Samsung WF231AN User manual

** Samsung received the highest numerical score for clothes washers (2009-2010) and dryers (2008-2010) in the proprietary J.D. Power and

Associates Laundry Appliance StudiesSM. 2010 study based on 10,344 total responses measuring 17 brands and measures opinions of

consumers who purchased their washer or dryer from a retail store or their new-home builder during the previous 24 months. Proprietary study

results are based on experiences and perceptions of consumers surveyed in March-April 2010. Your experiences may vary. Visit jdpower.com.

Available Colors

Features

∙3.5 cu. ft. Capacity*

∙VRT TM – Quiet Operation, Perfect for

2nd Floor Installation

∙PureCycleTM – A Washer that

Cleans Itself

∙Direct Drive Motor

∙1100 RPM Maximum Spin Speed

∙Internal Water Heater

∙9 Preset Wash Cycles

∙3 Options

Convenience

∙Add A Garment Option

∙Child Lock

∙End-Of-Cycle Signal (On / Off)

∙Delay Start – Up to 24 Hours

∙Automatic Dispensers:

Main Wash, Bleach,

Fabric Softener

∙Optional Pedestals or Stacking

Kit Available

Energy Star Rated:

Rated CEE Tier 3: Most Efﬁcient

MEF=2.8

WF=3.2

100 kWh / year

Signature Features

VRT™

Vibration Reduction Technology

Virtually silent washing thanks to special

sensors that keep the drum perfectly

balanced even at high spin speeds.

PureCycle™

A washer that cleans itself

Clean your drum with the touch of a

button to ensure a fresh, clean drum

without detergent.

Sanitize Cycle

Peace of mind with NSF®certiﬁed

sanitization cycle. Eliminates 99.9%

of household germs from laundry.

Neat White

WF231ANW

3.5 cu. ft. High Efciency VRTTM Front Load Washer

(Shown with optional pedestal) 3 Options

9 Cycles

Ranked “Highest in Customer

Satisfaction with Clothes

Washers” by J.D. Power and

Associates.**

* 3.45 cu. ft. measured as per Department of Energy

Actual color may vary. Design, speciﬁcations, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.

Fabric Care

9 Preset Wash Cycles

Normal, Heavy Duty, Permanent Press,

Sanitize, Bedding, Delicates, Wool, Quick Wash,

Rinse and Spin

3 Options

PureCycle™, Delay Start-Up to 19 Hours,

Extra Rinse

4 Temperature Settings

Hot / Cold, Eco Warm / Cold, Warm / Cold,

Cold / Cold

4 Spin Speeds

High, Medium, Low, No Spin

4 Soil Levels

Heavy, Normal, Medium, Light

2 Signal Sound Levels:

On, Off

Accessories:

Stacking Kit: SK-5A

Pedestal: WE357A0W

Warranty

One (1) Year All Parts and Labor

Two (2) Years Control Board

Three (3) Years Stainless Steel Tub

Ten (10) Years Motor

Product Dimensions + Weight

Dimensions: (WxHxD) 27" x 38 1⁄4" x 31 3⁄4"

Weight: 182.8 lbs / 83 kg

Shipping Dimensions + Weight

Dimensions: (WxHxD) 29 3⁄4" x 42 3⁄4" x 33 1⁄2"

Weight: 200.4 lbs / 91 kg

Installing your washer

Required Dimensions for Installation With Pedestal Required Dimensions for Installation

With Stacking Kit

* Required spacing ** External exhaust elbow requires additional space.

Minimum clearances

for closets and alcove:

Sides - 1 In.(2.5 cm)

Top - 17 In.(43.2 cm)

Rear - 4 In. (10.2 cm)

Closet Front - 2 In. (5.1 cm)

If the washer and dryer are

installed together, the closet

front must have at least a 72 in²

(465cm²) unobstructed air

opening. Your washer alone does

not require a speciﬁc air opening.

1" 27"

Recessed Area

2" 4"

31 3/4"

17"

Side View Confined

27"

38 1/4"

53"

Closet or Door

48"² *

24"² *

1" 35 1/4" 5 1/2"**

2 1/2"

1" 27"

76 1/2"

6" *

31 3/4"

50 13/16" to clear open door

2. With optional pedestal base or stacking kit

1. Alcove or closet installation

Installation Options:

Stacked Side by Side On Pedestals Stacked Depth

(38 2⁄8”)

WF231ANW

3.5 cu. ft. High Efciency VRTTM Front Load Washer

Color Model # UPC Code

Neat White WF231ANW 036725570047

Matching Dryer (Electric/Gas)

Neat White DV231AEW 036725570054

Neat White DV231AGW 036725570061
