Samsung WF331ANW/XAA Manual

WASHING MACHINE

Technical Information

Code No. : DC68-02834A-03_EN

• Due to possibility of personal injury or property damage, always contact an authorized

technician for servicing or repair of this unit.

• Refer to Service Manual for detailed installation, operating, testing, troubleshooting, and

disassembly instructions.

All safety information must be followed as provided in Service Manual.

CAUTION

To avoid risk of electrical shock, personal injury or death; disconnect power to washer

before servicing, unless testing requires power.

WARNING

Techsheet-WF350AN-02834A-03_EN.indd 1 2011-09-28 �� 4:00:29

ALIGNMENT AND ADJUSTMENTS

GENERAL ERROR FUNCTION

NO Error

Code

Diagnostic Code

Error Image Description Corrective Action

1 nd 1

The water level fails to drop below

the Reset Water Level within 15

minutes.

Go to “ Will Not Drain”

Troubleshooting Section.

2 LO 2 Door fails to Unlock After 7

attempts.

Go to “ Will Not Unlock”

Troubleshooting Section.

3 nF 3

When the lling Continues for

more than 40 minutes or there is no

change of water level for 6 minutes.

Go to “ No Water Fill”

Troubleshooting Section.

4 FL 4 Door fails to lock after 7 attempts. Go to “ Will Not Lock”

Troubleshooting Section.

5 LE 8

A water level lower than the Reset

water level (25.6Khz) is detected for

5 seconds during the Wash/Rinse

cycle.

Go to “No Water Fill”

Troubleshooting Section.

6 LE 8

Water Level Sensor Trouble. (When

the input signal from the water level

sensor is out of range, the unit will

send out beeping sounds and halts

the cycle.)

Go to “No Water Fill”

Troubleshooting Section

7 OE E

A fault is detected in the water level

sensor. Data (frequency) shows

the water level is at or above the

overow water level. (When this

condition is detected, the machine

will automatically starts draining

water until the water level falls

below the overow water level)

First check to see that all of water

valves are not stuck. If water valves

are OK, check water level sensor.

8 dc 10

Unbalance or cabinet bump is

detected during nal spin, which

prevents the drum from spinning

over 150 rpm. (Never exceeds 150

RPM due to unbalanced load)

Go to “Wet Clothes” Troubleshooting

Section.

9 E2 15

Jammed Key.(When key input

signals are coming out for more

than 30 seconds, it is regarded as

a jam.)

Check all of keys. If A key is sensed

to be pressed, all keys will do not

respond.

10 dL 18 Door is detected as open when the

motor is operating.

Check for loose wire connections. Go

to “Quick Test Mode” and then do Door

lock/Unlock Test and Motor Test.

To avoid risk of electrical shock, personal injury or death; disconnect power to washer

before servicing, unless testing requires power.

WARNING

Techsheet-WF350AN-02834A-03_EN.indd 2 2011-09-28 �� 4:00:29

ALIGNMENT AND ADJUSTMENTS

NO error

code

Diagnostic Code

Error Image Description Corrective Action

11 ds 22 Door is detected as open while it is

trying to lock the door.

Go to “Quick Test Mode” and then

do Door Lock/Unlock Test

12 tE 29

Abnormal high/low temperature or

resistance (Thermal sensor or PBA

resistance).

Go to “ Board Input Test” and check

Water Temperature. Check loose

or pinched wires. Replace PCB or

thermistor.

13 3E 2E

MICOM is attempting to drive the motor

but is not getting any response signals

from the hall sensor. Visual check shows

motor is not running. (Locked, Defective

Hall Sensor or Overload)

Evaluate wire harness for loose or

unhooked connections. Go to “

Quick Test Mode” and test Motor.

14 Sr 34

System Relay (Main Relay) Failure.

(PCB does not notice the relay

operation when there should be.)

Replace PCB.

