Samsung VCDC08 series User manual

Vacuum Cleaner

user manual

imagine the possibilities

Thank you for purchasing a Samsung product.

✻Before operating this unit, please read the instructions carefully.

✻For indoor use only. English

VCDC08**

VCDC12**

VCDC15**

VCDC20**

DJ68-00665A(EN)-07.indd 01DJ68-00665A(EN)-07.indd 01 2015. 6. 8.  3:572015. 6. 8.  3:57

02_ safety information

safety information

SAFETY INFORMATION

• Before operating the appliance, please read this manual thoroughly and

retain it for your reference.

• Because these following operating instructions cover various models,

the characteristics of your vacuum cleaner may differ slightly from those

described in this manual.

CAUTION/WARNING SYMBOLS USED

WARNING

Indicates that a danger of death or serious injury exists.

CAUTION

Indicates that a risk of personal injury or material damage exists.

OTHER SYMBOLS USED

Represents something you must NOT do.

Represents something you must follow.

Indicates that you must disconnect the power plug from the socket.

Notes on the energy label

• Declared energy efﬁciency and cleaning performance class on

carpet can be met with the enclosed 2-Step Brush.

• When the hard ﬂoor has joints and gaps, please use the

enclosed "Eco Hard Floor" brush which is designed to meet

the energy efﬁciency and cleaning performance class on hard

ﬂoor with joints and gaps.

• The values provided on the energy label have been

determinded according to the prescribed measuring process

(in accordance with EN60312 - 1).

Eco Hard Floor

WARNING

DJ68-00665A(EN)-07.indd 02DJ68-00665A(EN)-07.indd 02 2015. 6. 8.  3:572015. 6. 8.  3:57

safety information _03

safety information

IMPORTANT SAFEGUARDS

1. Read all instructions carefully. Before switching on, make

sure that the voltage of your electricity supply is the same

as that indicated on the rating plate on the bottom of the

cleaner.

2. WARNING : Do not use the vacuum cleaner when rug or

floor is wet.

Do not use to suck up water.

3. Do not use the vacuum cleaner without a dust bin.

Empty the dust bin before it is full in order to maintain the

best efficiency.

4. Slide to the Stop(or Min)position before inserting a plug

into the electrical outlet.

5. Do not use the vacuum cleaner to pick up matches, live

ashes or cigarette butts.

Keep the vacuum cleaner away from stoves and other

heat sources. Heat can deform and discolour the plastic

parts of the unit.

6. Avoid picking up hard, sharp objects with the vacuum

cleaner as they may damage the cleaner parts. Do not

stand on the hose assembly. Do not put weight on the

hose.

Do not block the suction or the exhaust port.

7. Switch the vacuum cleaner off on the body of the

DJ68-00665A(EN)-07.indd 03DJ68-00665A(EN)-07.indd 03 2015. 6. 8.  3:572015. 6. 8.  3:57

04_ safety information

machine before unplugging from the electrical outlet.

Disconnect the plug from the electrical outlet before

changing the dust bag or dust container. To avoid

damage, please remove the plug by grasping the plug

itself, not by pulling on the cord.

8. This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way

and understand the hazards involved.

9. Children shall not play with the appliance. Cleaning and

user maintenance shall not be made by children without

supervision.

10.The plug must be removed from the socket outlet before

cleaning or maintaining the appliance.

11.The use of an extension cord is not recommended.

12.If your vacuum cleaner is not operating correctly, switch

off the power supply and consult an authorized service

agent.

13.If the supply cord is damaged, it must be replaced by the

manufacturer or its service agent or a similarly qualified

person in order to avoid a hazard.

14.Don’t carry the vacuum cleaner by holding the hose.

Use the handle on the vacuum cleaner set.

15.Unplug the cleaner when not in use. Turn off the power

switch before unplugging.

