Samsung GVI Security SMT-4022 User manual

LCD Monitor

User Manual

SMT-4022

Safety Instructions

Notational

Note

These safety instructions must be followed to ensure your safety and prevent property dam-

age.

Make sure to read the instructions carefully and use the product in the correct manner.

Warning / Caution

Failure to follow directions noted by this symbol could result in bodily

harm or damage to the equipment.

Notational Conventions

Prohibited Important to read and under-

stand at all times

Do not disassemble Disconnect the plug from the

outlet

Do not touch Ground to prevent an electric

shock

Power

When not used for extended period of time, set your computer to DPM.

If using screen saver, set it to active screen mode.

The images here are for reference only, and are not applicable in all cases

(or countries).

Shortcut to Anti-Afterimage Instructions

Do not use a damaged power cord or plug or a damaged or

loose power outlet.

• Otherwise, this may result in electric shock or fire.

Do not touch the power plug with wet hands when removing or

plugging the plug into the outlet.

• Otherwise, this may result in electric shock.

Make sure to connect the power cord to a grounded power out-

let.

•Otherwise, it may result in electric shock or personal injury.

Ensure that the power plug is plugged into the power outlet

firmly and correctly.

•Otherwise, this may result in fire.

Do not forcefully bend or pull the power plug and do not place

any heavy material on it.

• Otherwise, this may result in fire.

Do not connect multiple appliances to the same power outlet.

• Otherwise, this may cause fire due to overheating.

Do not disconnect the power cord while using the product.

• Otherwise, this may result in damage to the product due to

electric shock.

To disconnect the apparatus from the mains, the plug must be

pulled out from the mains socket, therefore the mains plug shall

be readily operable.

• This may cause electric shock or fire.

Use only the power cord provided by our company. Do not use

the provided power cord of another product.

• Otherwise, this may result in fire or electric shock.

Installation

Be sure to contact an authorized Service Center when installing your LCD

Monitor in a location with heavy dust, high or low temperatures, high hu-

midity, and exposed to chemical substances and where it operates for 24

hours such as at airports, train stations etc.

Failure to do so may cause serious damage to your LCD Monitor.

Ensure that at least two persons lift and move the product.

• Otherwise, it may be dropped and cause personal injury, and/

or damage the product.

When installing the product in a cabinet or rack, make sure that

the front end of the bottom of the product does not project out.

• Otherwise, it may fall or cause personal injury.

• Use a cabinet or rack of a size appropriate to the product.

DO NOT PLACE CANDLES, MOSQUITO REPELLANT, CIG-

ARETTES AND ANY HEATING APPLIANCES NEAR THE

PRODUCT.

• Otherwise, this may result in fire.

Safety Instructions

Keep heating appliances as far away from the power cord or the

product as possible.

•Otherwise, this may result in electric shock or fire.

Do not install it in a badly ventilated location such as a bookcase

or closet.

• Otherwise, this may result in fire due to an increase in the in-

ternal temperature.

When putting the product down, make sure to put it down softly.

• Otherwise, this may result in damage to the screen display.

Do not place the front of the product on the floor.

• Otherwise, this may result in damage to the screen display.

Ensure that an authorized installation company installs the wall

mount.

• Otherwise, it may fall and cause personal injury.

• Make sure to install the specified wall mount.

Install your product in a well ventilated location. Ensure that

there is a clearance of more than 10 cm from the wall.

• Otherwise, it may result in fire due to an increase in the internal

temperature.

Ensure that the packaging vinyl is kept away from children.

• Otherwise, it may result in serious harm (suffocation) if children

play with it.

If the height of your LCD Monitor is adjustable, do not place any

object or part of your body on the stand when lowering it.

• This may cause damage to the product or the person carrying

it.

Clean

When cleaning the LCD Monitor case or the surface of the TFT-LCD

screen, wipe with a slightly moistened, soft fabric.

Do not spray cleaner directly onto the surface of the product.

• Otherwise, this may result in the discoloration and distortion of

the structure and the screen surface may peel off.

Clean the product using a soft cloth with a LCD Monitor cleaner

only. If you must use a cleaner other than the LCD Monitor cleaner,

dilute it with water at a ratio of 1:10.

Safety Instructions

When cleaning the power plug pins or dusting the power outlet,

clean it with a dry cloth.

•Otherwise, it may result in fire.

When cleaning the product, make sure to disconnect the power

cord.

• Otherwise, it may result in electric shock or fire.

When cleaning the product, disconnect the power cord and

clean it softly with a dry cloth.

• (Do not use chemicals such as wax, benzene, alcohol, thinner,

mosquito repellant, lubricant, or cleaner.) These may change

the appearance of the product surface and peel off the indica-

tion labels on the product.

Since the product housing is easily scratched, make sure to use

the specified cloth only.

• Use the specified cloth adding only a little water. As the product

may be scratched if there is any foreign material on the cloth,

make sure to shake it thoroughly before using it.

When cleaning the product, do not spray water directly onto the

main body of the product.

