Sennheiser 27 Series User manual

Sennheiser electronic GmbH & Co. KG

Am Labor 1, 30900 Wedemark, Germany

www.sennheiser.com

Printed in Germany, Publ. 07/22, 592848/A01

HMD 27 | HMDC 27

27 SERIES HEADSET

Quick Guide

Kurzanleitung

Guide de démarrage rapide

Guida rapida

Instrucciones resumidas

Instruções resumidas

Beknopte gebruiksaanwijzing

Krótka instrukcja obsługi

Snabbguide

Kort vejledning

Pikaohje

Σύντοµες οδηγίες

Kısa Kılavuz

Краткая инструкция

快速指南

快速使用指南

クイックガイド

요약 안내서

Sennheiser Documentation App

or online at

www.sennheiser.com/download

27 SERIES HEADSET_

HME 27

Switching ActiveGard™

In the box

Single-sided listening Using accessories

Wearing the headset

Switching NoiseGard™

Safety

Guide

Quick

Guide

ActiveGard

Limiter

2 cm

HME 27

HMD 27

45°

Off

ActiveGard

Limiter

Left = ActiveGard™ switched on

Right = ActiveGard™ switched off

HMD 27 HME 27 HMDC 27

180°

XLR-3

6.3 mm

OROR

2. push

1. press

OFF

HMDC 27

Cable-II-X3K1

HMDC 27

Replacing the headband Replacing the ear pads

Cleaning

1 Peel off the large headband padding.

Wearing with small headbandsWearing with large headband padding

1Remove both small headbands.

2 Collapse the split headband.

3 Mount the large headband padding. 2 Mount the small headbands.

Speciﬁcations

Transducer principle

Type

Directivity

Transmission rate

Sensitivity

Impedance

Max. sound pressure level

Interface

Power supply

Microphone

BMD 434

pre-polarized condenser

microphone dynamic

cardioid super-cardioid

40 – 20,000 Hz 40 – 18,000 Hz

16 mV/Pa @ 1 kHz 0.5 mV/Pa @ 1 kHz

– 300 Ω

–

Phantom-powered P12–P48

12 V – 48 V

BKE 10-4

150 dB SPL, 1 kHz, 0.5% THD

Ambient temperature

Weight without cable

General Data

Storage: -55 °C to +70 °C

approx. 240 g

Operation: -15 °C to +55 °C

Transducer principle

Ear coupling

Frequency response

Impedance

Power rating

Sensitivity

Max. sound pressure level

Limiter off

Max. sound pressure level

Limiter on

Ambient noise reduction

Distortion

Power supply /

consumption

Contact pressure

Headphone

dynamic, closed

circumaural

8 Hz – 18,000 Hz

64 Ω

500 mW

128 dB SPL @ 1 kHz

110 dB SPL @ 1 kHz 110 dB SPL @ 1 kHz

ANR on/off

–

600 Ω ANR on /

200 Ω ANR off

112 dB SPL / 1 Vrms / 1 kHz Limiter off 112 dB SPL / 1 Vrms / 1 kHz

ANR on, Limiter off

107 dB SPL / 1 Vrms / 1 kHz

ANR off, Limiter on/off

115 dB SPL @ 1 kHz ANR on

128 dB SPL @ 1 kHz ANR off

≤ 32 dB passive ANR off respectively

additonal ≤ 15 dB ANR on

< 0.1% @ 1 kHz, 100 dB SPL

approx. 3.3 N

– Phantom powered P12-P48

12 V – 48 V, ≤ 10 mA

HME 27 HMD 27 HMDC 27

2 Pull the headband carrefully apart.
