Simplicity 1693706 Setup guide

Rev. 6/2000

TP 400-2331-00-AT-SMA

Attachment

Illustrated

Parts List

MANUFACTURING, INC.

500 N Spring Street / PO Box 997

Port Washington, WI 53074-0997 USA

TP-400-2331-00-AT-SMA

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

The above parts group applies to the following Mfg. Nos.:

1693706 54” Turbo

54” Turbo

985714

Use existing

hardware

FRONT

TP-400-2331-00-AT-SMA

REF NO. PART NO. QTY. DESCRIPTION

Footnotes:

The above parts group applies to the following Mfg. Nos.:

1693706 54” Turbo

54” Turbo

1 1927557 8 FLANGE LOCKNUT, 5/16-18

2 1672689 1 S-HOOK

3 1933988 3 PUSH NUT, 5/16-18

4 1706630 1 STRAP

5 1720892 1 HOUSING, With Decal

6 1700259 1 DECAL,Danger

7 1919438 1 NYLOCK NUT, 5/16-18

8 1720932 1 V-BELT

9 1960472 6 SCREW, Truss Head, 1/4-20

10 1921961 1 CAPSCREW, Hex, 1/4-20 x 1-1/4

11 1921319 1 WASHER, 1/4

12 1665982 4 RETAINER, Bearing

13 108202 2 BEARING

14 1931333 5 CARRIAGE BOLT, 5/16-18 x 3/4

15 1706631 1 FAN ASSEMBLY

16 1921332 3 CAPSCREW, Hex Head, 5/16-18 x 3/4

17 1706634 1 PULLEY

18 1960619 1 SET SCREW, Torx, 5/16-18 x 5/16

19 960403 1 KEY, Woodruff

20 1921969 1 CAPSCREW, Hex Head, 3/8-16 x 1-1/2

21 1924940 4 WASHER, 3/8

22 174561 1 PULLEY, Idler

23 1720918 1 COVER

24 1916965 2 LOCKWASHER, 3/8

25 1916950 2 NUT, 3/8-16

26 1923701 1 CAPSCREW, Hex Head, 3/8-16 x 2

27 1666114 1 BUSHING

28 1720934 1 LEVER ASSEMBLY

29 1922755 1 WASHER, 3/8

30 1704419 1 BELT STOP

31 174896 1 SPRING, Extension

32 1720721 1 PLATE & BRACKETS ASSEMBLY

33 1930641 8 LOCKNUT, 1/4-20

34 1930645 1 NUT, Hex, 3/8-16

35 1927429 3 SCREW, Taptite, 1/4-20 x 5/8

36 1720718 2 PILOT PIN, Tapered Spacer

37 1720951 1 ROD & ANCHOR ASSEMBLY, Deflector

38 1720921 3 LOCKING TAB

39 1719590 1 SPRING, Extension

40 1933896 4 LOCKNUT, 10-24

41 1960404 4 SCREW, Truss Head, 10-24 x 3/4

42 1927120 1 CAPSCREW, Hex Head, 7/16-14 x 2-1/4

43 1720737 1 PULLEY & HUB ASSEMBLY

44 1921959 4 CAPSCREW, Hex Head, 1/4-20 x 5/8

45 1720978 1 SPACER, 5/8 x 1

46 1704628 2 PIN, Spring

47 1916964 4 LOCKWASHER, 1/4

48 1916622 4 NUT, Hex, 1/4-20

49 1931320 1 CARRIAGE BOLT, 1/4-20 x 1-1/4

TP-400-2331-00-AT-SMA

54”Turbo

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

985714

The above parts group applies to the following Mfg. Nos.:

1693706 54” Turbo

Use existing

hardware

FRONT

TP-400-2331-00-AT-SMA

54”Turbo

50 1720749 1 SUPPORT PLATE

51 1921719 1 CAPSCREW, Hex Head, 5/16-18 x 2-1/2

52 1929000 2 CAPSCREW, Hex Head, Taptite,1/4-20 X 5/8

53 1700654 1 BRACKET, Belt Cover

54 1720884 1 COVER, Arbor

55 1713588 1 SPACER

56 1917356 1 LOCKWASHER, 5/16

57 1935255 1 PAL NUT, 5/16-18

58 1700669 1 KNOB

59 1917372 1 NUT, Hex, 5/16-18

60 1720920 1 PLATE, Deflector Mounting

61 1921159 1 CAPSCREW, Hex Head, 1/4-20 x 2-1/4

REF NO. PART NO. QTY. DESCRIPTION

Footnotes:

