Sanyo HR-4UC Twicell User manual

Size : AAA

650mAh

600mAh

1.2V

Fast Charge 2) 650 mA x about 1.1h

Charge

Condition Fast Charge 2) 0°C - 40°C

0°C - 50°C

Less than

30days -20°C - 50°C

Less than

90days -20°C - 40°C

Less than

1year -20°C - 30°C

About 13 g

10.5(D) x 44.5(H) mm

pical Characteristics

Charge Discharge

1)Single cell capacity under the following condition.

Dimensions

(with tube)

Specifications

Cell T

pe HR-4UC

Charge : 65mA×16h, Discharge : 130mA(E.V.=1.0V) at 20°C

Nominal Voltage

Discharge Condition

Weight 4)

Size 4) :(Diameter) x (Height)

Type : Nickel-Metal Hydride Battery

Internal Impedance 3)

(after discharge to E.V.=1.0V)

Charging Current x Time

10.5 mm

44.5 mm 2)Use recommended charging system.

3)After a few charge and discharge cycles under the above 1) condition.

4)With tube.

44.5 mm

Ambient Temp.

Storage

Condition

10.5 mm

Capacity 1)

Typical

Minimum

0.9

1.0

1.1

1.2

1.3

1.4

1.5

1.6

0 100 200 300 400 500 600 700

Discharge Capacity (mAh)

Cell Voltage (V)

Charge : 65mA x 16h

Rest : 1h

Discharge : 130mA, 650mA, 1300mA (E.V.=1.0V)

Ambient Temp. : 20°C

130mA

650mA

1300mA

1.0

1.1

1.2

1.3

1.4

1.5

1.6

1.7

1.8

0 1020304050607080

Charge Time (min)

Cell Voltage (V)

Charge : 650mA (-∆V=10mV)

Ambient Temp. : 0°C,20°C,40°C

0°C

20°C

40°C

About 40mΩ(at 1000Hz)