DJ68-00665A(EN)-07.indd 04DJ68-00665A(EN)-07.indd 04 2015. 6. 8.  3:572015. 6. 8.  3:57

contents _05

contents

ASSEMBLING THE CLEANER

OPERATING THE CLEANER

07 ON/OFF Switch

07 Power Cord

08 Power-Control

MAINTAIN TOOLS AND FILTER

09 Using accessory

10 Maintain floor tools

13 Emptying the dust bin

14 When to clean the dust pack

15 Cleaning the dust pack

16 Cleaning the outlet filter

16 Change the battery (option)

TROUBLESHOOTING

DJ68-00665A(EN)-07.indd 05DJ68-00665A(EN)-07.indd 05 2015. 6. 8.  3:572015. 6. 8.  3:57

06_ assembling

assembling the cleaner

• Please do not press the button

of dust bin handle when carrying

machine.

• For storage, park the floor nozzle.

OPTION

• Features may vary according to model.

OPTION

DJ68-00665A(EN)-07.indd 06DJ68-00665A(EN)-07.indd 06 2015. 6. 8.  3:572015. 6. 8.  3:57

operating _07

02 OPERATING

operating the cleaner

ON/OFF SWITCH

1) BODY CONTROL TYPE 2) HANDLE CONTROL TYPE

• When removing the plug from the electrical outlet, grasp

the plug, not the cord.

POWER CORD

CAUTION

DJ68-00665A(EN)-07.indd 07DJ68-00665A(EN)-07.indd 07 2015. 6. 8.  3:572015. 6. 8.  3:57

08_ operating

POWER-CONTROL

BODY-CONTROL TYPE / ON/OFF TYPE

• HOSE

To reduce suction for cleaning draperies,

small rugs, and other light fabrics, pull

the tap air until the hole is open.

• BODY (BODY-CONTROL TYPE ONLY)

MIN = For delicate surface e.g. net

curtains.

MAX = For hard floors and heavily soiled

carpets.

HANDLE CONTROL TYPE

• HOSE

Vacuum cleaner MODE (MIN/MID,MAX)

Press the MODE button repeatedly

to select the correct mode.

(ON) MIN

→

MID

→

MAX

sender

Handle Control

The cleaner is controlled by

using infrared signals.

DJ68-00665A(EN)-07.indd 08DJ68-00665A(EN)-07.indd 08 2015. 6. 8.  3:572015. 6. 8.  3:57

maintain _09

03 MAINTAIN

maintain tools and filter

USING ACCESSORY

Pipe (Option)

• Adjust the length of the telescopic pipe by

sliding the length control button located in the

center of the telescopic pipe back and forth.

• To check for blockages, separate the

telescopic pipe and adjust to shorten. This

allows for easier removal of waste clogging the

tube.

Accessory

• Dusting brush for furniture. shelves, books,

etc.

• Crevice tool for radiators, crevices, corners,

between cushions.

DJ68-00665A(EN)-07.indd 09DJ68-00665A(EN)-07.indd 09 2015. 6. 8.  3:572015. 6. 8.  3:57

10_ maintain

maintain tools and filter

MAINTAIN FLOOR TOOLS

2-Step Brush (Option)

• Adjust the inlet lever according to the floor

surface.

• Remove waste matter

completely if the inlet is

blocked.

Carpet Cleaning

Floor Cleaning

Power Pet Plus Brush (Option)

Frequent vacuuming of hair or pet fur may cause a reduction in rotation due to matters

tangled around the brush-roller. In this case, clean the brush-roller with care.

1. Push the Open button of the transparent screen cover to separate the cover.

2. Remove the brushbar from the transparent screen.

3. Remove waste matter such as dust and hair tangled around the brushbar using

scissors.

4. Remove dust inside the brush housing using a dry duster or crevice tool.

5. Insert brushbar into rotating belt and assemble.

6. Click the transparent screen cover back into place to reassemble.

1 2

4 5

For improved

pickup of pet

hair and fibre on

carpets.

DJ68-00665A(EN)-07.indd 10DJ68-00665A(EN)-07.indd 10 2015. 6. 8.  3:572015. 6. 8.  3:57