15 Hr 36 Heater Relay Failure (No Heater

Relay Check Signal) Replace PCB

16 nF1 5 The hot/cold water hose connection

is not correct.

Please connect the hot/cold water

hose connection correctly.

17 2E - Voltage for motor control bus is

over or under specied limit. Replace PCB

18 7E - Silver Care Kit (PCB) Failure. Check PCB ,Main PCB & Wire-

harness

19 suds -

Suds is detected during the washing

session. (“SUdS” is not an error. If the

washer is in suds period, “SUdS” will

light up instead of remaining time.)

Guide a user to reduce amount of

detergent usage.

20 AE -

Communication error between SUB

PBA and MAIN PBA

Check Main PBA, SUB PBA & Wire-

harness. Replace PCB

SF1,

SF2,

SF3

-System Error Replace PCB

To avoid risk of electrical shock, personal injury or death; disconnect power to washer

before servicing, unless testing requires power.

WARNING

Techsheet-WF350AN-02834A-03_EN.indd 3 2011-09-28 �� 4:00:29

ALIGNMENT AND ADJUSTMENTS

TEST MODE

Test Mode:

Each Test Mode for the Squall is as follows in the

coming pages. The test modes indicated by the

red arrows are modes unable to get an access

once the washing cycle has started due to safety

resons.

Quick Test Mode

Denition of Quick Test Mode:

- Check operation of all LED’s (Verify faulty LED).

- Check model and software version.

- Check dierent operating modes (e.g. water valve, motor, door, drain pump, etc.).

How to Enter:

- Plug in the unit.

- Press Soil Level Key + Signal Key and Power Key at the same Time.

Important. Once test mode is performed, all data including the diagnostic code saved in the

EEPROM will be erased.

To avoid risk of electrical shock, personal injury or death; disconnect power to washer

before servicing, unless testing requires power.

WARNING

Special Test Mode

Power Off State

Quick Test Mode

EEPROM Clear

Mode

Continuous Cycle

Mode

Service Mode

Demo Mode

Quick Spin Test Mode

Cycle Count Check Mode

S/W Version Check Mode

Fast Time Down Test Mode

Board Input Test Mode

Diagnostic Code

CheckMode

Power On State

(Normal User Mode)

Techsheet-WF350AN-02834A-03_EN.indd 4 2011-09-28 �� 4:00:29

ALIGNMENT AND ADJUSTMENTS

Quick Test Mode:

1. All LED’s light up and it sends out Beep Sound when it

enters into the Quick Test Mode. (Including 7-Segment)

2. Displays software version for a sec and Clear EEprom. (Ex. If

S/W Version is 49, 7-Segment will display E149)

3. When the version is displayed, turn the Jog-Dial so that

the version disappears. Press the following keys to test the

various components.

- Temp Key : Water Valve Test

- Spin Key : Door Lock/Unlock Test

- Soil Key : Water/Steam Heater Test(Steam Models)

Water Test(Non-Steam Models)

- Signal Key : Drain Pump Test

To avoid risk of electrical shock, personal injury or death; disconnect power to washer

before servicing, unless testing requires power.

WARNING

Techsheet-WF350AN-02834A-03_EN.indd 5 2011-09-28 �� 4:00:29

ALIGNMENT AND ADJUSTMENTS

EEPROM Clear Check

Denition of EEPROM Clear Mode:

- EEPROM initialization.

- All course/option settings are to be reset to default values

after EEPROM initialization.

- When Service arises and it needs PCB replacement,

EEPROM should be reset.

How to Enter:

- The unit needs to be on.

Press Delay Start Key, Signal Key, and Power Key at the same time.

Continuous Run Mode

Denition of Continuous Run Mode:

- Will continuously repeat the current cycle until the Continuous Run Mode is cancelled.

How to Enter:

- Press Pre Wash Key and Pure Cycle Key together for 3 sec.

Continuous Run Mode:

1. Press

Pre Wash + Pure Cycle 3 sec

during Power On State (Normal User Mode) .

