Samsung ST5500 Instruction manual

Quick Start Manual

ST5500

This Quick Start Manual has been specially designed to guide

you through the basic functions and features of your device.

Please read the Quick Start Manual and User Manual carefully

to ensure safe and correct use.

For more information, refer to

the User Manual included on the

supplied CD-ROM.

ENG / GER / FRE / SPA / ITA / DUT / POR

ST5500_QSM_EUR1.indb 3 2010-03-04 오전 9:19:41

Health and safety informationContents

Warnings

Do not use your camera near ﬂammable or explosive

gases and liquids

Do not use your camera near fuels, combustibles, or

ﬂammable chemicals. Do not store or carry ﬂammable

liquids, gases, or explosive materials in the same

compartment as the camera or its accessories.

Keep your camera away from small children and pets

Keep your camera and all accessories out of the reach of

small children and animals. Small parts may cause choking

or serious injury if swallowed. Moving parts and accessories

may present physical dangers as well.

Prevent damage to subjects’ eyesight

Do not use the ﬂash in close proximity (closer than 1m/

3 ft) to people or animals. Using the ﬂash too close to your

subject’s eyes can cause temporary or permanent damage.

Health and safety information 2

Camera layout ……………… 4

Setting up your camera …… 5

Unpacking ……………………… 5

Inserting the battery and

memory card …………………… 6

Charging the battery …………… 6

Turning on your camera………… 7

Using the touch screen ………… 7

Capturing photos or videos 8

Playing ﬁles ………………… 9

Transferring ﬁles to a PC

(Windows) …………………… 9

Using photo or video sharing

websites……………………… 10

Speciﬁcations ………………11

101

126

ST5500_QSM_EUR1.indb 2 2010-03-04 오전 9:19:41

English

Do not insert foreign objects into any of your camera’s•

compartments, slots, or access points. This type of

damage may not be covered by your warranty.

Protect batteries, chargers, and memory cards from

damage

Avoid exposing batteries or memory cards to very•

cold or very hot temperatures (below 0° C/32° F or

above 40° C/104° F). Extreme temperatures can

reduce the charging capacity of your batteries and

can cause memory cards to malfunction.

Do not allow liquids, dirt, or foreign substances to•

come in contact with memory cards or the memory

card slot. Doing so may cause memory cards or the

camera to malfunction.

Do not use memory cards that have been formatted•

by other cameras or by a computer. Reformat the

memory card with your camera.

Follow all safety warnings and regulations

Comply with any regulations that restrict the use of a

camera in a certain area.

Handle and dispose of batteries and chargers with

care

Use only Samsung-approved batteries and chargers.•

Incompatible batteries and chargers can cause serious

injuries or damage to your camera.

Never place batteries or cameras on or in heating•

devices, such as microwave ovens, stoves, or

radiators. Batteries may explode when overheated.

Cautions

Handle and store your camera carefully and sensibly

Do not allow your camera to get wet—liquids can•

cause serious damage. Do not handle your camera

with wet hands. Water damage to your camera can

void your manufacturer’s warranty.

Avoid using or storing your camera in dusty, dirty,•

humid, or poorly-ventilated areas to prevent damage

to moving parts and internal components.

Exercise caution when connecting cables or adapters•

and installing batteries and memory cards. Forcing

the connectors, improperly connecting cables, or

improperly installing batteries and memory cards can

damage ports, connectors, and accessories.

ST5500_QSM_EUR1.indb 3 2010-03-04 오전 9:19:41

Shutter button

Flash

POWER button

Microphone

AF-assist light/timer lamp

Internal antenna

Lens

Speaker

Battery chamber cover

Camera layout

Playback button

Status lamp

Zoom button

HDMI port (Accepts HDMI cable)

USB and A/V port

(Accepts USB cable or A/V cable)

Touch screen

Tripod mount

1 2

4 5

8 7

ST5500_QSM_EUR1.indb 4 2010-03-04 오전 9:19:42

English

Setting up your camera

Camera AC adapter/

USB cable

Rechargeable battery Strap

Quick Start Manual User Manual CD-ROM Cradle Touch pen

Unpacking

Optional accessories

Camera case Memory card

(microSD

)

A/V cable Battery charger HDMI cable

ST5500_QSM_EUR1.indb 5 2010-03-04 오전 9:19:42

Setting up your camera

Inserting the battery and memory card Charging the battery

▼

Removing the battery

▼

Removing the memory card

Push gently until the card

disengages from the camera

and then pull it out of the slot.

