Samsung ATIV Smart PC Pro XE700T1C User manual

User Guide

Chapter 1

Getting Started

Contents

Chapter 1. Getting Started

3Before You Start

6Safety Precautions

21 Proper Posture During Computer Use

24 Overview

30 Turning the Computer On and O

Chapter 2. Using Windows 8

33 What is Microsoft Windows 8?

34 Screen At a Glance

36 Using the Charms

38 Using Apps

42 Windows Hot Key Function

Chapter 3. Using the computer

44 Using the Touch Screen

(For touch screen models only)

52 Using the Touch Supporter

(For touch screen models only) (Optional)

54 Micro SD Card Slot (Optional)

56 Connecting an External Display Device

59 Adjusting the Volume

61 LCD Brightness Control

62 Wireless Network (Optional)

64 NFC (Near Field Communication) (Optional)

66 Using the Keyboard Dock (Optional)

72 Using the TPM Security Device (Optional)

81 Using the Multimedia App (Optional)

85 Using the S Note app (S Note, Optional)

89 Sharing content using the AllShare Play app

(Optional)

98 Samsung Software Update

99 Diagnosing the Computer Status and

Troubleshooting

Chapter 4. Settings and Upgrade

101 BIOS Setup

103 Setting a Boot Password

106 Changing the Boot Priority

107 Battery

Chapter 5. Troubleshooting

112 Recovering/Backing up the Computer (Optional)

118 Reinstalling Windows (Optional)

121 Q&A

Chapter 6. Appendix

128 Important Safety Information

130 Replacement Parts and Accessories

132 Regulatory Compliance Statements

148 WEEE Symbol Information

149 Samsung Packaging Take-Back Program

150 TCO Certied

151 Product Specications

153 Glossary

157 Index

Before You Start 3

Safety Precautions 6

Proper Posture During Computer Use 21

Overview 24

Turning the Computer On and O 30

Chapter 1.

Getting Started

Chapter 1

Getting Started

Before You Start

Before reading the User Guide, rst check the following

information.

Optional items, some devices and software referred to in•

the User Guide may not be provided and/or changed by

upgrade.

Note that the computer environment referred in the User

Guide may not be the same as your own environment.

The pictures used for the cover and the main body in the•

User Manual are those of the representative model of each

series and may dier from the actual appearance of the

product.

This guide decribes procedures for using both the mouse•

and the S Pen.

In this manual ‘click’ means ‘one press with the S Pen’.

The User Guide describes information on the basis of the•

touch screen.

This manual has been written for the Windows 8 operating•

system. The descriptions and gures may dier depending

on the installed operating system.

The User guide supplied with this computer may vary•

depending on your model.

Software Usage Instructions

In the•Start screen, slightly drag the top edge of the

screen toward the center.

Click the corresponding program in the All Apps

menu item.

Alternatively, start the program from Quick Starter.

You can install•Quick Starter through the SW Update.

Chapter 1

Getting Started

Before You Start

Safety Precaution Notations

Icon Notation Description

Warning

Failure to follow instructions marked with

this symbol, may cause personal injury

and or fatality.

Caution

Failure to follow instructions marked with

this symbol, may cause slight injury to

yourself or damage your property.

Text Notations

Icon Notation Description

Caution Content included in this section includes

information required about the function.

Note Content included in this section includes

helpful information to use the function.

Samsung Electronics Co., Ltd. owns the copyright of this manual.

No part of this manual may be reproduced or transmitted in any

form or by any means, electronic or mechanical, without the

consent of Samsung Electronics Co., Ltd.

The information in this document is subject to change without

notice due to improving the performance of the product.

Samsung Electronics shall not be liable for any data loss. Please

take care to avoid losing any important data and backup your data

to prevent any such data loss.

OS and Software Support

If you change the product’s factory OS (Operating System) to

another OS or if you install software which is not supported by the

product’s original factory OS, you will not receive any technical

support, product exchange or refund. And a fee will be charged

when requesting a service.

Please use your computer with the original factory OS. If you

install an OS other than the factory OS, data may be deleted or the

computer may not start.

Chapter 1

Getting Started

Performance Information and Restriction

This computer automatically maintains the CPU and GPU clock•

speed at every moment to control the heating and power

consumption of the computer for minimum performance

degradation.

For best computer performance:

1. Connect the AC adapter.

2. Launch Settings software, and select General > Max.

Performance Mode > Activate max. performance mode.