• Ensure that water does not enter the product and that it is not

wet.

• Otherwise, this may result in electric shock, fire or a malfunc-

tion.

Others

The product is a high voltage product. Ensure that users do not

disassemble, repair or modify the product themselves.

• Otherwise, this may result in electric shock or fire. If the product

needs to be repaired, contact a Service Center.

If there is a strange smell or a strange sound or smoke is coming

from the product, disconnect the power plug immediately and con-

tact a Service Center.

• Otherwise, this may result in electric shock or fire.

Do not place this product in a location exposed to moisture, dust,

smoke, water, or in a car.

• Otherwise, this may result in electric shock or fire.

When you drop the product or the case is broken, turn the power

off and disconnect the power cord. Contact a Service Center.

• Otherwise, this may result in electric shock or fire.

Safety Instructions

If thunder or lightening is occurring, do not touch the power cord

or antenna cable.

•Otherwise, this may result in electric shock or fire.

Do not try to move the LCD Monitor by pulling only the wire or

the signal cable.

• Otherwise, it may fall and result in electric shock, damage to

the product or fire due to damage to the cable.

Do not lift or move the product back and forwards or right and

left while only holding the power cord or signal cables.

• Otherwise, it may fall and result in electric shock, damage to

the product or fire due to damage to the cable.

Make sure that the ventilating opening is not blocked by a table

or curtain.

• Otherwise, it may result in fire due to an increase in the internal

temperature.

Do not place any containers containing water, vases, flower-

pots, medicines as well as any metal on the product.

• If water or a foreign material enters the product, disconnect the

power cord and contact a Service Center.

• This may result in a product malfunction, electric shock, or fire.

Do not use or keep combustible spray or flammable material

near the product.

• Otherwise, this may result in an explosion or fire.

Do not insert any metal, such as chopsticks, coins, pins and

steel, or flammable objects, such as matches or paper, inside the

product (through the ventilating openings, input and output termi-

nals, etc).

• If water or foreign material enters the product, disconnect the

power cord and contact a Service Center.

• Otherwise, this may result in electric shock or fire.

When using a fixed screen for a long time, an afterimage or stain

may occur.

• If you are not using your product for a long period of time, put

it into sleep mode or use a moving screen saver.

Set a resolution and frequency appropriate to the product.

• Otherwise, your eyesight may be damaged.

When using headphones or earphones, do not turn the volume

too high.

• Having the sound too loud may damage your hearing.

Safety Instructions

If you continually move closer to the product screen, your eye-

sight may be failing.

Take a rest for at least five (5) minutes after using the LCD

Monitor for one (1) hour.

This reduces the weariness of your eyes.

Do not install it in an unstable location such as an unstable rack

or uneven surface or a location exposed to vibrations.

• Otherwise, it may fall and cause personal injury and/or damage

the product.

• If you use the product in a location exposed to vibrations, it may

damage the product and result in fire.

When moving the product, turn the power off and disconnect

the power plug, antenna cable, and all the cables connected to the

product.

• Otherwise, it may result in electric shock or fire.

Ensure that children do not hang onto the product or climb up

onto the product.

• The product may fall and cause personal injury or death.

If you do not use the product for a long period of time, disconnect

the power cord from the power outlet.

• Otherwise, this may result in overheating or fire due to dust,

and may result in fire due to electric shock or leakage.

Do not place any heavy items or toys or confectionery, such as

cookies etc. that may attract the attention of children and to the

product.

• Your children may hang onto the product causing it to fall and

this may result in personal injury or death.

Be careful that children do not place the battery in their mouths

when removed from the remote control. Place the battery in a lo-

cation that children or infants cannot reach.

• If children have had the battery in their mouths, consult your

doctor immediately.

When replacing the battery, insert it with right polarity (+, -).

• Otherwise, the battery may become damaged or it may cause

fire, personal injury or damage due to leakage of the internal

liquid.

Use only the specified standardized batteries, and do not use a

new battery and a used battery at the same time.

• Otherwise, the batteries may be damaged or cause fire, per-

sonal injury or damage due to a leakage of the internal liquid.

Safety Instructions

The batteries (and rechargeable batteries) are not ordinary re-

fuse and must be returned for recycling purposes. The customer

is responsible for returning the used or rechargeable batteries for

recycling.

• The customer can return used or rechargeable batteries to a

nearby public recycling center or to a store selling the same

type of the battery or rechargeable battery.

Do not place the product in a location exposed to direct sunlight

or near any heat such as a fire or heater.

• This may reduce the lifetime of the product, and may result in

fire.

Do not drop any objects onto the product or cause any impact

to the product.

•Otherwise, this may result in electric shock or fire.

Do not use a humidifier or kitchen table near the product.

• Otherwise, this may result in electric shock or fire.

When there is a gas leak, do not touch the product or the power

plug but ventilate immediately.

• If a spark occurs, it may cause an explosion or fire.

If the product has been turned on for a long time, the display

panel becomes hot. Do not touch it.

