Samsung UB6V Series Installation guide

LCD TV UB6V,UB7W

TRAINING MANUAL

UE**B6000VWXXC

UE**B7000WWXXC

UE**B7020WWXXC

BETO-PX

Agenda

I. Inside of UB7W

II. Board description

III. Disassembly

IV. Trouble Shooting

V. New function of UB7W

BETO-PX

Inside of UB7W

Inside of

UB7W

BETO-PX

Items Specification

UE**B7000WWXXC, (UE**B7020WWXXC)

Size (W*D*H) with Stand UE40B7000WWXXC : 39.21 x 27.24 x 10.03 inches

UE46B7000WWXXC : 44.45 x 30.20 x 10.83 inches

UE55B7000WWXXC : 52.01 x 34.53 x 12.01 inches

Weight with Stand UE40B7000WWXXC : 18.5kg

UE46B7000WWXXC : 22.5kg

UE55B7000WWXXC : 27.4kg

Panel Resolution 1920*1080

A/V 1AV

S-VIDEO No

component 1 component

480i/p,720p,1080i/p

SCART 1 SCART

PC 1 Dsub

HDMI 4 HDMI

Tuner 1 PAL/SECAM/NIM/QAM/Cable tuner

USB 2 USB

Sound Output 10W/10W/15W

DNIe Yes

PIP Yes

Sound option SRS TruSurround HD

Headphone No

Response time 3ms

Luminance [cd/m2, typical] 500

C/R 300,0000

Anynet+(hdmi cec) Yes

View Angle(H/V) 178/178

Power Supply AC 110~220V,60Hz

Power Consumption 120W/128W/161W

Stand-by Power consumption 0.8W/0.8W/0.9W

Inside of UB7W

BETO-PX

Spec Comparison

Model SAMSUNG

(UB6V)

UE46B6000VWXXC

SAMSUNG

(UB7W)

UE46B7000WWXXC

SAMSUNG

(sapphire)

LE46A856S1MXXC

Design

Set Size(without stand) 43.90 x 27.76 x 1.18

(Ultra slim) 44.45 x 27.755 x 1.18

(Ultra slim) 44.05 x 27.26 x 1.74

Panel Size Diagonal 46” Diagonal 46” Diagonal 46”

Resolution 1920 x 1080 1920 x 1080 1920 x 1080

Viewing angle H : 178 V : 178 H : 178 V : 178 H : 178 V : 178

Color System PAL PAL PAL

Tuner 1 1 1

Function Contrast (cd/m2)500 500 500

CR ( Dynamic ) 300,0000 : 1 300,0000 : 1 50000 : 1

Enhancer DNIe(FBE3) DNIe(FBE3) DNIe(FBE3)

Back light unit LED LED CCFL

Additional Function Media Link Internet@TV

Home network center infolink

Power Consumption 128W 128W 310W

Inside of UB7W

BETO-PX

Control & Connection Panel

Inside of UB7W

BETO-PX

Control & Connection Panel

Inside of UB7W

BETO-PX

Control & Connection Panel

Inside of UB7W

BETO-PX

Control & Connection Panel

Inside of UB7W

BETO-PX

Control & Connection Panel

Inside of UB7W

BETO-PX
