SCIFIT DC1000 Intelli-Fit User manual
Owner’s Manual
DC1000 Intelli-Fit Treadmill
SALES:
1-800-278-3933
CUSTOMER SERVICE:
1-800-745-1373
Order online 24/7 at www.SCIFIT.com
TM
This page purposely left blank
SCIFIT • Scientic Solutions for Fitness • SCIFIT • Scientic Solutions for Fitness • SCIFIT
Important Safety Instructions
Read all instructions before using your SCIFIT exercise machine!
Save these instructions!
Connect to a properly grounded outlet only. See Power Requirements
below. Also, always unplug this machine from the electrical outlet
immediately before cleaning and any servicing of the machine.
DANGER!
To minimize the risk of electric shock:
WARNING!
To reduce risk of burns, re, electric
shock, or injury to persons:
1. Close supervision is necessary when exercise machine is used
near children or disabled persons. Keep children away from
treadmill deck, especially when in operation.
2. Use the exercise machine only for its intended use as described
in this manual. Do not use attachments not recommended by
the manufacturer.
3. To make any adjustment during your workout, STOP the
machine and make the necessary adjustments.
4. Never operate the exercise machine if it has a damaged electrical
power cord or plug, if it is not working properly, or if it has been
damaged. Call the SCIFIT product support department for
further information about repair options.
5. Keep the electrical power cord away from heated surfaces, and
from the elevation mechanism.
6. Never operate the machine with the air openings blocked. Keep
the air openings free of lint, hair and other debris.
7. Never drop or insert any object into any opening.
8. Do not use outdoors.
9. Do not operate where aerosol (spray) products are being used
or in an oxygen rich environment.
10. To disconnect, turn o the power switch and unplug from the
wall outlet
SCIFIT • Scientic Solutions for Fitness • SCIFIT • Scientic Solutions for Fitness • SCIFIT
Important Safety Instructions
1. SCIFIT’s DC1000-INT(100-110V) treadmill requires a 110 Volt/ 15
AMP circuit. The circuit must have a minimum of 12 gauge wire.
Contact a qualied electrician to have one installed if needed.
Insucient power may cause your treadmill to function
improperly and will void the warranty.
2. DANGER: Improper connection of the equipment
grounding conductor can result in a risk of electric shock. Check
with a qualied electrician or serviceman if you are in doubt as
to whether the product is properly grounded. Do not modify
the plug provided with the product - if it will not t the outlet,
have a proper outlet installed by a qualied electrician
If you or your electrician have any questions, contact SCIFIT Product
Support at 1-800-745-1373.
Power Requirements – DC1000-INT (100-110V)
Figure A: Grounded Outlet Diagram
Plug grounding
pin
Grounded outlet
Introduction
Installation and Maintenance
Heart Rate Transmitter Strap
Keypad Functions
Program Descriptions
Troubleshooting
Warranty Policy and Service Procedures
Warranty card
1.1 to 1.2
2.1
3.1 to 3.16
4.1 to 4.2
5.1
6.1 to 6.2
7.1 to 7.5
8.1 to 8.2
9.1
10.1 to 10.5
11.1
Table of Contents
Set-Up Mode
Product Components
Specications
Assembly
12.1
SCIFIT • Scientic Solutions for Fitness • SCIFIT • Scientic Solutions for Fitness • SCIFIT
Thank you for your purchase of the SCIFIT treadmill. We have incorporated
the nest technology and ergonomic design into this machine to assist you
in achieving your tness goals. However, for your safety, please adhere to
the following recommendations before you begin to exercise.
FITKEY™
Warm Up and Cool Down
Exercise at Your Own Level
Stay Within Your Target Heart Rate Zone
CAUTION: When To Stop Exercising
Train Intelligently
Consult Your Physician
Introduction 1.1
Your SCIFIT treadmill may be equipped with a FITKEY receptical. Contact
SCIFIT to learn more about this exercise protocol and documentation
software.
Consult your physician or medical specialist before participating in any
exercise program, especially if you are pregnant, or if you are suering
from: heart disease, respiratory disease, diabetes, hypertension, high
blood pressure, elevated cholesterol, arthritis or any other diseases or
physical complaints.
To prevent muscle injuries and soreness, you should always warm up
(at least 5 minutes) and cool down (at least 5 minutes) by doing a series
of stretches before and after each workout.
