English-1

Viewing the Connection Panel

Whenever you connect an audio or video system to your set, ensure that all elements are

switched off.

Connecting an Aerial or Cable Television Network

To view television channels correctly, a signal must be received by the set from one of the following sources:

- An outdoor aerial

- A cable television network

- A satellite network

Connecting Set-Top Box, VCR or DVD

- Connect the CR or D D SCART cable to the SCART connector of the CR or D D.

- If you wish to connect both the Set-Top Box and CR (or D D), you should connect the Set-Top Box

to the CR (or D D) and connect the CR (or D D) to your set.

Input Output Specification

Power Input

Connector

SCART 1

SCART 2

Video Audio (L/R) S-Video R B Video+Audio (L/R)

Only T Out

Monitor Out

(T /Ext.1/Ext.2/A /S- HS)

Input Output

BN68-00751C-00Eng 7/20/04 5:20 PM Page 7

English-2

Installing VESA Com liant Mounting Devices (Sold separately)

<1> <2>

Align the mounting interface pad with the holes in the rear cover mounting pad and secure it with the four

screws that come with the arm-type base, wall mount hanger or other bases.

This T accepts a 200mmx100mm ESA-Compliant mounting interface pad.

Rear cover Mounting pad

1. Remove the 4 screws from the back of the T .

2. Separate the stand from the T .

3. Cover the botton hole with a cap.

<3>

Disconnecting the stand

BN68-00751C-00Eng 7/20/04 5:21 PM Page 54

English-3

Using the Anti-Theft Kensington Lock

1. Insert the locking device into the Kensington slot on the LCD TV (Figure 1), and turn it in the locking direction

(Figure 2).

2. Connect the Kensington lock ca le.

3. Fix the Kensington lock to a desk or a heavy stationary o ject.

The Kensington lock is a device used to physically fix the system when using it in a pu lic place.

The locking device has to e purchased separately. The appearance and locking method may differ from

the illustration depending on the manufacturer. Please refer to the manual provided with the Kensington lock for

proper use.

Figure 2

Figure 1

Ca le

<Optional>

BN68-00751C-00Eng 7/20/04 6:41 PM Page 55
