SEI HZ640500TX User manual

For assistance with assembly, contact:

Southern Enterprises Inc.

Customer Service 1-800-633-5096

[email protected]m

www.seifurniturestore.com

HZ640500TX

Adalyn Over-The-

Door Jewelry /

Makeup Storage

Assembly Instructions

Page 1

Adalyn Over-The-Door Jewelry / Makeup Storage

Parts List

Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded

surface like carpet or a blanket. Check that you have all parts indicated. Call customer service if any hardware is

missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the

pictures. Using the incorrect hardware will cause damage.

Quantity

of 1

Cabinet

Quantity

of 1

Back Rail

Quantity

of 2

Metal Hook

Quantity

of 1

Short Metal Cleat

Quantity

of 1

Long Metal Cleat

Quantity

of 2

Wood Stopper

Quantity

of 10

Bolt

∅

1/4”x1/2”L

Quantity

of 10

Short Screw

∅

1/8”x5/8”L

Quantity

of 4

Long Screw

∅

1/8”*1-3/4”L

Quantity

of 4

Wall Anchor

E Quantity

of 1

Level

Care and Cleaning Instructions:

Before using, wipe with a clean, dry cloth. Avoid rubbing or

scratching the surface with rough or abrasive objects.

For replacement parts or questions, please call SEI

customer service at 1-800-633-5096.

Assembly Tool Required No.2 Phillips

Screwdriver, Power Drill, Hammer (Not

Included)

Page 2

Figure 1

Over the Door:

Attach Metal Hooks (3) to Cabinet

(1) using Bolts (A).

Tighten Bolts (A) with Phillips

screwdriver (not included).

Figure 2

Hang the assembled unit over the

door.

Now your Adalyn Over-The-Door

Jewelry / Makeup Storage is ready

to use on door.

Adalyn Over-The-Door Jewelry / Makeup Storage

Assembly Instructions

Page 3

Figure 3

To change the height, return to

Step 1 and adjust the placement of

the hooks.

Figure

Wall Mount:

Take the assembled unit down from

the door.

Unscrew Bolts (A) with Phillips

screwdriver (not included).

Page 4

Figure 5

Attach Short Metal Cleat (4) to

Cabinet (1) using Short Screws

(B).

Tighten Short Screws (B) with

Phillips screwdriver (not included).

Figure 6

Attach Wood Stoppers (6) to

Cabinet (1) using Short Screws

(B).

Tighten Short Screws (B) with

Phillips screwdriver (not included).

Attach Back Rail (2) to Cabinet (1)

using Short Screws (B).

Tighten Short Screws (B) with

Phillips screwdriver (not included).

Page 5

Figure 7

Mark 4 locations on the wall,

matching 6 holes on Long Metal

Cleat (5).

Drill six 3/16" holes.

Insert Wall Anchors (D) into the six

holes on wall, tapping lightly with

hammer (not included) as needed.

Attach Long Metal Cleat (5) to wall

using Long Screws (C).

Tighten Long Screws (C) with

Phillips screwdriver (not included).

Figure 8

Lift Cabinet (1) and slide Cleats

together (4/5).

Page 6

Figure 9

Ensure unit is firmly mounted on

wall.

Use Level (E) on unit top to ensure

product is level.

Now your Adalyn Over-The-Door

Jewelry / Makeup Storage is ready

to use on wall.

Page 7

Please immediately examine this product carefully. Any request for missing parts or damage replacement

must be received within 90 days of your receipt of the product. Replacement, if available, will be honored

within this time frame.Parts will not be available for items arriving fully assembled. We do not recommend

modifying product(s) and we are not responsible for any damages due to product modification(s).

damages or missing parts are not reported within 90 days of your receipt, we are under no obligation to

provide parts or replacement merchandise.

Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri

Central time if you have product issues or email us at serv[email protected]. Please ask for customer service

representative for issues involving damages or replacement parts. Please ask for technical assistance

representative for any issues with product and assembly/construction.

Please contact the retailer that you purchased from for returns.

Customer Information

Name

Address

City/State/Zip Code

Phone Number

Please indicate where you purchased this item: Store/Website/Catalog

Please indicate color/size/style number:

Style No Parts Letter Parts Description Quantity Needed

Parts Replacement Form

Customer Service 1-800-633-5096

service@seidal.com

Southern Enterprises, Inc.

600 Freeport Parkway, Suite 200

Coppell, Texas 75019

Page 4

Page 8