Once in Continuous Run Mode, The seven segments will no longer display “0000” and will alternate

between displaying the number of cycles of the completed course and the remaining time of the course.

3. The Continuous Run Mode will repeat the previous cycle until continuous run mode is cancelled.

During Continuous Run Mode, press Pre Wash + Pure Cycle 3 seconds to return to normal user

mode. The seven segments will no longer display the number of cycles and will display the

maintenance time only.

5. If you exit Service Mode after entering it from Continuous Mode, the washing machine returns

to Continuous Mode.

6. If power is lost in Continuous Run Mode (that is, when the power plug is disconnected or the

Power key is pressed turning the washing machine o), the mode is released when the washing

machine is turned on again.

To avoid risk of electrical shock, personal injury or death; disconnect power to washer

before servicing, unless testing requires power.

WARNING

Techsheet-WF350AN-02834A-03_EN.indd 6 2011-09-28 �� 4:00:30

ALIGNMENT AND ADJUSTMENTS

Service Mode

Denition of Service Mode:

- Service Mode enables service technicians to verify the operation of the washing machine and

do troubleshooting.

- Service Mode can be entered during all washing cycle without interrupting the cycle except

some of test modes.

- Various tests can be done with Service Mode. So, troubleshooting can be done based on the

resulting diagnostic codes.

How to Enter:

- To enter the Service Mode, press the Signal and Delay Start Keys for 3 seconds or until the unit

sends out beeping sounds.

Service Mode:

1. The washer must be on to go into the Service Mode.

2. The motor speed will be displayed when started (It displays 0 when the motor does not spin).

3. The present state of the machine will not be changed.

(i.e., the current cycle in progress will not be interrupted and only the display will change)

4. To exit Service Mode, press Signal and Delay Start Keys for 3 second again, or Power Key.If no key

is operated during Service Mode for 5 minutes, the machine will return to normal user mode.

To avoid risk of electrical shock, personal injury or death; disconnect power to washer

before servicing, unless testing requires power.

WARNING

Techsheet-WF350AN-02834A-03_EN.indd 7 2011-09-28 �� 4:00:30

ALIGNMENT AND ADJUSTMENTS

Quick Spin Test Mode

Denition of Quick Spin Test Mode:

- Quick Spin Test Mode is to do Spin Check. (High RPM)

How to Enter:

- During Service Mode, press the Dealy Start and Pre Wash Keys for 3 seconds to enter Quick Spin

Test Mode. (Same for all Frontier 2 models.)

- Cannot enter once the washing cycle has started.

Quick Spin Test Mode:

As it enters into the Quick Spin Test Mode, it starts spinning and reaches to its maximum RPM.

Once the Spin speed reaches the maximum RPM, the speed drops immediately.

To hold Quick Spin Test Mode (entering Hold Speed Mode), press the Start/Pause button. If the

Start/Pause button is pressed during Quick Spin Test Mode, it will stop accelerating and hold its

spinning speed for 10 minutes before going back to Quick Spin Test Mode.

Also, to cancel the hold and allow Quick Spin Test Mode to continue, press the Dealy Start and Pre

Wash Keys together for 3 seconds.

If you hold down the Dealy Start and Pre Wash keys for three (3) seconds when the washing

machine is not in Hold Speed Mode, Quick Spin Mode is exited and Service Mode is restored.

To avoid risk of electrical shock, personal injury or death; disconnect power to washer

before servicing, unless testing requires power.

WARNING

Techsheet-WF350AN-02834A-03_EN.indd 8 2011-09-28 �� 4:00:30

ALIGNMENT AND ADJUSTMENTS

Cycle Count Check Mode

Denition of Cycle Count Check Mode:

- Cycle Count Check Mode is to tally up the number of washings.

How to Enter:

- To enter the Cycle Count Check Mode, press the Signal Key during Service Mode.

