SIMATIC NET

Produktinformation

Product Information

Information produit

Informazioni sul prodotto

Informaciónsobre producto

Stand/ Dated/ Edition/ Versione/ Versiòn 06/99

CP 343–1 6GK7 343-1BA00-0XE0

ab Ausgabestand 7 (FW–Stand V5.00)

version 7 or higher (firmware V5.00)

à partir de la version 7 (microprogramme V5.00)

a partire dalla versione 7 (versione FW V4.00)

a partir de la versión 7 (FW-V5.00)

SIMATIC S7–300

Deutsch / English / Français / Italiano / Español

ESIEMENS AG 1998

Änderungen vorbehalten

Subject to alteration

Sous réserve de modifications

Con riserva di modifiche

Sujeto a cambios

C79000–Z8964–C038–05

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hinweis / Note / Avertissement / Avvertenza / Indicación

Achtung

Vor der Inbetriebnahme Hinweise in der entsprechenden aktuellen Dokumentation beachten. Die Bestelldaten

hierfür entnehmen Sie bitte den Katalogen oder wenden Sie sich an Ihre örtliche SI M NSĆNiederlassung.

Die Inbetriebnahme ist solange untersagt, bis festgestellt wurde, daß die Maschine, in die diese Komponente

eingebaut werden soll, den Bestimmungen der Richtlinie 89/392/ WG entspricht.

Attention

Prior to startup you must observe the notes in the relevant documentation. For ordering data of the documentaĆ

tion please refer to catologs or contact your local SI M NS representative.

Startup must not take place until it is established that the machine, which is to accommodate this component,

is in conformity the guideline 89/392/ C.

Attention

Avant la mise en service, respecter les instructions de la documentation actuelle correspondante. Pour les

références de commande de la documentation, veuillezĆvous reporter aux catalogues ou consulter votre

agence locale SI M NS.

La mise en service est interdite tant que la machine dans laquelle est incorporé ce composant n'est pas conĆ

forme aux prescriptions de la directive 89/392/C .

Attenzione

Prima della messa in funzione, osservare attentamente le avvertenze riportate nella documentazione corrente.

Per i dati di ordinazione consultare i cataloghi oppure rivolgersi alla locale fidale SI M NS.

La messa in funzione è vietata fino a quando non è stato acctertato che macchina, in cui il componente deve

essere installato, non rispetta le disposizioni della direttiva 89/392/CC .

Atención

Antes de la puesta en marcha observar las indicaciones contenidas en la documentatción actual corresponĆ

diente. La referencia de la misma puede consultarse en los catáloges o solicitarse a su agencia SI M NS local.

stá prohibida la puesta en marcha hasta comprobar que la máquina en donde va a incorporarse este compoĆ

nente cumple lo especificado en la directiva 89/392/CC .

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

english

Productinformation CP343–1

C79000–Z8964–C038–05

Contents

Notes for the Reader 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1 The CP 343-1 Communications Processor 3. . . . . . . . . . . . . . .

1.1 Characteristics 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Performance Data 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2.1 Characteristics of S7 Communication 7. . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2.2 Characteristics of ISO Transport Connections 7. . . . . . . . . . . . . . . . . . .

1.3 Displays and Mode Selector 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.4 Further Information on Operation 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Installation 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 Module Accessories 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Procedure 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Attaching the CP 343-1 to Industrial Ethernet 13. . . . . . . . . . . . . . . . . . . .

3 Technical Data 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 General Technical Data 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 Pinout 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3 Notes on the CE Approval of SIMATIC NET Products 17. . . . . . . . . . . . .

4 References 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Compatibility with the Previous Version

The version of the CP 343-1 described here is functionally compatible with and can

be used to replace the CP 343-1 with order number 6GK7 343–1BA00–0XE0 ver-

sion 6.

The CP 343-1 decribed here has more functions. Refer to the information in

Section 1.1.

Reply Form (at the end of this product information):

We would like to know the purpose for which you are using this module

and would also like to know your opinion of the module and the documen-

tation. You can help us to provide you with better support and to further

improve the product. We would be grateful if you would complete the reply

form and return it to us by post or fax.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

english

2Productinformation CP343–1

C79000–Z8964–C038–05

Notes for the Reader

Safety Guidelines

This manual contains notices which you should observe to ensure your

own personal safety, as well as to protect the product and connected

equipment. These notices are highlighted in the manual by a warning

triangle and are marked as follows according to the level of danger:

Note

draws your attention to particularly important information on the product, handling

the product, or to a particular part of the documentation.

!Caution

indicates that minor personal injury or property damage can result if proper pre-

cautions are not taken.

!Warning

indicates that death, severe personal injury or substantial property damage can

result if proper precautions are not taken.

!Danger

indicates that death, severe personal injury or substantial property damage will

result if proper precautions are not taken.

