Siemens 1015N-2MFM-1A User manual

1015N-2MFM-1A

1015N-2M DIAL-UP MODEM

OPTION CARD

FOR SYSTEM 1010N

FLOWMETERS

FIELD MANUAL

FORTECHNICALASSISTANCE

Call:(800) 275-8480

(631)231-3600

Fax:(631)231-3334

E-mail:TSG[email protected]

FORGENERALINFORMATION

Website: www.controlotron.com

E-mail:[email protected]

Or:[email protected]

Field Manual 1015N-2MFM-1A

June 2006

For use with Operating System

Software Version 2.00.15 or later

1015N-2M DIAL-UP MODEM

OPTION CARD

FOR SYSTEM 1010N

FLOWMETERS

This equipment contains components that are

susceptible to electrostatic discharge (ESD).

Please observe ESD control measures during

the handling and connection process.

Printed June 2006

FOR TECHNICAL ASSISTANCE: FOR GENERAL INFORMATION:

Call: (800) 275-8480 Website:www.controlotron.com

(631) 231-3600 E-mail:[email protected]

Fax: (631) 231-3334 Or:[email protected]

E-mail:TSG[email protected]

IMPORTANT NOTICE

Controlotron is now part of:

Siemens Energy &Automation, Inc.

Process Instrumentation Business Unit (PI BU)

CoC Ultrasonic Flow

PreparedBy Date

ReviewedBy Date

Manual Changes

NOTE: For the latest updates and revisions to this field manual go to

www.controlotron.com/downloads.htm and check the Product Manual

listing.

1015N-2MFM-1A

Table Of Contents

1. Introduction ......................................................................................................1

2. 1015N-2M Modem Card Setup ...................................................................... 1

2.1 Option 1 Mounting Kit 1015N-2M-MK1 ...................................................... 1

2.2 Option 2 Mounting Kit 1015N-2M-MK2 ...................................................... 1

2.3 Option 3 Mounting Kit 1015N-2M-MK3 ...................................................... 1

Figure 1. 1015N-2M Modem Card and Attaching Hardware ................ 2

3. Technical Specifications.................................................................................2

4. 1010N Flowmeter System Requirements ..................................................2

5. Preliminary Installation Notes and Cautions ........................................... 2

5.1 1015N-2M Modem Card Installation ........................................................... 2

Module Loading Option 1 ..........................................................................3

Module Loading Option 2 ..........................................................................3

Module Loading Option 3 ..........................................................................3

5.1.1 Option 1 Installation Procedure (Mounting Kit 1015N-2M-MK1) ....... 3

Figure 2. 1010N Flowmeter Access Cover Removal ............................... 3

Figure 3. Option 1 Installation (side view) ............................................. 4

5.1.2 Option 2 Installation Procedure (Mounting Kit 1015N-2M-MK2) ....... 5

Figure 4. Option 2 Installation (side view) ............................................. 6

5.1.3 Option 3 Installation Procedure (Mounting Kit 1015N-2M-MK3) ....... 6

Figure 5. Option 2 Installation (side view) ............................................. 7

5.2 Setting 1010N Flowmeter RS-232 Parameters ......................................... 8

5.3 Telephone Line Connections ........................................................................8

6. Communications Configuration ................................................................... 9

7. Windows HyperTerminalTM Setup ...............................................................9

1015N-2M Reconfiguration Procedure.....................................................9

APPENDICES

Appendix A “AT” Command Set and “S” Registers .............................................. A-1

“AT” Commands .................................................................................. A-2

“S” Registers ........................................................................................ A-4

“AT” Commands and “S” Registers Exclusive to the PE2400 ......... A-5

Dial Modifiers ................................................................................ A-5

Ampersand (AT&) Commands ..................................................... A-6

Percent (AT%) Commands ........................................................... A-6

“S” Registers .................................................................................. A-7

Appendix B Engineering Drawings .......................................................................... B-1

Page

TABLE OF CONTENTS

1015N-2MFM-1A

1015N-2MFM-1 MODEM CARD

INSTALLATION INSTRUCTIONS

1. INTRODUCTION

The 1015N-2M Modem Card is one of three option cards used for remote communications

within the Controlotron 1010N family of flowmeters. External communication is achieved

through an on board dial-up miniature modem with asynchronous line speeds of 2400 bps,

1200 bps, or 300 bps. Implementation of Windows HyperTerminalTM or any other

communication software allows for the direct control of the modem’s Hayes compatible

command set.

