Samsung S22D390H User manual

User manual

S22D390H

S22D393H

S24D390HL

S24D393HL

S27D390H

S27D393H

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00383B-00

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

7 Copyright

7 Icons used in this manual

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

10 Safety Precautions

10 Symbols

11 Electricity and Safety

12 Installation and Safety

14 Operation and Safety

18 Correct posture to use the product

PREPARATIONS 19 Checking the Contents

19 Checking the Components

20 Parts

20 Frontal Buttons

23 Reverse Side

24 Installation

24 Attaching the Stand

25 Removing the Stand

26 Adjusting the Product Tilt

27 Anti-theft Lock

CONNECTING AND USING

A SOURCE DEVICE

28 Before Connecting

28 Pre-connection Checkpoints

28 Connecting and Using a PC

28 Connecting to a PC

30 Connecting to Headphones

31 Connecting the Power

32 Driver Installation

33 Setting Optimum Resolution

Table Of Contents

Table Of Contents 3

SCREEN SETUP 34 Brightness

34 Configuring Brightness

35 Contrast

35 Configuring Contrast

36 Sharpness

36 Configuring Sharpness

37 Game Mode

37 Configuring Game Mode

38 SAMSUNG MAGIC Bright

38 Configuring SAMSUNG MAGIC Bright

40 SAMSUNG MAGIC Angle (S22D390H /

S22D393H)

40 Configuring SAMSUNG MAGIC Angle

42 SAMSUNG MAGIC Upscale

42 Configuring SAMSUNG MAGIC Upscale

43 Image Size

43 Changing the Image Size

45 HDMI Black Level

45 Configuring the HDMI Black Level Settings

46 Response Time (S24D390HL /

S24D393HL / S27D390H / S27D393H)

46 Configuring the Response Time

47 H-Position & V-Position

47 Configuring H-Position & V-Position

49 Coarse

49 Adjusting Coarse

50 Fine

50 Adjusting Fine

Table Of Contents

Table Of Contents 4

CONFIGURING TINT 51 Red

51 Configuring Red

52 Green

52 Configuring Green

53 Blue

53 Configuring Blue

54 Color Tone

54 Configuring the Color Tone Settings

55 Gamma

55 Configuring Gamma

COORDINATING OSD 56 Language

56 Configuring Language

57 Menu H-Position & Menu V-Position

57 Configuring Menu H-Position & Menu V-

Position

58 Display Time

58 Configuring Display Time

59 Transparency

59 Changing Transparency

SETUP AND RESET 60 Reset All

60 Initializing Settings (Reset All)

61 Eco Saving

61 Configuring Eco Saving

62 Off Timer

62 Configuring Off Timer

63 Configuring Turn Off After

64 PC/AV Mode

64 Configuring PC/AV Mode

Table Of Contents

Table Of Contents 5

65 Key Repeat Time

65 Configuring Key Repeat Time

66 Source Detection

66 Configuring Source Detection

INFORMATION MENU AND

OTHERS

67 INFORMATION

67 Displaying INFORMATION

68 Configuring Brightness and Contrast in

the Initial Screen

69 Configuring Volume in the Initial Screen

INSTALLING THE

SOFTWARE

70 Easy Setting Box

70 Installing the Software

71 Removing the Software

TROUBLESHOOTING

GUIDE

72 Requirements Before Contacting

Samsung Customer Service Center

72 Testing the Product

72 Checking the Resolution and Frequency

72 Check the following.

75 Q & A

SPECIFICATIONS 77 General

78 PowerSaver

79 Standard Signal Mode Table

APPENDIX 81 Contact SAMSUNG WORLD WIDE

82 Responsibility for the Pay Service (Cost

to Customers)

82 Not a product defect

82 A Product damage caused by customer's fault

82 Others

Table Of Contents

Table Of Contents 6

83 Correct Disposal

83 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

84 Terminology

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cable from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cable to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

Precautions for storage

High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used

nearby.

Be sure to contact Samsung Customer Service Center (page 81) if the inside of the monitor needs

cleaning. (A service fee will be charged.)

10 cm

Before Using the Product

Safety Precautions

Symbols

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR

BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO

QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside. It is dangerous to

make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and

maintenance has been included with this product.

Warning A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

This manual suits for next models
