Operating instructions RDH100

The RDH100 is a room thermostat that allows you to set the desired room temperature (setpoint)

for the desired time. The unit features an ergonomic setting knob for easy temperature control.

Display

Actual room temperature

in ºC

The unit controls to the

selected comfort

temperature

Indicates when heating is

demanded

Replace batteries

Setting knob

Warmer/colder

knob for

selecting the

temperature

setpoint

Battery compartment

2 alkaline batteries type AA, 1.5 V

Commissioning

∑ Remove the black transit tabs from the 2 alkaline batteries.

Check to see if the battery compartment is in its correct position

∑ If no batteries are inserted, fit 2 alkaline batteries type AA in the

battery compartment

Selecting the required temperature

∑ Turn the setting knob counter-clockwise to decrease the setpoint,

or clockwise to increase the setpoint in increments of 0.5 °C

∑ The required temperature is displayed next to the comfort

temperature symbol

Changing the batteries

1. Get 2 new alkaline batteries type AA, 1.5 V.

2. Within 1 minute: pull out the battery compartment and remove the batteries, insert the new

batteries and replace the battery compartment.

3. Make certain the old batteries are disposed of properly,

in compliance with environmental requirements.

Energy saving tips without sacrificing comfort

∑Never allow room temperatures to exceed 21 C

∑Air out rooms for short periods of time only, but properly,

with the windows wide open

Parameter setting

Parameter setting mode

1. Press RESET on the rear for 5 seconds until “P01” appears.

Note: Pressing the button longer than 10 seconds resets the

thermostat.

2. Press RESET again and the parameter value on second line flashes

and is ready for adjustment.

3. Adjust the parameter using setting knob.

4. Press RESET once to confirm the setting.

5. Rotate the setting knob clockwise to next parameter and repeat steps

2 to 4.

6. Exit the parameter setting mode by rotating the setting knob

clockwise to “End” and pressing the RESET button once.

Parameters:

∑P01 Control behaviour: 2-position 1K / 2-position 0.5 K / PID fast /

PID slow (factory-setting)

∑P02 Maximum temperature range

∑P03 Minimum temperature range

A6V101035984_tr--_c 2018-06-21 Deiiklie tabidir Siemens Building Technologies / HVAC Ürünleri

Kullanma TalimatRDH100

RDH100 cihaz, istediiniz zaman istediiniz oda scaklna (ayar noktas) erimenizi salayan bir oda

termostatdr. Cihaz, scaklk kontrolünün kolaylatrlmas için ergonomik bir ayar dümesine sahiptir.

Gösterge

ºC biriminde gerçek oda scakl

Cihaz, seçilen uygun scakl kontrol

ediyor

Scaklk için ihtiyaç olduunu belirtir

Pilleri deitiriniz

Ayar

dümesi

Scaklk ayar

noktasnn

seçimi için

scak/souk

dümesi

Pil Bölümü

2 alkalin pil tip AA, 1.5 V

letim

∑ 2 alkalin pilden siyah geçi sekmesini çkarn. Pil tutucusunun doru

pozisyonda olup olmadn kontrol ediniz.

∑ Eer piller yerletirilmemi ise, AA tipinde 2 alkalin pili, pil bölümüne

yerletiriniz.

stenen scakln seçilmesi

∑ Ayar noktasn düürmek için ayar dümesini saatin

ters yönünde ya da ayar noktasn 0.5 °C art

aralklar ile arttrmak için ayar dümesini saat

yönünde çeviriniz.

∑ stenilen scaklkkonfor scaklk sembolünün

yannda görüntülenecektir.

Pillerin detirilmesi

1. 2 adet AA tipi, 1.5 V yeni alkalin pil alnz.

2. 1 dakika içerisinde: Pil tutucusunu çkarnz, yeni pilleri yerletiriniz ve pil

tutucusunu yeniden yerine yerletiriniz.

3. Kullanlm olan pillerin, çevresel gereklilikler ile uygun olarak imha edildiinden

emin olunuz.

Konfordan ödün vermeden enerji tasarrufu salama önerileri

∑ Oda scaklnn 21 C’nin üzerinde olmasna izin vermeyiniz.

∑ Yalnz ksa süreler içinde, camlar sonuna kadar açarak havalandrnz.

Parametre ayarlar

Parametre ayar modu

1. Arkadaki RESET dümesine 5 saniye kadar “P01”

gözükene kadar basn

Not: 10 saniye süreden fazla dümeye basarsanz,

termostat kapanp açlr.

2. RESET ‘e yeniden basn, parametre deeri ikinci

satrda yanp sönecektir ve ayarlamaya hazrdr.

3. Parametreyi ayar dümesi ile ayarlayn

4. Ayar sabitlemek için RESET’e bir kez daha basn

5. leriki parametre ayarna geçmek için ayar dümesini

saat yönünde çevirin ve 2. ile 4. Admlar arasn

tekrarlayn

6. Ayar dümesini saa yönünde “End” gözükene kadar

çebirin ve RESET ‘e basarak parametre ayar

modundan çkn.

Parametreler:

∑P01 Kontrol davran: 2-nokta 1K / 2-nokta 0.5 K /

PID hzl / PID yava (fabrika ayar)

∑P02 Maksimum scaklk aral

∑P03 Minimum scaklk aral

A6V10974417_----_c 2018-06-22 Subject to alteration Siemens Building Technologies / HVAC Products

RDH100

2 3

A6V10974417_----_c 2018-06-22 Subject to alteration Siemens Building Technologies / HVAC Products

Lx - Nx AC 24...250 V

Parameter

P01 PID slow ( ) (4)

0 =

, 1.0

1 = 2P, 0.5 K

2 = PID fast ( )

4 = PID slow ( )

P02

Max °C

30 °C P03…30 °C

P03

Min °C

5 °C 5 °C…P02

End Ë Exit
