Sevylor HUI 100 Product manual

I NFLATABLE BOATS

READ THE FOLLOWING

INSTRUCTIONS AND WARNINGS TO AVOID

DROWNING OR SERIOUS INJURY

WARNING:

•Not a life saving device.

•Not for use by children without adult supervision.

•Always wear an approved Personal Flotation Device

(Life Preserver).

•Do not overload.

•Never tow from another boat or vehicle.

•Use only in water away from debris and obstructions.

•Do not use in high wind, strong currents, open water or

dangerous tides.

•Be familiar with the area you intend to use the product.

•Never allow diving into or from these products.

•Never leave in or near water when not in use.

•Know and follow local water safety rules and boating

regulations.

•Use only in protected waters.

•Do not use this product under the inﬂuence of alcohol

or drugs.

•Do not over inﬂate.

•Follow inﬂation sequence on the product.

Including the following Model Series:

Colossus™ and HUI

INFLATABLE BOATS

IMPORTANT INFORMATION

The warnings below relate to various situations. Please observe them.

CAUTION!

Denotes a imminent hazard which will result in severe injury if you

do not comply with the instructions.

WARNING!

Reminds you of safety measures which must be observed. Also

denotes unsafe practices which could result in personal injury or

damage to the product or property, if you do not comply with the

instructions.

CAUTION!

It is the owner's responsibility to make sure all users carefully

read and follow the instructions for safe operation of this

product. Observe all local and national laws. Always wear a

Personal Flotation Device approved by the proper authorities.

Please carefully observe the Capacity Plate information which

is printed on the product.

WARNING!

These products are not meant for towing because the extreme

pressure of the water while towing can tear the eyelets and/or

handles. These products are not meant to be used in whitewater.

CAUTION!

Altering the construction of these products could jeopardize the

safety of the occupants and will void the limited warranty.

CAUTION!

Keep boat away from gasoline, battery acid, solvents, etc., as they

can damage the product.

INFLATABLE BOATS

INFLATION INSTRUCTIONS

CAUTION!

Do not over inate. Pressurize product to "Ination Pressure"

stated in the chart for your specic product.

WARNING!

Never use a compressor, CO2or compressed air to inate the

product. Do not let Your product come into contact with sharp,

pointed objects.

To inate using any Sevylor®Pump:

1. To begin inﬂation, open external cap and pull ﬁrmly on

the lanyard to extend out. This will open internal yellow

seal.

3. When fully inﬂated, seal valve by pushing in with

adapter nozzle. This will seal the internal yellow

stopper and keep air from escaping while closing cap.

Gently twist adapter while backing hose out of valve.

2. Attach nozzle of hose to inﬂation end of pump. Insert

adapter nozzle into valve and start pumping.

4. Fully remove pump and hose and close external cap.

Valve should appear depressed into itself.

INFLATABLE BOATS

IMPORTANT! Inate the product chambers in the following order:

1. Inate the inside all-around safety chamber.

2. Inate the oor chamber(s).

3. Inate the outside main chamber.

The chambers on the product will be numbered to indicate order of

ination also. This order of ination will ensure the proper volume and

buoyancy of the safety chamber.

Note: To inate the mini double lockTM valve, which is used on some

of the Sevylor boat oors and seat bottoms, follow the same ina-

tion instructions above, using the mini double lockTM valve adapter.

The mini Double Lock™ valve adapter is included with all Sevylor®

pumps. The adapter can be purchased from Customer Service by

calling 1-800-835-3278 (Part Number 5010000707).

CAUTION!

Water temperature and weather do affect the pressure in inatable

products. In cold weather your product will lose some pressure due

to the fact the air will contract. If this occurs, you may want to add

a little air to improve your product’s performance. However, in hot

weather, the air will expand. You must let some air out to prevent

your product from failing due to overpressure. You should avoid

exposing your product to extreme temperatures (hot or cold).

DEFLATION INSTRUCTIONS

Deation instructions using any Sevylor®Pump:

Remove nozzle of hose from inﬂation end and attach to

opposite deﬂation end of pump. Repeat same steps as

inﬂation. This will draw the air out quickly.