2. 1015N-2M MODEM CARD KITS

2.1 OPTION 1 MOUNTING KIT 1015N-2M-MK1

Description Part Number Qty

Cover, Communication Module 1010-436-1 1

Screw, Captive 6-32 x 1/2 4006M07F09 1

Label, Controlotron ID 1010-257 1

Standoff, Threaded, Cover Mount 1010-433-1 1

Standoff, Threaded, PCB Support 1010-434-1 4

Cover, Analog Input Module 1010-379 1

Installation Drawing 1015N-2M-MK-7 1

Installation, Wiring Drawing 1015N-2M-7 1

Insulator, Syscom shield, 1010N 1010-263 1

2.2 OPTION 2 MOUNTING KIT 1015N-2M-MK2

Description Part Number Qty

Cover, I/O Board 1010-446-1 1

Screw, Captive 6-32 x 1/2 4006M07F09 1

Label, Controlotron ID 1010-257 1

Standoff, Cover Mount 1010-447-1 1

Standoff, Threaded, PCB Support 1010-434-1 4

Installation Drawing 1015N-2M-MK-7 1

Installation, Wiring Drawing 1015N-2M-7 1

2.3 OPTION 3 MOUNTING KIT 1015N-2M-MK3

Description Part Number Qty

Cover, I/O Board 1010-446-2 1

Screw, Captive 6-32 x 1/2 4006M07F09 1

Label, Controlotron ID 1010-257 1

Standoff, Cover Mount 1010-447-1 1

Standoff, Threaded, PCB Support 1010-434-1 4

Installation Drawing 1015N-2M-MK-7 1

Installation Drawing 1015N 1

Installation, Wiring Drawing 1015N-2M-7 1

1015N-2MFM-1A

3. TECHNICAL SPECIFICATIONS

Interface: RS-232

Supply Voltage: 5 volts DC

Supply Current: 48 mA

Modem Line Speeds: 2400, 1200 and 300 bps Asynchronous

DTE Rates: 2400, 1200, 300 bps

Modulation: V.22bis, V.22, Bell 212A, Bell 103

Phone Line: Dial Up or 2 Wire Leased Line

Extended Hayes Command Set Compatibility

Error Correction / Error Detection: None

Operating Environment: -40 to 85 degrees C / 0 to 95% Humidity (non-condensing)

4. 1010N FLOWMETER SYSTEM REQUIREMENTS

The System 1010N Flowmeter operating system must be revision level 2.0 or later for the

1015N-2M Modem Card to function properly. In addition, the 1015N-2M Modem Card

requires 1010N system hardware of the following levels in order to work. Refer to the

appropriate 1010N user manual installation/outline drawings for circuit board locations.

a. 1010N-1-5 SysCom Version 3, Revision. D2 or Higher

b. 1010N-2K3 I/O Board A2

c. 1010N-8M-5 I/O Board A3

d. 1010N-7K2 Analog I/O A2

5. PRELIMINARY INSTALLATION NOTES AND CAUTIONS

CAUTION: It is highly recommended that installation be done in a static free

environment or damage to the 1015N-2M Modem Card may result.

NOTE: The 1015N-2M Modem will not function if the 1010 flowmeter RS-232 port is

connected to the serial port of your PC.

NOTE: The 1015N-2M Modem will only transmit and receive data when used with

direct phone line connections (see paragraph 5.3 below for communication

connection options).

Figure 1. 1015N-2M Modem Card and Attaching Hardware

Top View Side View

Module ID Label

Captive

Screws (4)

1015N-2M

Modem Card

TB1 Network Connection

(2-Wire Hook Up)

Con 2 Network Connection

(RJ11 Connector)

1015N-2MFM-1A

Figure 2. 1010N Flowmeter Access Cover Removal

5.1 1015N-2M MODEM CARD INSTALLATION

WARNING: Set flowmeter and instrumentation power to OFF when inserting or

removing the 1015N-2M Modem Card.

Before proceeding with the following installation procedures, identify the Module Loading

option and installation drawing for your Modem Card (see Appendix A). The options are as

follows:

a. Module Loading Option 1

1010N-5 with 1010N-2 in 1010N/DN Type System. Use Mounting Kit 1015N-2M-MK1. Refer

to Installation Drawing 1015N-2M-MK-7 (sheet 1 of 3). Proceed to paragraph 5.1.1.

b. Module Loading Option 2

1010N-2 only in 1010N/DN Type System. Use Mounting Kit 1015N-2M-MK2. Refer to

Installation Drawing 1015N-2M-MK-7 (sheet 2 of 3). Proceed to paragraph 5.1.2.

c. Module Loading Option 3

1010N-8M with 1010N-2M in 1010MN Type System. Use Mounting Kit 1015N-2M-MK3.

Refer to Installation Drawing 1015N-2M-MK-7 (sheet 3 of 3). Proceed to paragraph 5.1.3.

