Please read this user manual prior to using this product.
Avoid installation in the following places: above 50℃ or under -10℃; places exposed to rain, snow, or high humidity;
places containing or exposed to oil or gas; places exposed to vibration or shock; places under direct sunlight or
exposed to outdoor weather conditions; places exposed to strong magnetic forces or high frequency (RF) or near
power lines.
Do not leave the device at any place where water might fall or splash. Also, do not put anything full of water such as
a flower vase on the device.
Do not use this device in close proximity to a device that produces strong waves such as radio set (Transceiver, Walkie-
talkie, etc.) or repeater. It may affect the image signal, or cause disorders such as noise or crack on the screen.
Do not disassemble or put foreign substances in the device.
When using the product, be careful with electric shock due to the electric shock hazard in the device.
Do not use the device above rated capacity. It may cause malfunction and fire.
Disconnect the power plug with care during thunder and lightning.
Check the power voltage of this product prior to installation.
Strong shock or vibration may cause device failure. Be careful when using the device.
If you keep using the device after noticing smoke or smell from the device, it may cause fire or electric shock. In such
cases, immediately remove the power cord and contact your place of purchase or our A/S center for professional
technical advice.
Check if the power cord is properly plugged in when the power is not on.
The transmission medium (CABLE) must be a coaxial cable.
Transmission distance may vary depending on the type of coaxial cable.
Be sure to check the specifications and instructions of this product prior to installation.
Refer to the user’s manual for problems or questions besides the above. Contact our service center if you need
assistance from a professional technician.
The joint part of the connecters must be insulated to prevent the metal part from exposure.
To extend or terminate the coaxial cables, you should connect them in the following way.
☞BNC-M(Male) - BNC-JJ - BNC-M(Male): BNC Connecter Connection Example (for HD-SDI)
