Saregama CARVAAN User manual
USER MANUAL
BUTTONS & PORTS ON SAREGAMA CARVAAN
The battery charging indicator will display:
a. Red light when Carvaan is being charged
b. Green light when Carvaan is fully charged
To choose a mode, press the corresponding mode
button on the unit/ remote
1. SAREGAMA: 5000 pre-loaded evergreen
songs categorized into Artistes, Moods & Tagore;
this is the default mode on first power on/reset
2. USB / AUX IN: Plug in a USB into the USB
port on Carvaan to enjoy your personal collection
of songs. You can also connect an Aux cable in
the Aux IN port on the back panel of Carvaan to
play songs from your phone/tablet. Press the
mode button to switch between USB and Aux In
3. FM/AM : Listen to local FM/AM stations.
Press the mode button to switch between FM and
AM
FM frequency: 87.5 to 108 MHZ
AM frequency: 520 to 1710 KHZ
Note: We recommend that you do not put the unit on charge while
listening to FM/AM as it will interrupt the signal
4. BLUETOOTH : Pair your mobile phone /
tablet with Carvaan. Enjoy songs stored on your
personal device on Carvaan speakers
battery charging
indicator
power
SAREGAMA
USB / AUX IN
FM/AM
BLUETOOTH
modes
USB / AUX IN
FM/AM
3.5 mm audio
jack for connecting
external
speakers/
headphones
volume
*support for USB 2.0
**AM station will play as per broadcast timings
***support for BT version 4.1
Full battery charge time: 2-3 hours;
Battery usage: Approximately 5 hours once the
battery is fully charged
ARTISTES MOODS TAGORE
Hemanta Mukherjee
MUCHHE JAOA DIN GULI
Voltage: 220V
Frequency: 50 Hz for input
and 5V 1A for output
External Antenna:
Insert the antenna into the AUX IN
port for improved reception of local
FM stations
ARTISTES MOODS TAGORE
Hemanta Mukherjee
MUCHHE JAOA DIN GULI
categories
go to
previous/next song
station name
battery
song marked
as favourite
song name
turn left/right to move
across stations
USB port
AUX In
charging
port
reset to
factory settings
AUX IN
SAREGAMA CARVAAN APP
Download the ‘Saregama Carvaan’ app from
the Apple / Android store to enjoy a host of
free and subscription based services.
Free services – Use the app to find a song,
create playlists to playout on your Carvaan
unit.
Note: To use the app, press the ‘Saregama mode’ button
on Carvaan. Connect the app & Carvaan using Bluetooth
on your phone/tablet.
Subscription services - Subscribe to the
app and listen to the songs on your
phone/tablet without being connected to
the Carvaan unit
Refer to the enclosed insert for steps on
how to connect the app and Carvaan unit.
Choose a category in Saregama Mode
1. Artistes: 20+ music stations dedicated to Bengali &
Hindi film legends like Hemanta Mukherjee, Manna Dey,
Arati Mukherjee, Kazi Nazrul Islam, Kishore Kumar, Lata
Mangeshkar and many more
2. Moods: 4 music stations viz Romance, Sentimental,
Devotional & Folk
3. Tagore: 4 stations dedicated to Tagore songs viz Puja,
Prem, Prakriti and Bichitro
Choose your preferred category in Saregama mode
Saregama mode
decrease volume
increase volume
favourite
next song
play/pause
previous song
previous station
next station
USB / AUX IN
mode
FM/AM mode
BT mode
Waste electrical products should
not be disposed of with household
waste. Please follow disposal and recycling
instructions issued by the concerned local
authority.
SAFETY HANDLING
1. CARE FOR PRODUCT
a. Keep Carvaan away from dust and excessive
heat (heat registers, stoves etc.)
b. Prevent spillage of water or any other liquid
as this can cause failure of Carvaan or could
prove to be a potential fire hazard
c. Clean the unit with a dry cloth only
d. Do not walk on or pinch the power cord
close to the plug
e. Do not immerse Carvaan or the remote into
water
f. Remove the remote battery when it is not
used for longer duration
g. Do not mix different brands or types of
batteries in the remote
2. CARE FOR BATTERY
a. Do not expose the battery to heat
sources greater than 60°C
b. Recycle or dispose the battery when
essential. Please ensure proper battery
handling and disposal methods
c. Do not subject the battery pack to a
mechanical shock
To replace the remote control battery:
1. Open the battery compartment
2. Insert a fresh CR2025 battery
with the correct polarity (-/+)
3. Close the battery compartment
4. Discard the used battery
d. In the event of a battery leak, do not allow
the liquid to come in contact with the skin or
eyes. If contact has been made, wash the
affected area with water and seek medical
advice
e. For prolonging battery life, avoid
discharging the battery completely
f. To ensure optimum battery condition, the
unit should be charged for atleast 8 hours,
once a month.
Note: if the unit is unused for a month or more,
battery will get completely discharged
3. OTHERS
a. Use attachments/accessories as specified
by the manufacturer
b. Please contact an authorized service
center for any repair/ servicing requirements
or call the toll free no. 1800-102-7799
MOODS TAGORE
WARRANTY TYPE
Home service and carry in warranty are
provided.
Home service warranty requires
customers to have a technician visit their
home and service the product. This type
of warranty can be availed by customers
living in locations where there is an
authorized service center. The list of
authorized service centers is available on
www.saregama.com/carvaan/2018/
service-center
Carry-in Warranty service requires that
the Product be brought by the Customer,
at his/her sole cost and responsibility, to
the Authorized Dealers along with the
original invoice.
Once the Product is serviced/ repaired/
replaced, the Customer shall be
responsible to pick-up the Product from
the concerned Authorized Dealer.
IMPORTANT LINKS
Station List & Song List:
www.saregama.com/carvaan/2018/songlist
Detailed Warranty:
www.saregama.com/carvaan/2018/warranty
Download the “Saregama Carvaan” app from
the Apple/ Android store.
WARRANTY CARD
Customer’s Signature
Customer’s Name:
Customer’s Address:
Product Serial No.:
Date of Purchase:
Expiry Date:
I accept the terms and conditions of the
warranty.
Retailer’s Name:
Retailer’s Signature/Seal:
WARRANTY OVERVIEW
Carvaan comes with a 1 year Warranty on
all parts, excluding accessories. This
includes servicing/ repair or replacement
of damaged parts.
The warranty does not apply and does
not cover the following:
• Liability for loss of data/content
loaded in the product due to misuse or
tampering.
• Damage caused due to force majeure
events; events caused by fire, water,
electrical disturbances etc.; events
beyond the control of Saregama; acts of
negligence or mishandling; usage for
commercial, business, industrial,
educational or rental purposes
