Sanyo CR17335 User manual

Cell Type CR17335

Specifications

Typical Characteristics

1400mAh

3V

10mA

1500mA

3500mA

-40

℃～

60

℃

16g

D 17.0mm

H 33.8mm

d6.3mm

Dimensions

Nominal Capacity*1

Nominal Voltage

Standard Discharge Current

Weight

Max. Discharge Current

Temperature Range

Continuous*2

Pulse*3

Nominal capacity is determined to an end voltage of 2.0V when the battery is

allowed to discharge at a standard current level at 23oC.

*1

Current value is determined to be the level at which 50% of the nominal

capacity is obtained with an end voltage of 2.0V at 23 oC.

*2

Current value for obtaining 1.0V cell voltage when pulse is applied for

15seconds at 50% discharge depth at 23 oC.

*3

Discharge Characteristics of CR17335

Cell Voltage(V)

Number of Cycles

Cell Voltage(V)

Number of Cycles

Pulse Discharge Characteristics of CR17335

Pulse Discharge Characteristics of CR17335

Cell Voltage(V)

Duration(hour)

0

200

400

600

800

1000

1200

1400

1600

1800

1.0

1.5

2.0

2.5

3.0

3.5

Pulse: 1.2A*3s on/7s off

Initial

23 oC

-20 oC

0

200

400

600

800

1000

1200

1400

1600

1800

2000

1.0

1.5

2.0

2.5

3.0

3.5

Pulse: 0.9A*3s on/27s off

Initial

23 oC

-20 oC

0

10

20

30

40

50

60

70

80

90

100

110

120

130

140

1.0

1.5

2.0

2.5

3.0

3.5

Load: 200ohm

Temp.: 23 oC

Initial

D

H

d