Wehavecheckedthecontentsofthismanualforagreementwiththe

hardware and software described. Since deviations cannot be

precludedentirely, we cannot guarantee full agreement. However,

the data in this manual are reviewed regularly and any necessary

corrections included in subsequent editions. Suggestions for

improvementare welcomed.

Technical data subject to change.

The reproduction, transmission or use of this document or its

contents is not permitted without express written authority.

Offenders will be liable for damages. All rights, including rights

createdbypatentgrantorregistrationofautilitymodelordesign,are

reserved.

Siemens AG

A&D

IndustrialAutomationSystems

Postfach4848, D-90327Nürnberg

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

english

Productinformation CP 343–1

C79000–Z8964–C038–05

1 The CP 343-1 Communications Processor

Application

The CP 343-1 communications processor is designed for operation in an

S7-300 programmable logic controller. It allows the S7-300 to be attached to

Industrial Ethernet.

LED displays

Mode selector

AUI/ITP interface

15-pin sub D

with sliding locking

mechanism

Figure1 CP 343-1

Design

The module has been designed to match the components of the S7-300

programmable logic controller and has the following features:

SDouble-width module for simple installation in the S7-300 rack.

SThe operator controls and displays are all located on the front panel.

SNo fan necessary.

SDirect backplane bus connection of the modules via accompanying

backplane module connectors.

S15-pin sub D female connector with sliding locking mechanism for

attaching the CP 343-1 to Industrial Ethernet (automatic switchover

between the AUI interface and Twisted Pair interface).

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

english

4Productinformation CP 343–1

C79000–Z8964–C038–05

Configuration

You can configure the CP 343–1 via MPI or LAN/Industrial Ethernet. You re-

quire STEP 7 with the following version of NCM S7 for Industrial Ethernet

(abbreviated to ”NCM IE”below):

Table 1

Version STEP7/NCM IE Functionality of the CP 343–1

V2.x to V5.x The same functionality is available as with the previous

versions of the CP.

SConfiguration data created with these STEP 7 or NCM

versions can be downloaded to the CP 343–1.

V5.x + SP2 or higher The full functionality including the extended functions as

listed in Section 1.1 can be used.

Information about the required service pack (SP2) is

available on the Internet at:

http://www.ad.siemens.de/csi/net

1.1 Characteristics

Services

The CP 343-1 supports the following communication services:

SS5-compatible communication with

–SEND/RECEIVE interface via ISO transport connections

–FETCH/WRITE services (passive; according to the S5 protocol) via

ISO transport connections and ISO-on-TCP connections

SS7 communication with

–PG functions

–Operator control and monitoring functions

–Data exchange using communication function blocks

PG functions:

Using the PG functions, modules such as the FM 354 or FM 355 can be

accessed via the CP (“extended”PG functions).

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

english

Productinformation CP 343–1

C79000–Z8964–C038–05

Note

If there is a diagnostic connection to the CP via the CPU, configuration

data cannot be downloaded automatically to the CP by the CPU at the

same time!

Extended Functions Compared with Version 5

SReading and writing data in the FETCH/WRITE mode

The services FETCH and WRITE are supported for direct access to sy-

stem memory areas on the SIMATIC S7 PLC via ISO transport and and

ISO-on-TCP connections. The SIMATIC S7-300 with the CP 343-1 is

always the server (passive connection establishment), while the fetch or

write access (client functionality with active connection establishment)

originates from a SIMATIC S5 PLC or other device

Requirements –General Operation

The following table shows the S7–300 CPUs with which the CP 343–1 can be

operated with this range of functions:

Table 2

CPU MLFB–Number

CPU 312 IFM 6ES7 312–5AC02–0AB0

CPU 312 (T) 6ES7 312–5AC82–0AB0

CPU 313 6ES7 313–1AD03–0AB0

CPU 314 6ES7 314–1AE04–0AB0

CPU 314 (T) 6ES7 314–1AE84–0AB0

CPU 314 IFM 6ES7 314–5AE03–0AB0

CPU 314 IFM (T) 6ES7 314–5AE83–0AB0

CPU 315 6ES7 315–1AF03–0AB0

CPU 315–2 DP 6ES7 315–2AF03–0AB0

CPU 315–2 DP (T) 6ES7 315–2AF83–0AB0

CPU 316–2 DP 6ES7 316–2AG00–0AB0

CPU 318–26ES7 318–2AJ00–0AB0

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

english

6Productinformation CP 343–1

C79000–Z8964–C038–05

Table 2

CPU MLFB–Number

CPU 614 6ES7 614–1AH03–0AB3

CPU 614–Z6ES7 614–1AH03–0AB3–Z

The table lists the CPUs approved at the time of printing this product informa-

tion bulletin. S7–300 CPUs approved later and not listed in the table also

support the range of functions described here.

All versions of the SINUMERIK CPUs 840D and 810D are supported.