Increase your exercise level gradually, and avoid sudden, erratic,
or careless exercise. The key to a successful exercise program is
consistency.
For healthy beginners, start exercising two to four days a week with
your heart rate in the target zone for about twenty (20) minutes each
day.
Your approximate maximum heart rate (MHR) is equal to 220 minus
your age. The upper limit of your target zone is equal to 0.85 times
your MHR. The lower limit of your target zone is equal to 0.60 times
your MHR.
For example, if you are 40 years old, your approximate MHR is equal to
180 (220 minus 40). Therefore, your target zone is between 60% of 180
(0.60 x 180) = 108, and 85% of 180 (0.85 x 180) = 153. So for a 40 year
old, the target heart rate zone is between 108 and 153.
Try to stay within the target heart rate zone to achieve optimal tness
training. Avoid exceeding your maximum target heart rate as this
may cause stress, fatigue, and/or injuries to your body. At the same
time, you need to sustain the intensity level of your exercise above the
minimum target heart rate in order to achieve
Stop exercising immediately if you feel nausea, dizziness, sharp pain,
or any other physical discomfort. Do not resume until you consult with
a physician.
To ensure a future of good health, you should always eat well balanced
meals, drink plenty of uid/water during a workout, and stay t by
exercising intelligently.
SCIFIT • Scientic Solutions for Fitness • SCIFIT • Scientic Solutions for Fitness • SCIFIT
Introduction 1.2
• The safest position is with your feet on each top side cover,
straddling the running belt. Step onto the running belt after
you have started the treadmill to prevent injury.
• To balance yourself look straight ahead and hold on to the
side handlebars or front handlebar.
• It is common to feel slightly dizzy after getting o the treadmill
after a workout. This is because the ground has been moving
under you. To help avoid this, turn the treadmill down to a
slow speed and cool down for several minutes before getting
o.
• A treadmill is not for children to play on. Use common sense
when operating this treadmill and observe all caution stickers.
• Keep hand and ngers away from all areas that could cause
injury such as the front and back rollers.
• Never place rear of the treadmill near an obstruction.
• Never put any substance underneath the treadmill running
belt
• Do not spill any liquid on the treadmill running belt.
• Maximum user weight is 375 lbs/ 170 kg.
The Emergency Stop Magnet/Clip
• To stop the treadmill quickly in emergency situations pull the
magnet from the Emergency Stop housing.
Attach the Emergency Stop Clip to your clothing, in the front
chest area, using the Grip Teeth (see Figure to left) before
beginning your workout. If you should fall or slip backward
during the workout, the magnet will pull away from the
Emergency Stop housing and the running belt will come to a
rest
Safe Use of Treadmill
Emergency Stop Magnet is
located on the front handlebar
MAGNET
CLIP
SCIFIT • Scientic Solutions for Fitness • SCIFIT • Scientic Solutions for Fitness • SCIFIT
Product Components 2.1
1. External components
2. Internal components
Water Bottle Holder
LCD Intelli-Fit Console
Contact Heart Rate
Emergency Stop
Magnet/Clip
Easy Grip L & R
Side Handlebars
Non-Skid
Side Covers
L & R End Caps with
Walkbelt Alignment
Bolt Access
Motor Cover
Adjustable
Rear Feet
Walkbelt
LH & RH
Uprights
Drive
Belt
Front Roller
& Pulley
3hp Motor
110V Actuator
110V Motor
Controller Board
On/O
Power Switch
Thermal Fuse
AC Inlet
Transformer
Speed Sensor
Assembly
PARTS LIST
Please make sure all parts below are in the box before assembly.
Order online 24/7 at www.SCIFIT.com
NO
C
MAIN UNIT WITH MOTOR COVER
UPRIGHT WELDMENT ASSEMBLY
CONSOLE
SIDE HAND RAILS
POWER CORD
M5 x 12mm
Screw (Qty. 4) Console
CONSOLE MOUNT WELDMENT
3.1
PARTS LIST CONT’D
Please make sure all parts below are in the box before assembly.
Order online 24/7 at www.SCIFIT.com
MAGNET/CLIP LOWER SIDE RAIL COVERS
2-WIRE E-STOP CABLE
EXTENSION
4-WIRE CHR CABLE
EXTENSION
10-WIRE MAIN CABLE
EXTENSION
Assembly 3.2
