Sharp FP-F30EU-H User manual
Home Appliances
Air Purifier
Service
& Support
Visit our website:
www.sharphomeappliances.com
Or contact us: Air Purifier
FP-F30EU-H
*The number in this technology mark indicates an
approximate number of ions supplied into air of
1 cm3, which is measured around the center of a
room with the “high-density plasmacluster 7000”
applicable oor area (at 1.2 m height above the
oor) at the medium wind volume in air purifying
mode, when an air purier using the high-density
plasmacluster ion evolving device is placed close
to a wall. This product is equipped with a device
corresponding to this capacity.
“Plasmacluster” and “Device of
a cluster of grapes” are trade-
marks of Sharp Corporation.
00_OM_FP-F30EU_20170223_FRONT.indd 1 2017/02/24 11:30:37
For Life
EN
Operation manual
DE
Bedienungsanleitung
NL Bedieningshandleiding
PL Instrukcja obsługi
ES Manual de funcionamiento
SE Bruksanvisning
FR Manuel d’utilisation
DK
Brugsanvisning
Please read before operating your new Air Purier
The air purier draws in room air from the air intake, passes the air through a pre-Fil-
ter, a HEPA Filter inside of the unit, then discharges the air through the air outlet.
The HEPA Filter can remove 99.97% of dust particles as small as 0.3 microns that
pass through the lter.
Some odours absorbed by the lter may break down over time, resulting in additional
odours. Depending on the usage environment, especially when the product is used
in extreme environments (signicantly more severe than normal household use), this
odours may become strong in a shorter period than expected. If the odours persists,
the lter should be replaced.
NOTE
• The air purier is designed to remove air-suspended dust, but not harmful gases
(for example, carbon monoxide contained in cigarette smoke).
HEPA Filter
Pre-Filter
OM_FP-F30EU_20161214_WEST.indb 1 2017-02-22 15:14:30
E-1
ENGLISH
ENGLISH
Thank you for purchasing the SHARP
Air Purifier. Please read this manual care-
fully. Before using this product, be sure to
read the section: “Important Safety Instruc-
tions.” After reading this manual, keep it in a
convenient location for future reference. For
your reference, we recommend to keep this
manual in the place where you can read at
any time.
IMPORTANT SAFETY INSTRUCTIONS
.....E-2
PART NAMES...............................................E-4
FILTER INSTALLATION .............................E-5
OPERATION .................................................E-6
CARE AND MAINTENANCE .....................E-8
TROUBLESHOOTING ..............................E-10
SPECIFICATIONS......................................E-10
CONTENTS
FEATURES
Unique Combination of Air Treatment
Technologies
Filtration System + Plasmacluster
TRAPS DUST*
Pre-Filter traps dust and other large
airborne particles.
REDUCES POLLEN & MOLD*
HEPA Filter traps 99.97% of particles as
small as 0.3 microns.
FRESHENS
Plasmacluster treats the air similar to the
way nature cleans the environment by
emitting a balance of positive and negative
ions.
* When air is drawn through the lter
system.
OM_FP-F30EU_20161214_WEST.indb 1 2017-02-22 15:14:30
E-2
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be fol-
lowed, including the following:
WARNING - To reduce the risk of electrical shock, re or injury to persons:
• Read all instructions before using the unit.
• Use only a 220-240 volt outlet.
• Do not use the unit if the power cord or plug is damaged or the connection
to the wall outlet is loosened.
•Periodically remove dust from the power plug.
• Do not insert ngers or foreign objects into the intake or air outlet.
• When removing the power plug, always hold the plug and never pull the
cord.
Electrical shock and/or re from short circuit may occur as a result.
• Be careful not to damage the power cord, it may cause electric shock, excess heat
or res.
• Do not remove the plug when your hands are wet.
• Do not use this unit near gas appliances or replaces.
• Remove the power plug from the wall outlet before cleaning the unit and
when not using the unit.
Electrical shock from bad insulation and/or re from short circuit may occur as a
result.
•When cleaning the unit, or when the unit is not in use, be sure to unplug the unit.
Electrical shock and/or re from a short circuit may result.
• If the power cord is damaged, it must be replaced by the manufacturer, its
service agent, Sharp Approved Service Centre or similarly qualied person
in order to avoid a hazard.
