Samsung YP-T5 yepp' User manual

- MP3 and WMA playback

- Removable Storage Device

- Encoding function

- FM reception

- 3D sound

- Upgradable

- 12 hours of continuous play

YP-T5

AH68-01567B (Rev 0.0)

Contents

Basic Usage

Playing Music and Turning Off the Device 26

Adjusting the Volume/Hold Function 27

Recording Voice 28

MP3 Encoding 29

Searching for Music/Voice Files 30

Listening to FM Radio 31

FM Encoding 33

Preparations

Safety Instructions 4

Features 6

Accessories 9

Location of Controls (yepp) 10

Connection to Computer

Connecting the yepp to a PC 12

Manual Installation of the USB Driver 16

Using the removable storage 20

●Downloading/Uploading files 20

●Disconnecting the USB cable 21

●Formatting 22

Installing yepp Studio 23

●To View Help on yepp Studio 25

Loop Repeating 34

Using Navigation 35

Setting Playlist 36

Setting up MENU 37

Managing Files 38

●Deleting 38

●Formatting 39

Setting the Advanced Functions 40

Selecting the Play mode 41

Setting the EQ mode 42

Display 43

●Scroll Speed /Time 43

●Backlight 44

●Contrast 45

Power Off Time 46

●Time / Sleep 46

Encoding 47

●Bitrate / AutoSync Time 47

WOW Level 48

●Adjusting SRS and TruBass LEVEL 48

●WOW Optimum 48

Default Volume 49

Appendix

MENU Table 50

Customer Support

Troubleshooting 52

Specifications 54

Additional Usage

Safety Instructions Earphones

Follow Traffic Safety Instructions

●

Do not use the earphones while driving an automobile or riding a bicycle.

It’s not only dangerous, but also against the law.

●

An accident may result if you turn up the volume of the earphones too high while walking

down the street, especially when crossing at intersections.

Protect your ears

●

Do not turn the volume up too high.

Doctors warn against prolonged exposure to high volumes.

●

Stop using the device or turn the volume down if you get ringing in your ears.

●

Follow local guidelines for waste disposal when discarding packaging, batteries,and old

electronic appliances.

●

yepp packaging uses cardboard, polyethylene etc., and does not use

any unnecessary materials.

●

Ambient temperature : 5°C ~ 35°C (41°F ~ 95°F)

●

Humidity : 10% ~ 75%

Read and understand all the instructions to avoid injury to yourself and damage to the equipment.

✽

Please be aware that we disclaim all responsibility for damages from loss of saved

or recorded data due to breakdown, repair or other causes.

Do not expose to extreme

temperatures (above 95°F or below

23°F). Do not expose to moisture.

Do not apply excessive pressure

to the device.

Do not expose to chemicals such

as benzene and thinners.

Remove batteries when the device

is left unused for a long period of

time.

Do not expose to direct sunlight

or heat sources.

Do not store in dusty areas.

Do not place heavy objects on top

of the device.

Do not let any foreign matter spill

into the device.

Do not try to disassemble and

repair the device yourself.

Ambient operating conditions

Environmental Information

MP3 & WMA Playback

●MP3 is an MPEG1 Layer3 audio format.

●WMA is a Microsoft Windows Media audio format.

Removable Storage Device

●You can easily copy and paste files to the yepp player using Windows Explorer.

Encoding Function

●You can make an MP3 file from an external source using the ENC jack

on the main unit.

●You can also convert an FM radio program into an MP3 file in real time.

FM Reception

●Listening to an FM program is made easy with Auto Search and Frequency

Memory functions.

3D Surround Sound

●You will hear deep bass and 3D surround sound.

Upgradable

●You can upgrade the built-in programs when available.

Add functions, CODEC, etc. Please check the yepp home page for upgrades.

12-Hour Continuous Play

●This unit uses one AAA/LR03 alkaline battery. Operation can last up to 12hours.

Actual playing time may vary according to the type and capacity of the battery.

Voice Recording Function

●You can do a Voice Recording with high quality and use it for a conference.

Sound

●You can adjust the equalizer manually.

●

The capacity of the useable built-in memory is less than indicated as the internal firmware

uses a part of the memory as well.

●

Design of accessories is subject to change, for the purposes of improvement, without notice.