Online games and some games(3D,2D) may not be supported•

and Full HD video and some high bit rate HD video playback

may be slow and stutter on this computer.

About the Product Capacity Representation

Standard

About the capacity representation of the storage

The capacity of the storage device (HDD, SSD) of the manufacturer

is calculated assuming that 1KB=1,000 Bytes.

However, the operating system (Windows) calculates the storage

device capacity assuming that 1KB=1,024 Bytes, and therefore the

capacity representation of the HDD in Windows is smaller than the

actual capacity due to the dierence in capacity calculation.

(E.g. For a 80GB HDD, Windows represents the capacity as 74.5GB,

80x1,000x1,000x1,000 byte/(1,024x1,024x1,024)byte = 74.505GB)

Windows may also display a smaller hard disk capacity due

to some hidden functions or software programs such as the

Recovery program.

About Memory Capacity Representation

The memory capacity reported in Windows is less than the actual

capacity of memory.

This is because BIOS or a video adapter uses a portion of memory

or claims it for further use.

(E.g. For 1GB(=1,024MB) memory installed, Windows may report

the capacity as 1,022MB or less)

Before You Start

Chapter 1

Getting Started

Installation Related

Do not install the product in places exposed

to humidity such as a bathrooms.

There is a danger of electric shock. Use the

product within the operating conditions

specied in the Manufacturers User Guide.

Keep the plastic bags out of the reach of

children.

There is a danger of suocation.

Keep a distance of 15cm or more between

the computer and the wall and do not place

any objects between them.

This may increase the internal temperature of

the computer and may cause an injury.

Safety Precautions

Do not install the computer on a slant or a

place prone to vibrations, or avoid using the

computer in that location for a long time.

This increases the risk that a malfunction or

damage to the product will occur.

Be careful that people are not exposed to

the computer’s ventilator, adapter, etc., as

they generate heat over a long period of

time when your PC is powered on.

Exposing a part of your body close to the heat

from the vent or AC adapter for long periods of

time may cause a burn.

Avoid blocking the vent at the bottom or

side of the computer when using it on a bed

or cushion.

If the vent is blocked, there is a danger of

damaging the computer or overheating the

inside of the computer.

For your security and to prevent damage, please read the

following safety instructions carefully.

Since this is commonly applied to Samsung Computers,

some pictures may dier from actual products.

Warning

Failure to follow instructions marked with this symbol may

cause personal injury and even fatality.

Ver 3.2

Chapter 1

Getting Started

If the power cord or power outlet makes a

noise, disconnect the power cord from the

wall outlet and contact a service center.

There is a danger of electric shock or re

hazard.

Do not use a damaged or loose main plug or

power cord or power outlet.

There is a danger of electric shock or re

hazard.

Plug the power cord rmly into the power

outlet and AC adapter.

Failure to do so may cause re hazard.

Do not unplug the power cord by pulling

the cable only.

If the cord is damaged, it may cause electric

shock.

Do not bend the power cord excessively or

do not place a heavy object over the power

cord. It is especially important to keep the

power cord out of reach of infants and pets.

If the cord is damaged, it may cause electric

shock or re.

Power Related

The power plug and wall outlet gures may dier

depending on the country specications and the product

model.

Do not touch the main plug or power cord

with wet hands.

There is a danger of electric shock.

Do not exceed the standard capacity

(voltage/current) of a multiplug or power

outlet extension when using it for the

product.

There is a danger of electric shock or re

hazard.

Safety Precautions

Warning

Failure to follow instructions marked with this symbol may

cause personal injury and even fatality.

Chapter 1

Getting Started

Connect the power cord to an outlet or

multiple power plug (extended cable) with

a ground terminal.

Failure to do so may result in electric shock.

When the power supply is ungrounded, the

current may leak resulting in electric shock.

If water or another substance enters

the power input jack, AC adapter or the

computer, disconnect the power cord and

contact the service center.

If the notebook computer has an external

type (removable) battery, separate the

battery also.

Damage to the device within the computer

may cause electric shock or re hazard.

Keep the power cord or outlet clean so that

they are not covered with dust.

Failure to do so may result in re.

AC Adapter Usage Precautions

Connect the power cord to the AC adapter

rmly.

Otherwise, there is a danger of re due to an

incomplete contact.

Use only the AC adapter supplied with the

product.

Using another adapter may cause the screen to

icker.