•Do not operate when using aerosol insecticides or in rooms where there is oily
residue, incense, sparks from lit cigarettes, chemical fumes in the air or in very
high humidity conditions, such as a bathroom.
•Be cautious when cleaning the unit. Corrosive cleansers may damage the exterior.
•Only a Sharp Authorized Service Centre should service this air purier. Contact
the nearest Service Centre for any problems, adjustments, or repairs.
• This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
NOTE - Radio or TV Interference
If this air purier should cause interference to radio or television reception, try to cor-
rect the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the unit and radio/TV/wave-clock receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
OM_FP-F30EU_20161214_WEST.indb 2 2017-02-22 15:14:30
E-3
ENGLISH
CAUTIONS CONCERNING OPERATION
• Do not block the intake and/or air outlet.
• Do not use the unit near or on hot objects, such as stoves or heaters or where it
may come into contact with steam.
• Do not lay the unit down when using.
• Always hold the handle on the back of the unit when moving it.
• Do not use without the lter inside the unit.
•Do not wash and reuse the HEPA Filter.
Not only does it not improve filter performance, it may cause electric shock or
malfunction.
INSTALLATION GUIDELINES
•When using the unit, place it away from equipment utilizing electric waves
such as televisions or radios to avoid electrical interference.
•Avoid use in locations where furniture, fabrics or other items may come in
contact with and restrict the air intake and/or air outlet.
•Avoid use in locations where the unit is exposed to condensation or drastic
temperature changes. Appropriate conditions are when room temperature is
between 0 – 35 ºC.
•Place on a stable surface with sufcient air circulation.
When placing the unit on a heavily carpeted area, the unit may vibrate slightly.
•Avoid locations where grease or oily smoke is generated.
The unit surface may crack as a result.
•Place the unit about 30 cm(1 ft) away from the wall in order to ensure proper
airow.
The dust collecting performance will be the same even if using the unit 3cm away
from the wall, but place it as far as possible(30cm away recommended) because it
may dirty the wall or oor around.
FILTER GUIDELINES
• Follow the instructions in this manual for correct care and maintenance of the l-
ter.
OM_FP-F30EU_20161214_WEST.indb 3 2017-02-22 15:14:30
E-4
1Main Unit 9 HEPA Filter
2Air Outlet 10 Upper Tabs
3Fan Speed Indicator Lights (green) 11 Back Panel (Pre-Filter)
4MODE Button / LIGHT ON/OFF Button
(Press 3 sec.) 12 Bottom Tabs
5Plasmacluster Ion Indicator Light (blue) 13 Handle
6Plasmacluster Ion ON/OFF Button 14 Date Label
7POWER ON/OFF Button 15 Power Cord
8CLEAN ION SHOWER Button / CLEAN ION
SHOWER indicator Light (green) 16 Plug
PART NAMES
13
14
16
2
1
FRONT
BACK
4
6
7
8
3
15
9
10
11
12
5
OM_FP-F30EU_20161214_WEST.indb 4 2017-02-22 15:14:31
E-5
ENGLISH
4Replace the Back Panel to the
main unit.
5Fill in the usage start date on the
Date Label.
Use the date as a guide for the filter re-
placement schedule.
FILTER INSTALLATION
To maintain the quality of the lter, it is installed in the main unit and packed in plastic
bag. Be sure to remove the lter from the plastic bag before using the unit.
1
Remove the Back Panel.
2
Remove the lter from the plas-
tic bag.
3
Place the filter within the main
unit.
Do not install the lter backwards or the
unit will not operate properly.
Upper Tabs
• Do not operate the unit without the lter.
Date Label
Pull
Be sure to remove the power plug
from the wall outlet.
Bottom Tabs
Push
OM_FP-F30EU_20161214_WEST.indb 5 2017-02-22 15:14:32
E-6
OPERATION
Releases high-density Plasmacluster ions and discharges strong air ow for 60 minutes.
CLEAN AIR
START
•Select the desired fan speed.
•Unless the power cord has been unplugged,
the operation starts in the previous mode it
was operated in.
STOP
CLEAN ION SHOWER
START
• If Plasmacluster Ion is OFF, Plasmacluster Ion will not be
released.