The above parts group applies to the following Mfg. Nos.:

1693706 54” Turbo

Torque Specification Chart

FOR STANDARD MACHINE HARDWARE (Tolerance ± 20%)

Hardware

Grade

SAE Grade 2 SAE Grade 5 SAE Grade 8

Size Of

in/lbs in/lbs

in/lbs

Hardware ft/lbs Nm. ft/lbs Nm. ft/lbs Nm.

8-32

2.1

3.4

4.6

8-36

2.3

3.5

4.9

10-24

3.1

4.9

6.8

10-32

3.5

5.5

7.7

1/4-20

7.6 810.9 12 16.3

1/4-28

8.6 10 13.6 14 19.0

5/16-18 11 15.0 17 23.1 25 34.0

5/16-24 12 16.3 19 25.8 27 34.0

3/8-16 20 27.2 30 40.8 45 61.2

3/8-24 23 31.3 35 47.6 50 68.0

7/16-14 30 40.8 50 68.0 70 95.2

7/16-20 35 47.6 55 74.8 80 108.8

1/2-13 50 68.0 75 102.0 110 149.6

1/2-20 55 74.8 90 122.4 120 163.2

9/16-12 65 88.4 110 149.6 150 204.0

9/16-18 75 102.0 120 163.2 170 231.2

5/8-11 90 122.4 150 204.0 220 299.2

5/8-18 100 136 180 244.8 240 326.4

3/4-10 160 217.6 260 353.6 386 525.0

3/4-16 180 244.8 300 408.0 420 571.2

7/8-9 140 190.4 400 544.0 600 816.0

7/8-14 155 210.8 440 598.4 660 897.6

1-8 220 299.2 580 788.8 900 1,244.0

1-12 240 326.4 640 870.4 1,000 1,360.0

Hex Head Capscrew

Hex Nut

Lockwasher

Washer

Carriage Bolt

NOTES

1. These torque values are to be used for all hardware

excluding: locknuts, self-tapping screws, thread forming

screws, sheet metal screws and socket head setscrews.

2. Recommended seating torque values for locknuts:

a. for prevailing torque locknuts - use 65% of grade 5

torques.

b. for flange whizlock nuts and screws - use 135% of

grade 5 torques.

3. Unless otherwise noted on assembly drawings, all torque

values must meet this specification.

Hardware Identification & Torque Specifications

Common Hardware Types

Screw, 1/2 x 2

Body

Diameter

Body

Length

Inside

Diameter

Nut, 1/2”

Marks

3/8” Bolt or Nut

Wrench—9/16”

3/8

5/16” Bolt or Nut

Wrench—1/2”

5/16

1/4” Bolt or Nut

Wrench—7/16”

1/4

1/2” Bolt or Nut

Wrench—3/4”

1/2

DIA.

7/16

DIA.

7/16” Bolt or Nut

Wrench (Bolt)—5/8”

Wrench (Nut)—11/16”

Wrench & Fastener Size Guide

Standard Hardware Sizing

When a washer or nut is identified as 1/2”, this is the

Nominal size

, meaning the

inside diameter

is 1/2 inch; if a

second number is present it represent the

threads per inch

When bolt or capscrew is identified as 1/2 - 16 x 2”, this

means the

Nominal size

, or

body diameter

is 1/2 inch; the

second number represents the

threads per inch

(16 in this

example, and the final number is the

body length

of the

bolt or screw (in this example 2 inches long).

The guides and ruler furnished below are designed to

help you select the appropriate hardware and tools.

01/4 3/4

1/2 11/4 3/4

1/2 21/4 3/4

1/2 31/4 3/4

1/2 4
