Saxby Lighting 75270 Manual

• Thissystemcontainsnon-replaceablepartsandcannotbeserviced.Ifdamageoccursthepartshould

bescrapped.

Instructionleaflet

Sentinel Battery PIR Wall Light

www.saxbylighting.com

Foryoursafety,alwaysswitchoffthesupplybeforecleaning.

Wasteelectricalproductsshouldnotbedisposedofwithhouseholdwaste.Pleaserecyclewherefacilities

exist.CheckwithyourLocalAuthorityorretailerforrecyclingadvice.

Recycling advice

Safety information

SaxbyLightingLtd.BH233PE

Werecommendcleaningwithasoftdrycloth.

Donotusesolventsorabrasivecleanersasthesecoulddamagethefinish.

Fitting/replacing bulbs

Iss.121062018

75270

PIR Adjustment

• Theunitmustbeinstalledinavertical position, and

fittedbetween1.8mand2.5mabovetheground.

• The PIR sensor can be adjusted, allowing the

detection distance to be altered to suit the location.

The detection angle is set at 180 degrees. The

durationthat thelamp stayson canbe alteredfrom

10±5 seconds to 60±10 seconds. The detection

distance "SENS" can be adjusted up to 10m Use a

small screwdriver to adjust the ‘TIME’ and ‘SENS’

screws. When adjusting the sensitivity (detection

distance)indaylightitwillbenecessarytocoverthe

sensortosimulatenighttime.

Detection range can be adjusted

by turning 'SENS' screw

Adjustable up to 10 metres

Duration the bulb stays on is

adjustable by turning 'TIME' screw

The sensor trigger point is adjust-

able by turning the ‘LUX’ screw.

Base of product

Thankyouforpurchasingthislightfitting.Pleasereadtheinstructionscarefullybeforeusetoensuresafeand

satisfactoryoperationofthisproduct.Pleaseretaintheseinstructionsforfuturereference.

Warning

Thisunitcannotbedimmed.

Thisproductcontainsnon-replaceablepartsand

cannotbeserviced.Ifdamageoccurstheproduct

shouldbescrapped.

Wasteelectricalproductsshouldnotbedisposedof

withhouseholdwaste.Pleaserecyclewherefacilities

exist.Checkwithyourlocalauthorityorretailerfor

recyclingadvice.

ThisproductisratedatIP44.

Thisproductisnotsuitableforlocationinorneara

marineenvironment.

Battery Care:-

- Donotrechargenon-rechargeablebatteries.

-Donotmixoldandnewbatteriesorbatteriesof

differenttypes/brands.

-Donotuserechargeablebatteries.Alwaysremove

exhaustedbatteriesfromtheproduct.

-Alwaysinsertbatterieswiththecorrectpolarity.

-Donotshortthesupplyterminals.

-Thisproductissuitableforusebyadultsonly.

Specification

Voltage: 6V

Lamp: 2x2WLEDModule

IPrating: 44

BatteryType: 4x1.5VAA(notsupplied).

Layout

• Avoidmountingonsurfacessubjecttovibration,as

thismayaffectthePIRsensor.

• Toavoiddamagetotheunit,donotaimthesensor

towardsthesunorareasofstrongelectro-magnetic

disturbances.

• Toavoidnuisancetriggering,thesensorshouldbe

aimedawayfromheatsources,suchasBBQ’s,

Air-Conditioners,otheroutsidelighting,movingcars

andflueventsorreflectivesurfacessuchassmooth

whitewallsorswimmingpools.

• Whenselectinglocation,itisadvisabletonotethat

movementacrossthesensorsfieldismoreeffective

thantowards/awayfromit..

• Decideontheoptimumlocationfortheproduct.Ensurethewalliscapableofholdingtheweightoftheproduct.

• Placetheproductinanuprightposition.

• Detachthewallbackbyremovingthescrewfromthebottomoftheproduct.Setscrewasideforrefittinglater

(Fig.1).

•.Pushbuttonontopofproductandremovewallback(Fig.1).

•.Usingthewallbackasatemplate,markanddrillthepositionofthefixingholes.

• Fixthewallbacktothewallusingthescrewsandwallplugs.Takecaretoavoiddamaginganyconcealed

wiringandpipes.Thecorrectfixingsshouldbeusedforbrickorcavitywalls.

• Removethebatterycasecoverandfitthebatteries.Ensurethe"BatteryCare"warningsonthepreviouspage

arefollowed(Fig.2).

• RefitthebatterycasecoverandthenRefitthescrewssetasideearliersecureinplace.

• SwitchontheproductusingthepushswitchonthefrontoftheproductandadjustthePIRsensorasdetailed

overleaf.Pleasenotethesensorrotatesforeasyaccesstothecontrols.Linethewhitedotsupatthefrontof

theproducttoensurethecorrectorientation.

• Gentlyrotatetheangleoftheshadesbyhandto     

yourpreferredposition.

• Yourlightisnowreadyforuse.

Installation

Fig. 1

Fig. 2

Push
