Samsung Yepp YP-N30 User manual

Connecting the USB cable

USB connect cable

1Plug one end of the USB cable into the USB port

on the PC.

2Insert the battery into the yepp and turn on the

power.

3Slide down the bottom cover of the player.

Plug the other end of the USB cable

into the USB port on the right side at the bottom.

● If you disconnect the USB cable from your PC while

implementing a command or initializing during USB driver

installation, your PC may not function correctly.

4USB driver is installed with a message saying that

it is searching for a new device. You may not see

the display screen during installation. Go to the

device manager to check that installation has

been successfully completed.

5When USB driver is installed, "SAMSUNG YP-

N30” will appear in [System Properties] ➝

[Device Manager]

YP-N30 Quick Guide

➤Before connecting yepp to PC, make sure to install USB driver.

Location of Controls

Earphone Jack

Microphone

Neck strap Hook

Display

Voice Recording Button MENU/Loop Repeating Button

Hold Switch

USB Cable Connection Port

Volume

Play/Stop/Pause/Forward/Backward

Button

Playing Music

Stopping Music

When you press the button, the yepp logo appears and a music/voice file is played.

When you press the button while playing, the music stops. If no buttons are pressed

within 5 seconds (changes depending on settings), the yepp automatically powers off.

Quick-N30 2/14/04 1:29 PM Page 2

Downloading/Uploading files

1Turn on the yepp and connect it to your PC.

2Open Windows Explorer on PC.

3Select the file to save and drag-and-drop it into the removable disk icon.

The saved files will be played in the order they were downloaded. Once

they are downloaded you cannot change the sequence of play.

NNoo

oott

ttee

●Do not create new folders within the removable disk directory as the files saved in the newly

created folders will not play.

●Music files such as MP3, WMA and SM3 can not be uploaded to your PC due to copyright

protection.

NNoo

oott

ttii

iicc

ccee

●The “WRITING” message will appear during file download or upload. Disconnecting the USB cable

while “WRITING” is displayed may cause malfunction of the unit.

Disconnecting the USB cable

1Select the removable disk icon and click the right mouse button to select

[Eject].

2Select [OK] and disconnect the USB cable when a picture appears as

shown below.

After completing file transmission, you must disconnect the cable in the following way:

3 4

AH68-01506A (Rev 0.0)

Quick-N30 2/14/04 1:29 PM Page 4
