Samsung SR10J50 Series User manual

Robot vacuum cleaner

User manual

SR10J50✴✴✴ Series

• Beforeoperatingthisunit,pleasereadtheinstructionscarefully.

• Forindooruseonly.

VR5000_EN_00734A-00.indd 1 2015-02-27 오후 5:53:56

Installation

Powerofthechargermustbeonatalltimes.

Installitinaplacewithout

obstaclesanddangeroffalling.

NOTE

• Installthechargerinaplacewheretheoorandwallarelevel.

• Installthechargeralongthegrainofwoodenoors.

• Ifthepowerswitchisoff,therobotvacuumcleanerwillnotchargeevenifitisdocked

onthecharger.

• Alwaysturnonthepowerofthecharger.

–Ifpowerisnotsuppliedtothecharger,therobotvacuumcleanercannotnditand

cannotautomaticallyrecharge.

–Iftherobotvacuumcleanerisleftdetachedfromthecharger,thebatterywilldrain

naturally.

• Iftherobotvacuumcleanerisinenergy-savingmode,powerwillnotcomeonevenif

thepowerswitchisturnedoffandthenon.PressandholdtheStart/Stopbuttononthe

robotvacuumcleaner.

Powerlamp

(Red)

About1m

About0.5m

Installation

VR5000_EN_00734A-00.indd 12 2015-02-27 오후 5:53:57

Installation

Accessories

Remotecontrol(Option) Batteries

[AAAtype(Option)]Usermanual

Sparelter(Option) CleaningbrushVirtualguard(Option)

VR5000_EN_00734A-00.indd 13 2015-02-27 오후 5:53:58

Installation

Charging

Ittakesapproximately120minutestocompletelychargewhenchargingforthersttime

afterpurchaseandcanbeusedforapproximately90minutes.

WARNING

Ratedinputvoltageofthis

productis220-240V~.

Charginglampduringcharging(green)

1 Turn on the power switch on the

bottom.

Youmustturnonthepowerswitchtoturn

ontherobotvacuumcleaner.

2 Manually charge the robot vacuum

cleaner by placing it on the charger.

Makesurethechargepinsoftherobot

vacuumcleanerandthechargerisaligned.

3 Check the charging status.

“”willturnonaccordingtocharging

progressand“FULL”willturnonwhen

chargingiscomplete.

VR5000_EN_00734A-00.indd 14 2015-02-27 오후 5:53:58

Installation

Automatic charging

Whenthebatteryindicatorblinksduring

cleaning,therobotvacuumcleanerwill

returntothechargertochargeitself

automatically.

Recharge

Youcancommandtherobotvacuum

cleanertorechargeatthechargerwhileit

isincleaningprocess.

Low battery (Lo)

Manuallychargetherobotvacuumcleaner

byplacingitonthecharger.

Steps to take if recharging is not being executed.

Check the installation status of the charger when:

• thechargerislocatedinaplacewheretherobotvacuumcleanercannoteasilyaccess.

• distancebetweenthechargerandrobotvacuumcleanerisover5mapart.

–Itmaytakealongtimefortherobotvacuumcleanertoreturntothechargerfor

recharging.

Manually charge the robot vacuum cleaner when:

• thechargerislocatedinacorner.

• batteryisfullyexhausted.

• therobotvacuumcleanerisstuckbyobstacles(furnitureetc.).

• therobotvacuumcleanercan’tclimbthresholdnearcharge.(Heightofthethreshold

thattherobotvacuumcleanercanclimb:about1.5cmandbelow)

• whenthebatteryindicatorblinksand“Lo”isdisplayed.

• whentherobotvacuumcleanerissetonSpotcleanorManualcleanmode.

VR5000_EN_00734A-00.indd 15 2015-02-27 오후 5:53:59

Installation

Installing the virtual guard (Optional)

InfraredrayfromtheVirtualguardwillrestricttherobotvacuumcleanerfrom

approachingcertainareas.

Thedistanceofvirtualwallis2.5matminimumandmaydifferdependingon

surroundingsandmovementstatusoftherobotvacuumcleaner.

Powerlamp(Red)willblink. 1 Press the Power button to turn it on.

2 Install the Virtual guard where you

want to restrict the robot vacuum

cleaner’s entrance.

Makesurethatthedistancesensoris

facinginthedesireddirectionyouwant

tocreateainvisiblebarrier(whichwill

restricttherobotvacuumcleaner’s

approach).

Virtualguard

Minimum 2.5m

VR5000_EN_00734A-00.indd 16 2015-02-27 오후 5:53:59

Installation

Part name of the virtual guard

Powerbutton

Powerlamp

Poweron:Redlampblinks

Poweroff:Lampisoff

Robotvacuumcleanerdetectionsensor

Distancedetectionsensor(Infraredray

sensor)

Batterycover

Inserting batteries

Batteries for the Virtual guard must be purchased separately.

1 Open the battery cover of the Virtual

guard by pressing the locking tab

and lift it up.

2 Insert the batteries (D type) as

shown in the illustration (check the

+, - polarity).

3 Insert the tip of the cover into the

slot and push the other end to close

the battery cover.

VR5000_EN_00734A-00.indd 17 2015-02-27 오후 5:53:59

Operations

Using the robot vacuum cleaner

Youmustturnonthepowerswitchbeforeusingtherobotvacuumcleaner.

WARNING

• Whentherobotvacuum

cleanerisnotusedfor

10minutes,powerwillturn

offautomatically.

Turning the power on/off

Turnon/offthepowerswitchon

thebottomoftherobotvacuum

cleaner.

Operations

Using auto clean mode

Therobotvacuumcleanermovesand

cleansautomaticallyuntilitcleansan

entirespaceonce.

❇ Stopcleaning:Pressthebutton

shortly

Using the cleaningmodes

Youcanselectthedesiredcleaningmode.

Recharge

Youcancommandtherobotvacuum

cleanertorechargeatthecharger

automaticallywhileitisincleaning

process.

Setting schedule

Youcansetorcancelon-timeordaily

schedule.

❇ Referto“Settingtheschedule”.

VR5000_EN_00734A-00.indd 18 2015-02-27 오후 5:54:00

Operations

Selecting cleaning mode

Cleaning mode How to select Displayed icon

Autoclean

Pressonce

Spotclean

Presstwice

Maxclean

Press3times

Manualclean

Press4times

❇ Directioncontrolcanbedoneonlybythe

remotecontrol.

Edgeclean

Press5times

❇ Whentherobotvacuumcleanerisbeingcharged,youcanonlyselecttheAutoclean,Maxcleanor

Edgecleanmode.

VR5000_EN_00734A-00.indd 19 2015-02-27 오후 5:54:01

Operations

Cleaning method for each mode

Auto clean

Cleansautomatically

untilanentirespace

iscleanedonce.

About1.5m

Spot clean

Cleansalocalized

areaintensely.It

canbeusedtoclean

breadorcookie

crumbs.

Max clean

Cleansuntilthe

batteryisdepleted.

Manual clean

Youcanmovethe

robotvacuumcleaner

withtheremote

controltocleanthe

desiredspot.

Edge clean

Cleansthecornersby

reachingtothemas

closeaspossible.

VR5000_EN_00734A-00.indd 20 2015-02-27 오후 5:54:01
