot Interface for Volvo engine

NAIS300

• Class-B AIS Transponder

Radar 3G

• Broadband Radar

RS82

• dVHF DSC Radio System

FLYER GT 34 & SIMRAD - BACKBONE

Option Auto Pilot IPS

Pack Elect.

136719

SimNet

Multi

BR24 3G

10m

RI10

Option Radar

Ethernet

NAIS

300

Option AIS

RS82

12-24 V

Simrad SG05

Gateway

Autopilot Interface kit

(V olvo Penta part number 3819744)

Autopilot

Gateway

EVC connect point

Y-split

cable

Not Included

128311

136719 128312

Option VHF

12-24 V

128316

136719

Photo 1

Photo 3

Photo 5

7way

SimNet

Joiner

FLYER GT 34 & SIMRAD - BACKBONE

11/3/2010

CREATION

DATE

TITLE Flyer GT34-Schematics

AUTHOR JMB LAST EDIT 10/10/2011VERSION

RC42

128310

Fonction Display Finition 2

NSS-8"

P79

Echo sounder Finition 2

12m

Rem

ote

Marine Audio Server & Dock

Finition 2

136717

12-24 V

12VDC

128312

128314

128316

128313

Photo 4

Photo 2

Photo 5