Requirements –ISO Transport Connections

The following conditions must be taken into account on ISO transport con-

nections depending on the length of the data to be transferred:

Table 3

Functionality Requirement

Transfer of

data fields <= 240 bytes The blocks AG_SEND FC5 and AG_RECV FC6 or as an

alternative the blocks AG_LSEND FC50 and AG_ LRECV

FC60 are required.

Transfer of data

fields > 240 bytes Note the two requirments below:

SYou require the blocks AG_LSEND FC50 and

AG_LRECV FC60. These blocks are shipped with

NCM V 4.02 with service pack 1.

The blocks are shipped as standard components of

newer versions of NCM.

SConfiguration:

When configuring the CP 343–1 with Hardware

Configuration in STEP 7, select the option “Data length

> 240 bytes”under the “Options”tab.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

english

Productinformation CP 343–1

C79000–Z8964–C038–05

1.2 Performance Data

1.2.1 Characteristics of S7 Communication

The functions and characteristics of S7 communication are described in /8/

and /11/.

1.2.2 Characteristics of ISO Transport Connections

The following information is important for operating ISO transport connections

(SEND/RECEIVE interface):

Table 4

Characteristic Explanation / Values

Total number of connections on Industrial

Ethernet 32 maximum

Number of connections for S7 communication

on Industrial Ethernet The actual value depends on the CPU type

being used. Please refer to /1/ for the values

for your CPU.

Number of ISO transport connections 16 maximum

Maximum data length for AG_SEND and

AG_RECV blocks AG_SEND and AG_RECV allow the transfer

of data fields of between 1 and 240 bytes.

Maximum data length for AG_LSEND and

AG_LRECV blocks AG_LSEND and AG_LRECV are shipped for

the CP 343–1 from version 5 or higher

(firmware V3.00) and permit the transfer of

data fields of between 1 and 8192 bytes (for

more detailed information, see Table 3 ).

Reaction Times of ISO Transport Connections

The calculation of the reaction times with ISO transport connections is deter-

mined by the run time of the function blocks required on the S7-300 CPU

(AG-SEND, AG–RECV).

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

This manual suits for next models

Table of contents

Other Siemens Computer Hardware manuals

Siemens

Siemens SIMATIC NET CP 443-1 Advanced User manual

Siemens

Siemens CPU 412-1 User manual

Siemens

Siemens PAD-5 Series User manual

Siemens

Siemens TC35i Terminal User manual

Siemens

Siemens SIMATIC CP 541 User manual

Siemens

Siemens SIMATIC NET CP 1623 User manual

Siemens

Siemens CP 5613 A3 User manual

Siemens

Siemens SMP16-CPU06 Series User manual

Siemens

Siemens SIMATIC NET 6GK7 443-5FX02-0XE0 User manual

Siemens

Siemens CPU 31 Series Instruction manual

Siemens

Siemens Metro 21 M216KA User manual

Siemens

Siemens Simatic 545-1106 User manual

Siemens

Siemens Simatic M7-400 User manual

Siemens

Siemens XMS-SP User manual

Siemens

Siemens SIMOTION TB30 User manual

Siemens

Siemens Simatic S7-300 Instruction manual

Siemens

Siemens SIMATIC NET CP 5622 User manual

Siemens

Siemens SIMATIC CP 341 User manual

Siemens

Siemens SIMATIC S7-1200 CP 1243-8 IRC User manual

Siemens

Siemens CP 443-1 User manual

Siemens

Siemens SIMATIC S7-300 CPU Data: CPU 315-T-2 DP User manual

Siemens

Siemens SIMATIC NET CP 1411 User manual

Siemens

Siemens PAD-5-CLSA User manual

Siemens

Siemens SIMEAS-Hub 7KE6000-8AD /CC User manual

Popular Computer Hardware manuals by other brands

EMC2

EMC2 VNX Series Hardware Information Guide

Panasonic

Panasonic DV0PM20105 Operation manual

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 user manual

Gigabyte

Gigabyte B660M DS3H AX DDR4 user manual

Raidon

Raidon iT2300 Quick installation guide

National Instruments

National Instruments PXI-8186 user manual

Hauppauge

Hauppauge WinTV-HVR-2250 Quick installation guide

Kontron

Kontron CP6002 user guide

Manhattan

Manhattan 702843 user manual

Aphex

Aphex 230 instruction manual

AMD

AMD Phenom II Product data sheet

Intel

Intel NUC 12 Pro user guide

dbx

dbx Zone Pro 1260 user manual

Galaxy

Galaxy GHDX2-2430S-24F4D Installation and hardware reference manual

Intel

Intel AXXRMFBU4 Quick installation user's guide

Kontron

Kontron DIMM-PC/MD product manual

ST X-NUCLEO-SAFEA1B How to use

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 installation manual