Do not place heavy objects or step onto

the power cord or AC adapter to avoid

damaging the power cord or AC adapter.

If the cord is damaged, there is a danger of

electric shock or re.

Unplug the wall-mount AC adapter (adapter

and plug intergrated type) from the wall

outlet while holding the body and pulling it

in the direction of the arrow.

If you unplug the adapter by holding and

pulling the cable, the adapter may be damaged

and an electric shock, explosive sound or spark

may occur as a result.

Warning

Failure to follow instructions marked with this symbol may

cause personal injury and even fatality.

Safety Precautions

Chapter 1

Getting Started

Battery Usage Related

Please charge the battery fully before using the

computer for the rst time.

Keep the battery out of the reach of infants

and pets, as they could put the battery into

their mouths.

There is a danger of electric shock or choking.

Use an authorized battery and AC adapter

only.

Please use an authorized battery and adapter

approved by Samsung Electronics.

Unauthorized batteries and adapters may not

meet the proper safety requirements and may

cause problems or malfunctions and result in

an explosion or re.

Warning

Failure to follow instructions marked with this symbol may

cause personal injury and even fatality.

Safety Precautions

Do not use the computer in a badly

ventilated location such as on bedding, on a

pillow or cushion, etc, and do not use it in a

location such as room with oor heating as

it may cause the computer to overheat.

Take care that the computer vents (on the side

or the bottom) are not blocked especially in

these environments. If the vents are blocked,

the computer may overheat and it may cause a

computer problem, or even an explosion.

Do not use the computer in a humid

location such as a bathroom or sauna.

Please use the computer within the

recommended temperature and humidity

range (10~32ºC, 20~80% RH).

Do not close the LCD panel and put the

computer into your bag to move it when it is

still turned on.

If you put the computer into your bag without

turning it o, the computer may overheat and

there is a danger of re. Shut the computer

down properly before moving it.

Other manuals for ATIV Smart PC Pro XE700T1C

This manual suits for next models

Table of contents

Other Samsung Tablet manuals

Samsung

Samsung Q1 Ultra Series User manual

Samsung

Samsung SM-T537A User manual

Samsung

Samsung SMW737N0 User manual

Samsung

Samsung Galaxy Tab S7 User manual

Samsung

Samsung SM-T715 User manual

Samsung

Samsung Galaxy Tab A SM-T380 User manual

Samsung

Samsung GT-P5110 User manual

Samsung

Samsung SHWM180S User manual

Samsung

Samsung SM-T227UZAAXAU User manual

Samsung

Samsung GT-P5220 User manual

Samsung

Samsung SM-T310 User guide

Samsung

Samsung Galaxy Tab A10.1 User manual

Samsung

Samsung SM-T535 User manual

Samsung

Samsung Galaxy Tab GT-P7500 User manual

Samsung

Samsung Galaxy Tab S SM-T807A User manual

Samsung

Samsung galaxy tab 4 nook 10.1 User manual

Samsung

Samsung Galaxy Tab 7.7 GT-P6800 User manual

Samsung

Samsung GT-N8000 User manual

Samsung

Samsung Galaxy Tab3 User manual

Samsung

Samsung SM-T307U User manual

Samsung

Samsung Galaxy Tab A 9.7 WiFi User manual

Samsung

Samsung Galaxy Tab S3 User manual

Samsung

Samsung Galaxy Tab GT-P5100 User manual

Samsung

Samsung SM-T355Y User manual

Popular Tablet manuals by other brands

Laser

Laser MID-1060 Quick operation guide

MUNBYN

MUNBYN IRT09J Easy setup guide

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz quick start guide

Dell

Dell Latitude ST Setup and features information

Lenovo

Lenovo IdeaTab S6000L Hardware Maintenance Manual

Venturer

Venturer WT9L11 quick start guide

EDUGEAR

EDUGEAR UnoBook user guide

Philips

Philips PI3210G/58 user manual

ADLINK Technology

ADLINK Technology IMT-BT user manual

TwinMOS

TwinMOS TwinTAB-T102D1 user guide

Archos

Archos 9.7 xenon manual

Getac

Getac E100 user manual

HANNspree

HANNspree HANNspad SN70T3 quick start guide

Philips

Philips PI3105W2/55 user manual

LG LG-V935 user guide

Zeki

Zeki TBDB763B user guide

Ricoh

Ricoh eQuill user guide

DT Research

DT Research DT365CT Basic operation guide