5.1.1 OPTION 1 INSTALLATION PROCEDURE (Mounting Kit 1015N-2M-MK1)

1010N-5 Module with 1010N-2 Module in 1010N/DN Type System

(Refer to Installation Drawing 1015N-2M-MK-7 sheet 1 of 3)

DISASSEMBLY (see Figure 2 and Figure 3)

1. Referring to Figure 1, open the 1010 NEMA flowmeter top cover by releasing the cover

latch.

2. Place the power switch to the OFF position.

3. Loosen the captive thumbscrew securing the Access Cover and remove Access Cover.

Access Cover

Screw

1010N

Power Switich

Cover Latch

1015N-2MFM-1A

CAUTION: Do not connect a serial data cable to J1 on the 1015N-2M Modem Card or

damage to the Modem Card and flowmeter may result.

4. Loosen the four captive screws (1) at the corners of the 1010N-2 module (7) and carefully

lift out the module disengaging it from the connector on the 1010N-5 module (2).

5. Lift off the shield (3) covering the 1010N-5 module (2).

6. Leave the 1010N-5 module in place. Check to assure that the four corner standoffs (4) are

securely threaded in place.

ASSEMBLY (see Figure 3)

7. Install shield (5) supplied with the 1015N-2M-MK1 mounting kit and cover the 1010N-5

module. Note: This shield replaces the shield removed in Step 5 above.

8. Remove the four captive screws (1) from the 1010N-2 module loosened in Step 4 above.

Install standoffs (6) from mounting kit in the vacant positions.

9. Install the 1010N-2 module (7) carefully engaging connector P1 to the 1010N-5 module (2).

Secure by threading the four standoffs (6) installed in Step 5 above with their mates on

the 1010N-5 module.

10. Check for properly alignment of P1.

Figure 3. Option 1 Installation (side view)

(11) 1010N-2 I/O

Module Cover

(9) 1010N-2 I/O Module

(12) Captive Screw

(1) 1010N-2 Captive Screws

(3) 1010N-5 Analog Module Shield

(4) Threaded Standoffs

(2) 1010N-5 Analog Module Assy

START VIEW

(11) 1010N-2 I/O

Module Cover

(9) 1015N-2M

Modem Card

(7) 1010N-2

I/O Module

(12) Captive Screw

(10) Cover Mount

Standooff

(4) Threaded Standoffs

(6) Threaded Standoff

(5) 1010N-5 Analog

Module Shield

(2) 1010N-5 Analog Module Assy

FINISH VIEW

Serial Data Cable - Not

used with 1015N-2M

Modem Card.

1015N-2MFM-1A

11. Install the 1015N-2M Modem Card (9) on top of the 1010N-2 module (7) carefully engaging

connector P1 on the 1015N-2M with its mate P1 on the 1010N-2 module. Secure the 1015N-

2M by engaging its four captive screws with the four standoffs on the 1010N-2 module.

12. Install the large threaded cover mount standoff (10) from the mounting kit through the

hole at the center of the 1015N-2M Modem Card (9) and into the threaded receptacle on

the shield (5) previously installed in Step 7.

13. Referring to installation drawing 1015N-2M-7 (see Appendix A), plug telephone jack into

J4 of the Modem Card. Thread the telephone line plug through one of the System 1010

flowmeter access holes and plug it into a standard telephone outlet (refer to paragraph

5.3 below for communication connection options).

14. Replace Access Cover and finger tighten captive thumbscrew (12).

15. Place the 1010 flowmeter power switch to the ON position.

16. Close the 1010 flowmeter top cover by locking the cover latch.

17. Proceed to paragraph 5.2 to set 1010N flowmeter RS-232 parameters.

5.1.2 OPTION 2 INSTALLATION PROCEDURE (Mounting Kit 1015N-2M-MK2)

1010N-2 Module only in 1010N/DN Type System

(Refer to Installation Drawing 1015N-2M-MK-7 sheet 2 of 3)

DISASSEMBLY (see Figure 2 and Figure 4)

1. Referring to Figure 2 above, open the 1010 NEMA flowmeter top cover by releasing the

cover latch.

2. Place the power switch to the OFF position.

3. Loosen the captive thumbscrew securing the Access Cover and remove Access Cover.

CAUTION: Do not connect a serial data cable to J1 on the 1015N-2M Modem Card or

damage to the Modem Card and flowmeter may result.

4. Loosen the four captive screws (1) at the corners of the 1010N-2 module (2) and carefully

lift out the module disengaging it from the connector on the 1010N-1 module.

ASSEMBLY (see Figure 4)

5. Remove four captive screws (1) from the 1010N-2 module (2) loosened in Step 4 above.

Install standoffs (3) from the mounting kit in the vacant positions.

6. Install the 1010N-2 module (2) carefully engaging connector P1 to the 1010N-1 module.

Secure module by threading the four standoffs (3) installed in Step 5 above with their

mates on the 1010N-1 module.

