Silvercrest SADH A1 User manual
IAN 359185_2007
AROMA DIFFUSER SADH A1
AROMA DIFFUSER
Operation and safety notes
DUFTSPREDER
Brugs- og sikkerhedsanvisninger
DIFFUSEUR DE BRUME
Instructions d‘utilisation et consignes de
sécurité
AROMA-DIFFUSER
Bedienings- en veiligheidsinstructies
AROMA-DIFFUSER
Bedienungs- und Sicherheitshinweise
IAN 359185_2007
GB/IE/NI Operation and safety notes Page 5
DK Brugs- og sikkerhedsanvisninger Side 22
FR/BE Instructions d‘utilisation et consignes de sécurité Page 38
NL/BE Bedienings- en veiligheidsinstructies Pagina 55
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 72
A
1
2
3
4
5
6
7
HG05382A HG05382B
B
16
4
13
15
11
89
14
10 12
5GB/IE/NI
Warnings and symbols used ...................................Page 6
Introduction ...................................................Page 8
Intended use..................................................Page 8
Scope of delivery..............................................Page 8
Safety instructions.............................................Page 8
Parts description...............................................Page 14
Technical data ................................................Page 15
Before use.....................................................Page 15
Operation.....................................................Page 15
Timer and output control ........................................Page 16
LED control...................................................Page 17
Switching off the product ........................................Page 17
Cleaning and care .............................................Page 17
Descaling ....................................................Page 18
Storage .......................................................Page 18
Troubleshooting ...............................................Page 19
Disposal.......................................................Page 19
Warranty .....................................................Page 20
6 GB/IE/NI
Warnings and symbols used
The following warnings are used in this user manual and on the packaging:
DANGER! This symbol in
combination with the signal
word “Danger” marks a high-risk
hazard that if not prevented
could result in death or serious
injury.
Read the manual.
WARNING! This symbol in
combination with the signal word
“Warning” marks a medium-risk
hazard that if not prevented
could result in death or serious
injury.
Alternating current / voltage
Direct current / voltage
Hertz (supply frequency)
Watt
CAUTION! This symbol in
combination with the signal
word “Caution” marks a low-risk
hazard that if not prevented
could result in minor or moderate
injury.
Ampere (current)
Symbol for a Protection Class II
product.
7GB/IE/NI
ATTENTION! This symbol
with the signal word “Attention”
indicates a possible property
damage.
Use the product in dry indoor
spaces only.
Polarity of the output terminal
Protection against penetration of
solid objects (Ø > 12.5mm)
Highest rated ambient
temperature
NOTE: This symbol in
combination with “Note”
provides additional useful
information.
Short-circuit proof safety
transformer
SMPS (Switch mode power
supply unit) (switching power
supply)
For ESSENTIAL OIL –
LAVENDER:
May cause an allergic skin
reaction. Causes serious eye
irritation.
For ESSENTIAL OIL –
TEATREE:
Causes skin irritation. May cause
an allergic skin reaction.
For ESSENTIAL OIL –
TEATREE:
May be fatal if swallowed and
enters airways.
Tactile hazard symbol for people
with impaired vision.
8 GB/IE/NI
AROMA DIFFUSER
Introduction
We congratulate you on the purchase
of your new product. You have chosen a
high quality product. The instructions for
use are part of the product. They contain
important information concerning safety,
use and disposal. Before using the product,
please familiarise yourself with all of the
safety information and instructions for use.
Only use the product as described and for
the specified applications. If you pass the
product on to anyone else, please ensure
that you also pass on all the documentation
with it.
Intended use
The product is designed for air refreshing
and humidification in enclosed spaces.
Do not use the product for any other
purpose.
The product is only intended for private
household use, not for commercial
purposes.
The manufacturer accepts no liability for
damages caused by improper use.
Scope of delivery
After unpacking the product, check if the
delivery is complete and if all parts are
in good condition. Remove all packing
materials before use.
(Fig. A, B)
1x Aroma diffuser
1x Power adaptor
1x Measuring cup
2x Aroma oil
1x Leaflet for aroma oil
1x Instruction manual
Safety instructions
BEFORE USING THE
PRODUCT, PLEASE
FAMILIARISE YOURSELF
WITH ALL OF THE SAFETY
INFORMATION AND
INSTRUCTIONS FOR USE!
WHEN PASSING THIS
PRODUCT ON TO OTHERS,
PLEASE ALSO INCLUDE ALL
THE DOCUMENTS!
9GB/IE/NI
In the case of damage
resulting from non-compliance
with these operating
instructions the warranty claim
becomes invalid! No liability
is accepted for consequential
damage! In the case of
material damage or personal
injury caused by incorrect
handling or non-compliance
with the safety instructions, no
liability is accepted!
m DANGER TO LIFE AND
RISK OF ACCIDENTS
FOR INFANTS AND
CHILDREN! Never leave
children unsupervised with
the packaging materials.
The packaging material
poses a suffocation
hazard.
Children frequently
underestimate the
dangers.
Always keep children
away from the packaging
material.
¾This product can be used
by children aged from
8 years and above and
persons with reduced
physical, sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the product in a safe
way and understand the
hazards involved.
10 GB/IE/NI
Children shall not play
with the product.
Cleaning and user
maintenance shall not be
made by children without
supervision.
Avoid electric
shock
m WARNING! Keep the
product dry.
m WARNING! If the
product falls into the
water, immediately
disconnect the power
adaptor from the socket
outlet before reaching into
the water.
m WARNING! Never
touch the power adaptor
with moist or wet hands.
m WARNING! Never
submerge the product or
the supply cord with the
power adaptor in water or
any other liquid and never
rinse these under running
water.
¾For additional protection,
the installation of a
residual current device
(RCD) having a rated
residual operating current
not exceeding 30 mA is
advisable in the electrical
circuit supplying the
bathroom. Ask your
installer for advice.