• When the operation nishes, the unit will return to the prior
operation mode.
It is able to change the other mode and during this
mode.
NOTE
FAN SPEED
MED MAX SLEEP
SLEEP
• The unit will operate very quietly with low fan speed. Plas-
macluster Ion Indicator goes off automatically. Even though
the indicator is off, Plasmacluster Ion is dispersed into air
unless Plasmacluster Ion is turned off by pressing .
NOTE
OM_FP-F30EU_20161214_WEST.indb 6 2017-02-22 15:14:33
E-7
ENGLISH
When Indicator is off,
•If Plasmacluster Ion is ON,
•If Plasmacluster Ion is OFF,
If the , , lamp Lights up for 10 seconds, the setting is completed.
Light Control
Plasmacluster Ion ON/OFF
You can set the Plasmacluster Ion Indicator to OFF when the Plasmacluster Ion Indicator is bright.
ON
more than 3 sec. more than 3 sec.
OFF
When Plasmacluster Ion is ON, the Plasmacluster Ion Indicator Light will turn on. (blue)
ON OFF
Auto RESTART
If the unit is unplugged or if there is a power failure, the unit will resume operation with the previous
settings after power is restored.
ON OFF
(with the unit OFF)
more than 3 sec.
(with the unit OFF)
more than 3 sec.
3 sec.
3 sec.
OFF
OFF
•When the unit starts operation, the
Plasmacluster Ion Indicator always
lights.
•In SLEEP mode, Light Control but-
ton doesn’t operate.
NOTE
NOTE
Flashing
Lighting
Lighting Flashing
OM_FP-F30EU_20161214_WEST.indb 7 2017-02-22 15:14:35
E-8
Gently remove dust from the back panel,
using a vacuum cleaner attachment or simi-
lar tool.
Gently remove dust from the HEPA Filter with a vacuum clean-
er attachment or similar tool.
BACK PANEL (Pre-Filter)
HEPA Filter
To maintain optimum performance of this air purier, please clean the unit including the lter
periodically.
Be sure to disconnect the power cord from the wall outlet before performing any maintenance.
CARE AND MAINTENANCE
Back Panel
Back Panel
CAUTION
Do not apply excessive pressure, when
scrubbing the back panel.
CAUTION
• Do not WASH in water and DRY in the sun.
• Apply the maintenance only on the side with the tag.
Do not clean the opposite side; otherwise, the lter will be
damaged.
The lter is fragile, be careful not to apply too much force.
NOTE How to clean stubborn dirt
1. Add a small amount of kitchen
detergent to water and soak for about
10 minutes.
2. Rinse off the kitchen detergent with
clean water.
3. Completely dry the lter in a well-
ventilated area.
UNIT
Wipe with a dry, soft cloth
For stubborn stains or dirt, use a soft cloth dampened with warm water.
CAUTION
•Do not use volatile uids
Benzine, paint thinner, polishing powder, etc. , may damage the surface.
•Do not use detergents
Detergent ingredients may damage the unit.
Tag
OM_FP-F30EU_20161214_WEST.indb 8 2017-02-22 15:14:36
Table of contents
Languages:
Other Sharp Air Cleaner manuals
Sharp
Sharp IG-CL15UW User manual
Sharp
Sharp Plasmacluster KC-6400E User manual
Sharp
Sharp FP-FM40E User manual
Sharp
Sharp Plasmacluster FP-P60CX User manual
Sharp
Sharp KI-A60Y User manual
Sharp
Sharp IG-NX2B User manual
Sharp
Sharp Plasmacluster FP-A40C User manual
Sharp
Sharp QNET FP-E50E User manual
Sharp
Sharp FP-J40A User manual
Sharp
Sharp FX-J80A User manual
Sharp
Sharp IG-DX10A User manual
Sharp
Sharp IG-CL15B User manual
Sharp
Sharp FU-440E User manual
Sharp
Sharp EH-HS41 User manual
Sharp
Sharp Plasmacluster FP-P40CX User manual
Sharp
Sharp Plasmacluster KC-C100U User manual
Sharp
Sharp KC-F32EU User manual
Sharp
Sharp FU-28H-S User manual
Sharp
Sharp IG-A40UW User manual
Sharp
Sharp KCP110UW User manual