Cycle Count Check Mode:

1. Activate the Service Mode in advance.

2. When the Signal key is pressed, the total number of washings will light up and a signal LED will

glow.

3. The maximum number of cycles will be 9999.

The counter will roll over to 0 and start counting again after 9999.

4. The counting will be carried out at the end of the normal cycle.

(For normal and Continuous Run cycles, the count is carried out at the end of the cycles.

5. To exit the Cycle Count Check Mode, press the “Signal” key again.

S/W Version Check Mode

Denition of S/W Version Check Mode:

- S/W Version Check Mode is to bring up S/W Version information.

How to Enter:

- To enter the S/W Version Check Mode, press the Soil Level Key during Service Mode.

S/W Version Check Mode:

1. Activate the Service Mode in advance.

2. Press the Soil Level Key to bring up its software Version

EX) Generate AE49 at Version 49 (AE is Micom code, 49 is it’s software version)

3. To exit the S/W Version Check Mode, press the Soil Level S/W once again.

Then, it returns to the Service Mode with motor RPM illuminating.

To avoid risk of electrical shock, personal injury or death; disconnect power to washer

before servicing, unless testing requires power.

WARNING

Techsheet-WF350AN-02834A-03_EN.indd 9 2011-09-28 �� 4:00:31

ALIGNMENT AND ADJUSTMENTS

Fast Time Down Test Mode

Denition of Fast Time Down Test Mode:

- Fast Time Down Test Mode is to forward the program to the next cycle stage.

How to Enter:

- To enter the Fast Time Down Test Mode, press the Temp key during Service Mode.

Fast Time Down Test Mode:

1. Activate the Service Mode in advance.

2. To forward the program to the next cycle stage, press the Temp key.

Each stage is located at key points of a complete cycle as follows:

- End of Each Fill (Beginning of Wash or Rinse Tumble Session)

Caution: Check if the current water level is higher than the Reset water level and then perform

the Fast time down test.

- Beginning of Drain Session

- Beginning of Spin Session (Here, it checks the water level. So, if it is over the reset level, it carries

out draining before the spinning.)

- Beginning of Fill Session

- Beginning of Bleach Fill

- Beginning of Fabric Softener Fill

- Every 3 minutes during Wash and Rinse Tumble Session

To avoid risk of electrical shock, personal injury or death; disconnect power to washer

before servicing, unless testing requires power.

WARNING

Techsheet-WF350AN-02834A-03_EN.indd 10 2011-09-28 �� 4:00:31

Other manuals for WF331ANW/XAA

Table of contents

Languages:

Other Samsung Washer manuals

Samsung

Samsung WD9 T4 Series User manual

Samsung

Samsung WF218ANB User manual

Samsung

Samsung M1001 User manual

Samsung

Samsung WF804P4SA Series User manual

Samsung

Samsung WF-F1256 User manual

Samsung

Samsung WA70B3 User manual

Samsung

Samsung WF7602NAW Instructions for use

Samsung

Samsung WA45T3400A User manual

Samsung

Samsung WA70H4210S Series User manual

Samsung

Samsung WA14R6380B Series User manual

Samsung

Samsung WF8694AH(A/C/D/F/G/H/R/S/T/V/W/Z)(U) User manual

Samsung

Samsung WA95W9 User manual

Samsung

Samsung WA70R3 User manual

Samsung

Samsung WF6704N1 User manual

Samsung

Samsung WF8602SEA User manual

Samsung

Samsung WA10F5S2 User manual

Samsung

Samsung P1405J User manual

Samsung

Samsung WE357A7W User manual

Samsung

Samsung WF3784YPV/XEG Instructions for use

Samsung

Samsung WA75H4 Series User manual

Samsung

Samsung WF36J4 Series User manual

Samsung

Samsung WF328AAW/XAA-0000 User manual

Samsung

Samsung WA10K9 User manual

Samsung

Samsung WF405ATPASU/A2 User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
