Sennheiser ME 35 Dimensions

General Description

Sennheiser’s modular Installed Sound Series microphones kits for podium,

hanging, boundary layer and table stand applications facilitate all possible

installation conﬁgurations at affordable prices. At the heart of the series are

three superbly engineered capsules: the ME 34 cardioid, the ME 35 super cardioid

and the unique lobar-patterned ME 36 mini shotgun. Each capsule can interface

with three different goosenecks: the 15 cm MZH 3015 (6"), the 40 cm MZH 3040

(15.75") and the dual ﬂex 40 cm MZH 3042 (15.75"), all designed to maintain

proper capsule placement. Each system requires 12-48 volt phantom power.

All contact points are gold plated and corrosion resistant. All components have

anti-reﬂective matte black surfaces.

Technical Data

Acoustic operating principle Pressure gradient transducer

Pick-up pattern Super-cardioid

Frequency response 50–20,000 Hz

Sensitivity (free ﬁeld, no load) 10 mV/Pa

Electrical impedance 50 Ω

Min. terminating impedance 1 KΩ

Equivalent noise level 26 dB-A

37 dB-CCIR

Power supply P 12–P 48

Dimensions .47" x .71" (11.93mm x 18.04mm)

Weight .34 oz.

Connector XLR-3

.69"

[17.53mm]

Ø.48"

[12.19mm]

MZS31

MZT30

MZH3015

ME35

ME 35

Polar Pattern Frequency Response Graph

Super cardioid patterned condenser microphone capsule. Provides

a high degree of isolation.

.68"

[17.3mm]

2.96"

[75.2mm]

5.59"

[142.0mm]

1.95"

[49.5mm]

Ø .74"

[18.8mm]

Ø.32"

[8.1mm]

The MZH 3015 is a metal gooseneck for use with the ME 34, ME 35

and ME 36 microphone capsules and is 15 cm (6") in length.

It features a rugged anti-reﬂective matte black coating and uses

a balanced ﬂoating XLR-3 connector with standard polarity.

MZH 3015

Microphones | Installed Sound

Kit Includes:

ME 35 Capsule

MZH 3015 Gooseneck

MZT 30 XLR Table Mount

MZS 31 Shock Mount

i15-S

150˚

120˚

90˚

60˚

30˚

030˚

60˚

90˚

120˚

150˚

180˚

125 Hz

250 Hz

500 Hz

1000 Hz

2000 Hz

4000 Hz

8000 Hz

16000 Hz

i15-S

CBinder - MIcrophones.indd 5 11/11/08 2:23:00 PM