INFLATABLE BOATS

Persons

Capacity

Maximum Pay-

load Capacity Engine Inflation

Pressure

Inflation

Pressure

Model # Persons Only

Persons, Gear,

Motor

(if applicable)

Max. HP Engine Main

Chamber(s)

Floor

Chamber(s)

HUI 100 1 Pers. or 190

lbs. 190 lbs. N/A 0.4 PSI 0.4 PSI

HUI 200 2 Pers. or 370

lbs. 370 lbs. N/A 0.4 PSI 0.4 PSI

HUI 400 4 Pers. or 650

lbs. 650 lbs. N/A 0.4 PSI 0.4 PSI

WARNING!

Do not exceed the certied maximum capacities under any circumstances!

WARNING!

Do not exceed the certied maximum capacities under any circumstances!

Persons

Capacity

Maximum Pay-

load Capacity Engine Inflation

Pressure

Inflation

Pressure

Model # Persons Only

Persons, Gear,

Motor

(if applicable)

Max. HP Engine Main

Chamber(s)

Floor

Chamber(s)

Colossus™

2 Person Boat

2 Pers. or

435 lbs. 435 lbs. N/A 0.5 PSI 0.5 PSI

Colossus™

3 Person Boat

3 Pers. or

680 lbs. 680 lbs. N/A 0.5 PSI 0.5 PSI

Colossus™

4 Person Boat

4 Pers. or

840 lbs. 840 lbs. N/A 0.5 PSI 0.5 PSI

WARNING!

Do not attempt to mount a motor on any boat that does not state a

Max. HP Engine rating.

INFLATABLE BOATS

OPERATING INSTRUCTIONS:

•Follow all local boating regulations and navigation rules.

Familiarize yourself with boating conditions where you plan to use

the product. Use common sense and caution when operating in

unfamiliar places.

•Observe the maximum weight the product can carry and do not

overload past this limit. Over-loading jeopardizes the safety of the

occupants.

•Be sure all accessories and/or equipment (e.g. oars, life jackets)

are in proper working condition before using the product. Each

person occupying the product is to wear an approved Personal

Flotation Device (life preserver).

•Sharp objects are not to be carried in the product without

adequate protection or storage.

•When navigating the product in any water depth, watch for

submerged or sharp objects that may damage or pierce the

product’s air chambers.

•Enter the product from the port (left) or starboard (right) sides -

not from the fore (front) or aft (back) sides.

•Never tow with a boat or any other vehicle.

DANGER!

CARBON MONOXIDE (CO) CAN CAUSE PERSONAL INJURY,

BRAIN DAMAGE OR DEATH.

Carbon monoxide is an odorless, colorless, extremely toxic gas.

Symptoms of carbon monoxide poisoning are dizziness, ears

ringing, headaches, nausea and unconsciousness.

Have the victim breathe fresh air deeply. If breathing stops,

resuscitate. A victim often revives, then relapses because organs

are damaged by lack of oxygen. Seek immediate medical attention.

WARNING!

ROTATING PROPELLER MAY CAUSE SERIOUS INJURY OR DEATH

•Keep away from the rear of boat while engine is running.

WARNING!

•DO NOT mount a motor on any boat that exceeds the Maximum

Horsepower rating for your specic boat model. See pages 5.

MOTOR MOUNTING

INFLATABLE BOATS

WARNING!

AVOID SERIOUS INJURY OR DEATH

•DO NOT sit on the side tubes while the product is underway.

Sudden movement of the product will cause you to lose balance

and fall. Sit on the oor or on the seating cushion and use the

grab line to prevent loss of balance.

PROPER SEATING LOCATION

CARE & STORAGE:

•Your product is made of the highest quality materials. Altering

the construction of your product will void the limited warranty and

could jeopardize the safety of the occupants.

•If your product has been used in salt water, rinse it off with fresh

water as soon as possible.

•Remove tar spots or other soiled areas by using a mild soap and

rinsing with fresh water.

•Be sure Your product is completely dry before storing.

•The product may be stored inated, but do not place any heavy or

sharp objects on or near it. Storage is best in a dry room.