• Keep the small accessories in a location out of the reach of

children.

Be careful when adjusting the angle of the product or the height

of the stand.

• This may result in personal injury as your hand or fingers may

become caught.

• Also, if you tilt the product too far, it may fall and cause personal

injury.

Do not install the product in a location low enough for children

to reach.

• Otherwise, it may fall and result in personal injury.

• Since the front part of the product is heavy, install the product

on a level and stable surface.

Do not put any heavy objects on the product.

• This may result in personal injury and/or damage to the prod-

uct.

Safety Instructions

Contents

Safety Instructions ............................................................................................. 2

Notational ............................................................................................................ 2

................................................................................................................. 2

.......................................................................................................... 3

.................................................................................................................. 4

Others ................................................................................................................. 5

Introduction

Package Contents ............................................................................................... 12

Your LCD Monitor ................................................................................................ 13

Machanical Layout ............................................................................................... 19

Connections

Connecting a Computer......................................................................................... 26

Connecting to Other devices .................................................................................. 27

Adjusting the LCD Monitor

Input ................................................................................................................. 57

Picture [PC / DVI / MagicInfo Mode]

Picture [AV / HDMI / TV Mode] .................................................. 65

Sound................................................................................................................ 70

Multi Control ....................................................................................................... 85

MagicInfo .................................................................................................. 86

................................................................................................ 16

Using the Software

Monitor Driver ......................................................................................... 26

MDC System .................................................................................. 38

Power

Installation

Clean

Remote Control

Setup .............................................................................................................. 72

.......................................................................................... 26

...................................................................................................... 26

........................................................................................................ 12

............................................................................ 57

.......

...................

......................................................................... 58

................

........

.......

Troubleshooting ................................................................................................. 88

Self-Test Feature Check ......................................................................................................... 88

Check List ............................................................................................................................... 89

Q & A ....................................................................................................................................... 92

Specifications .......................................................................................................................... 94

General ................................................................................................................................... 94

PowerSaver ............................................................................................................................

Preset Timing Modes ..............................................................................................................

Information ....................................................................................................... 98

For Better Display ................................................................................................ 98

PRODUCT INFORMATION (Image Retention Free) .................................................... 98

Appendix .............................................................................................................. 103

Contact SAMSUNG WORLDWIDE .......................................................................... 103

Terms ............................................................................................................... 105

Correct Disposal .................................................................................................. 106

Authority ............................................................................................................ 107

Other manuals for GVI Security SMT-4022

Table of contents

Other Samsung Monitor manuals

Samsung

Samsung PS-42P4H Instruction manual

Samsung

Samsung 320MP-2 - SyncMaster - 32" LCD Flat Panel... User manual

Samsung

Samsung 275T - SyncMaster - 27" LCD Monitor User manual

Samsung

Samsung SyncMaster S19B150B User manual

Samsung

Samsung C24RG50F User manual

Samsung

Samsung T260HD - SyncMaster - 25.5" LCD Monitor User manual

Samsung

Samsung S34C50 Series User manual

Samsung

Samsung 720N - SyncMaster - 17" LCD Monitor User manual

Samsung

Samsung SyncMaster 204BM User manual

Samsung

Samsung NL22B User manual

Samsung

Samsung SyncMaster TA950 User manual

Samsung

Samsung S32AM501NU User manual

Samsung

Samsung LN46D567F9H Quick start guide

Samsung

Samsung PL-50P5HD User manual

Samsung

Samsung SyncMaster 275TPLUS User manual

Samsung

Samsung 215TW - SyncMaster - 21" LCD Monitor User manual

Samsung

Samsung TS DR Series Installation guide

Samsung

Samsung SyncMaster 400UXN-2 User manual

Samsung

Samsung SyncMaster 211MP User manual

Samsung

Samsung 192T - SyncMaster 192 T User guide

Samsung

Samsung SP-R4232 User manual

Samsung

Samsung SyncMaster 460UT-2 User manual

Samsung

Samsung SyncMaster XL20 User manual

Samsung

Samsung SyncMaster 820DXN-2 User manual

Popular Monitor manuals by other brands

Linear Acoustic

Linear Acoustic LQ-1000 user guide

AOC

AOC I2579V user manual

Gateway

Gateway FPD1520 user guide

Furuno

Furuno Mu 120c Operator's manual

Asus

Asus VB171D - 17" LCD Monitor Service manual

Dell

Dell S2230MX Setting up

Philips

Philips 107C64 user manual

Dell

Dell S2409WFP user guide

EverFocus

EverFocus EN-7517E instruction manual

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Service manual

Dell

Dell Precision 7680 Connection guide

LG 50PM1M - - 50" Plasma Panel Service manual

Bosch

Bosch DDU 9 manual

Acer

Acer A231HL user manual

Philips

Philips 86BDL4152T user manual

NEC

NEC AccuSync LCD5V user manual

Emay

Emay SleepO2 user manual

IBM

IBM 6360 Product support manual
