SIIG CE-H27611-S1 User manual
Features
• Support HDCP 1.3
• Build-in EDID, resolution up to 1080p@60Hz
• HDMI wireless transmission distance up to
656ft/200m. (In an open environment
without Wi-Fi interference.)
• Support one transmitter and multiple
receivers, up to 4 receivers.
• Support one-way IR extend
• Support PCM 2ch audio
• 5G Wireless connectivity
Package contents
1. Wireless HDMI Transmitter
2. Wireless HDMI Receiver
3. Power adapter 12V/1A x2
4. 5G WiFi antenna x4
5. IR Emitter Cable (For TX IR out)
6. IR Receiver Cable (For RX IR in)
7. Quick start guide
Layout
1. DC Power jack:
connect to power adapter
DC 12V/1A
2. Power LED:
3. RESET: Restore factory settings after long
press for 5s, and require to pair again
4. HDMI In: Connect to HDMI source
5. Loop Out: Connect to HDMI display
6. IR Out: Connect to IR Emitter Cable
Transmitter
Receiver
1. DC Power jack:
connect to power adapter
DC 12V/1A
2. Power LED:
3. RESET: Restore factory settings after long
press for 5s, and require to pair again
4. HDMI Out: Connect to HDMI display
5. IR In: Connect to IR Receiver Cable
1 2 3 4 5
6
1 2 3 4
5
Full HD Wireless HDMI
Extender with Loopout & IR Kit
Quick Start Guide
04-1368B P/N: CE-H27611-S1
Support
For more info or tech support
http://www.siig.com/support
Oct, 2022 Copyright © 2022 by SIIG, Inc. All rights reserved.
Dear Valued Customer
WE REALLY
APPRECIATE
YOUR PURCHASE
~thank you~
Pairing Instruction
1. Power on the TX & RX
2. Wait for 30 sec
3. Using an HDMI cable, Connect the TX input
on the Transmitter to the RX output on the
Receiver to be paired.
4. Wait for 10 sec
5. Remove the HDMI cable and power
from the RX and TX
6. Connect RX output into your display and
Connect the TX into your video source
7. Power on the RX & TX.
Application