INFLATABLE BOATS

Grab Line

4 Oar Locks

2 Oar Locks

4 Air

Chambers

4 Air

Chambers

3 Air

Chambers

8 Rope Holders

with Oar Storage

Clips

8 Rope Holders

with Oar Storage

Clips

Front

Handle

Front

Handle

Front

Handle

4 PERSON

3 PERSON

2 PERSON

Colossus™ Models

INFLATABLE BOATS

HUI 400

HUI 200

HUI 100

HUI Models

Carry

Handle

Grab Line

4 Oar Locks

DIN Safety Chamber

Main Chamber

Inated Floor-

2 Chambers

2 Oar Locks

Main Chamber

Inated Floor-

2 Chambers

DIN Safety Chamber

Grab Line

Inated Floor-

2 Chambers

Grab Line

2 Oar Locks DIN Safety Chamber

Main Chamber

INFLATABLE BOATS

GRAB LINE INSTALLATION:

IMPORTANT: To properly install the inatable boat’s grab line, rst

inate the product. Feed the grab line through the eyelets on each of

the rope holders. Then tie the two loose ends in a square knot at the

rear of the product.

The assembled oar is to be inserted into the oar locks from the

outside of the product. The oar retainer ring is then placed onto

the top half of the assembled oar, from the inside of the product, to

prevent the oar from sliding into the water (see below).

OAR ASSEMBLY:

(for models with oar included)

Join the two shafts together by screwing them together into the

coupler. Attach the blade to the shafts by screwing in into the bottom

of the shaft.

Replacement Part #2000004151

Square Knot

Retainer

Ring

Coupler

Shaft Shaft

Blade

This manual suits for next models

Table of contents

Other Sevylor Boat manuals

Sevylor

Sevylor Coral Sea STK290 User manual

Sevylor

Sevylor SK100DS User manual

Sevylor

Sevylor Tahiti User manual

Sevylor

Sevylor SV270S-HF User manual

Sevylor

Sevylor YUKON KCC380 User manual

Sevylor

Sevylor Tahiti User manual

Sevylor

Sevylor Sit On Top User manual

Sevylor

Sevylor FT280 Fish Ranger User manual

Sevylor

Sevylor INFLATABLE STANDUPPADDLEBOARD User manual

Sevylor

Sevylor REEF 240 User manual

Sevylor

Sevylor HUDSON SIROCCO PRO 3 User manual

Sevylor

Sevylor HUDSON KCC360 User manual

Sevylor

Sevylor QuikPak User manual

Sevylor

Sevylor Pacifica User manual

Sevylor

Sevylor QuikPak User manual

Sevylor

Sevylor Fish Hunter Series User manual

Sevylor

Sevylor POINTER K1 User manual

Sevylor

Sevylor RIO Series KCC305 User manual

Sevylor

Sevylor Caravelle KK55 User manual

Sevylor

Sevylor K5 QuikPak Operating instructions

Sevylor

Sevylor 1 Person Sit On Top Kayak (Non Covered) User manual

Sevylor

Sevylor Fiji User manual

Sevylor

Sevylor TFT260 User manual

Sevylor

Sevylor HUDSON KCC360 User manual

Popular Boat manuals by other brands

Raymarine

Raymarine ST70 Instrument User reference handbook

Pro-Line Boats

Pro-Line Boats Pro Line 19 Sport owner's manual

Jeanneau

Jeanneau CAP CAMARAT 8.5 CC owner's manual

Tiara Yachts

Tiara Yachts C49 2024 owner's manual

Monterey Boats

Monterey Boats Sport Yacht 330 owner's manual

J 105 owner's manual

PURSUIT

PURSUIT OS 335 owner's manual

Boston Whaler

Boston Whaler CONQUEST 345 owner's manual

Jeanneau

Jeanneau SUN ODYSSEY 41 DS owner's manual

Meridian

Meridian 490 Pilothouse owner's manual

Advanced Elements

Advanced Elements AdvancedFrame Expedition AE1009 owner's manual

Robo Marine Indonesia

Robo Marine Indonesia GEOMAR user manual

Swallow Boats

Swallow Boats BayRaider owner's manual

Intex

Intex Excursion 5 Set manual

X SHORE

X SHORE EELEX 8000 owner's manual

ISLAND PACKET

ISLAND PACKET 370 owner's manual

Sea Ray

Sea Ray 175 Sport owner's manual

Regal

Regal 2300 owner's manual