Accessories

Player Earphones USB cable User manual

Installation CD

One Battery

(1.5V AAA/LR03 type) Neck Strap

Carrying case

Direct Connect

USB Adapter Line In Cable

Model

Built-in memory

YP-T5 H

128MB

YP-T5 V

256MB

YP-T5 X

512MB

Location of Controls (yepp)

Playtime indicator

Mode indicator

Bit rate indicator

Play mode indicator

Equalizer, SRS indicator

Play/Stop/Pause indicator

Remaining Battery Power indicator

Track Number indicator

Title (track & artist) indicator

Display

Inserting a Battery

Recording Button

Play/Pause Button

Hold Switch

Loop Repeating Button

USB Cable

Connection Port

ENC Jack

Microphone

Neck strap Hook

MENU, Navigation button/

Move to Track/Speed Search/

Volume Button

Display

Earphone Jack

Battery Cover

Slide the cover in the

direction of the arrow to open.

Insert a battery to the right poles

+ , – and push-close the cover in the

direction the arrow as indicated.

NNoo

oott

ttee

●

Do not place heavy objects on the cover.

Connecting the yepp to a PC

Before connecting yepp to PC, make sure to install

USB driver. If “Add New Hardware Wizard”appears,

press the [Cancel] button and install the USB driver.

System

Requirements.

The PC system must meet the

following specifications:

●

Pentium 133MHz or greater.

●

Windows 98SE/ME/2000/XP.

●

40MB of available hard disk space

●

CD-ROM drive.

(double speed or greater)

●

USB port (1.1) supported.

●

DirectX 8.0 or above.

Continued...

NNoo

oott

ttee

●

Install the operating system in

Administrator Account mode for Windows

2000 or XP. Otherwise, installation will not

be completed.

●

Windows ME, 2000 and XP can recognize

the driver without installing the provided

program. However, you must install the

program in order to format yepp and

upgrade firmware.

●

If the YP-T5 program has not been

installed in Windows 98, then it will not

communicate with your removable disk.

You must install the USB driver file first.

Installing software

1Insert the Installation CD into the CD-ROM drive.

The picture shown below appears.

Select [yepp USB Driver] 2Click [Next] in the series of windows that appear.

Connect a USB cable to the USB port on the

computer.

Connect the other end of a USB cable to the USB cable

connection port on the bottom of the yepp, and press

the button on the main unit.

●

If you disconnect the USB cable from your PC while

implementing a command or initializing during USB

driver installation, your PC may not function correctly.

Upon installation of the USB driver

"Samaung yepp YP-T5" will appear in the

[System Properties]

→

[Device Manager].

The USB driver is installed with a message saying that

it is searching for a new device. You may not see the

display screen during installation.

Go to the device manager to check that

installation has been successfully completed.

How to check the USB driver

●

Windows 98/ME:

Control Panel

→

System

→

Device Manager

→

Disk Drives

→

Samsung yepp YP-T5

●

Windows 2000:

Control Panel

→

System

→

Hardware

→

Device Manager

→

Disk Drives

→

Samsung yepp YP-T5

USB Device

●

Windows XP:

Control Pane

→

System

→

Hardware

→

Device Manage

→

Disk Drives

→

Samsung yepp YP-T5

USB Device

When the USB driver is not installed automatically,

refer to the next page.

Connecting the yepp to a PC with a USB cable

Connecting the yepp to a PC

USB connect cable

Manual Installation of the USB Driver

Go to “Downloading/Uploading files” on page 20 if the USB driver is in place.

Follow these steps if the USB driver is not in place :

Check the device manager.

●

Windows 98/ME:

Control Panel

→

System

→

Device Manager

●

Windows 2000 (Professional):

Control Panel

→

System

→

Hardware

→

Device Manager

●

Windows XP (Professional):

Control Panel

→

System

→

Hardware

→

Device Manager

Check if there is a device listed with an

exclamation point or a question mark

(displayed as unknown device or USB device).

Double click on the device listed with an exclamation

point or a question mark.

After selecting the driver,

click on [Update Driver].

4Select a compatible driver,

click on [Next] to finish.

NNoo

oott

ttee

●

If you are using Windows 2000 and your version of Windows does not recognize the USB driver

please download and install the latest service pack from windows update.microsoft.com

●

The installation method may vary depending on the type of PC or operating system.

Contact your PC dealer or service center for installation information.

●

If errors occur continuously when you install the USB driver,

reconnect the USB cable after rebooting your system.

When an error occurs during installation of the USB driver

In Windows 98

Manual Installation of the USB Driver

●

You must reboot your computer to

complete the installation.

USB driver location

[CD ROM]\setup\Drivers NN

NNoo

oott

ttee

●

You cannot use it as a removable disk in Windows 98 if the YP-T5 program is not installed.

Make sure to install the USB driver file first.

Click [Next] button in the series of windows that appear.