7. Check for properly alignment of P1.

8. Install the 1015N-2M Modem Card (4) on top of the 1010N-2 module (2) carefully engaging

connector P1 on the 1015N-2M with its mate P1 on the 1010N-2 module. Secure the 1015N-

2M by engaging its four captive screws (1) with the four standoffs (3) on the 1010N-2 module.

1015N-2MFM-1A

9. Install the large threaded cover mount standoff (5) from the mounting kit through the

hole at the center of the 1015N-2M Modem Card, through the spacer on the 1010N-2 module

and then into the threaded receptacle on the 1010N-1 module shield (6).

10. Referring to installation drawing 1015N-2M-7 (see Appendix A), plug a telephone jack

into J4 of the Modem Card. Thread the telephone line plug through one of the System

1010 flowmeter access holes and plug it into a standard telephone outlet (refer to paragraph

5.3 below for communication connection options).

11. Replace Access Cover (7) and finger tighten captive thumbscrew (8).

12. Place the 1010 flowmeter power switch to the ON position.

13. Close the 1010 flowmeter top cover by locking the cover latch.

14. Proceed to paragraph 5.2 to set 1010N flowmeter RS-232 parameters.

5.1.3 OPTION 3 INSTALLATION PROCEDURE (Mounting Kit 1015N-2M-MK3)

1010N-8N Module with 1010MN Type System

(Refer to Installation Drawing 1015N-2M-MK-7 sheet 3 of 3)

DISASSEMBLY (see figure 2 and figure 5)

1. Referring to Figure 2 above, open the 1010 NEMA flowmeter top cover by releasing the

cover latch.

2. Place the power switch to the OFF position.

3. Loosen the captive thumbscrew securing the Access Cover and remove Access Cover.

Figure 4. Option 2 Installation (side view)

(7) 1010N-2 I/O

Module Cover

(2) 1010N-2 I/O

Module Assy

(8) Captive Screw

(1) Captive Screws

(6) 1010N-1 Module Shield

(7) 1010N-2 I/O

Module Cover

(4) 1015N-2M

Modem Card

(2) 1010N-2 I/O

Module Assy

(8) Captive Screw

(5) Cover Mount

Standoff

(3) Threaded

Standoff

(6) 1010N-1 Module Shield

START VIEW

FINISH VIEW

Serial Data Cable - Not

used with 1015N-2M

Modem Card.

This manual suits for next models

Table of contents

Other Siemens Modem manuals

Siemens

Siemens EDGE Speed ES75 User manual

Siemens

Siemens TC35i Terminal User manual

Siemens

Siemens SINAUT MD720-3 User guide

Siemens

Siemens APOGEE USR5686 User manual

Siemens

Siemens Orcon Homehub User manual

Siemens

Siemens 7NG3092-8KU User manual

Siemens

Siemens SE366 User manual

Siemens

Siemens 7XV5655-0BB00 User manual

Siemens

Siemens SpeedStream 6101 User manual

Siemens

Siemens MC35 Terminal User manual

Siemens

Siemens TC35i Terminal User manual

Siemens

Siemens SINAUT MD720-3 User manual

Siemens

Siemens tc35it Assembly instructions

Siemens

Siemens SpeedStream 4100 User manual

Siemens

Siemens Brodersen MC55 AT Installation instructions

Siemens

Siemens SINAUT ST7 User manual

Siemens

Siemens 7XV5655-0BB00 User manual

Siemens

Siemens Gigaset USB Stick 108 User manual

Siemens

Siemens Simatic S7-300 User manual

Siemens

Siemens Insys 56k User manual

Siemens

Siemens TC35 User manual

Siemens

Siemens SpeedStream 4200 User manual

Siemens

Siemens Gigaset USB Stick 108 User manual

Siemens

Siemens C2-010 User manual

Popular Modem manuals by other brands

Davicom

Davicom DM562AP Operation manual

EpiValley

EpiValley TATA indicom SXC-1080 user guide

Zte

Zte WiMAX user manual

Intelimax

Intelimax MA-2060 user manual

SMC Networks

SMC Networks D3CM1604V Administrator's manual

Telstra

Telstra Wi-Fi 4G Advanced Pro X user guide

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 user manual

Samsung

Samsung AceLink SAM-335A user guide

Enfora

Enfora Enabler-G Integration guide

iRZ

iRZ ATM2-232 user guide

Zhone

Zhone 6310 installation instructions

Paradyne

Paradyne Hotwire 7976 installation instructions

US Robotics

US Robotics 3453C datasheet

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... user manual

Zte

Zte MF823 user guide

Four-Faith

Four-Faith F1403 user manual

Sierra Wireless

Sierra Wireless AIRLINK MP595W user guide

Gemtek

Gemtek WiMAX WIXFBR-103 user manual