With the Samsung

logo facing down

With the gold-

coloured contacts

facing up

Before using the camera for the ﬁrst time, you must

charge the battery.

Indicator light

Red▪: Charging

Green▪: Fully charged

ST5500_QSM_EUR1.indb 6 2010-03-04 오전 9:19:42

English

Press [

POWER] to turn your camera on or off.

The initial setup screen appears when you turn on▪

your camera for the ﬁrst time.

Select a language, set the date and time,

select a time zone, and calibrate the screen.

Use the supplied touch pen to touch or drag on the

screen.

Caution

Do not use other sharp objects, such as pens or pencils,

to touch the screen. Doing so may damage the screen.

Touching

Touch an icon to

open a menu or

set an option.

-2 -1 0+2-2 -

2+1

Dragging

Drag left or

right to scroll

horizontally.

Turning on your camera Using the touch screen

ST5500_QSM_EUR1.indb 7 2010-03-04 오전 9:19:42

Recording a video

Select

a→v.

Align your subject in the frame.

Press [

Shutter].

To pause, select▪.

To resume, select▪.

Press [

Shutter] again to stop recording.

Note

Number of photos by resolution (for 1 GB microSD

)

Resolution Super ﬁne Fine Normal

4320 X 3240 122 240 353

4000 X 3000 142 278 409

3984 X 2656 160 312 454

3840 X 2160 206 401 588

3264 X 2448 211 409 594

2560 X 1920 335 637 908

2048 X 1536 510 936 1,314

1920 X 1080 762 1,373 1,931

1024 X 768 1,626 2,575 3,090

These ﬁgures are measured under Samsung’s standard conditions and may

vary depending on shooting conditions and camera settings.

Taking a photo

Make sure that the camera is in the

amode

(Auto mode).

Align your subject in the frame.

Press [

Shutter] halfway down to focus

automatically.

A green frame means the subject in focus.▪

Press [

Shutter] all the way down to take the

photo.

Capturing photos or videos

ST5500_QSM_EUR1.indb 8 2010-03-04 오전 9:19:43

English

Playing ﬁles

Viewing photos

Press [

Playback].

Draw a horizontal bar left or right,

or select <or >to scroll through photos.

You can also view ﬁles by tilting your camera.▪

Viewing videos

Press [

Playback] and select .

Use the following icons to control playback.

Scan backward

Pause or resume playback

Stop playback

Scan forward

Adjust volume or mute sound

Transferring ﬁles to a PC

(Windows)

Connect the camera to your computer with the

USB cable.

Note

Make sure that the PC Software option is set to On in the

settings menu.

Turn on the camera.

The computer recognizes the camera automatically.▪

For Windows Vista, select▪Run iStudio.exe from

the AutoPlay window.

Select a folder on your computer to save new

ﬁles.

If your camera has no new ﬁles, the window to save▪

new ﬁles will not appear.

Select

Yes.

New ﬁles will be transferred to your computer.▪

You can now use the Intelli-studio program.

Note

About Intelli-studio

Intelli-studio is a built-in program that allows you to play

back and edit ﬁles. You can also upload ﬁles to websites,

such as Flickr or YouTube.

ST5500_QSM_EUR1.indb 9 2010-03-04 오전 9:19:43

Accessing a website

In Shooting or Playback mode, select

N→.

The camera will search for and display available▪

AP devices.

Select an AP device.

The camera will connect to the WLAN.▪

If the selected AP device requires a password,▪

enter a password.

If the camera fails to connect to the WLAN▪

automatically, connect to it manually. For more

information about connecting to the WLAN,

contact your network administrator or network

service provider.

Select a website.

Enter your login ID and password, and select

Uploading photos or videos

Select

<or >to scroll through ﬁles.

Drag photos or videos to the selection area or

select photos or videos, and select OK.

Date

Select▪Date to categorize the ﬁles.

Enter a title and select an album, and then

select .

Note

The speed of your internet connection may affect how•

quickly photos upload or web pages open.

You may not be able to send an email due network•

connection or email account settings.

Using photo or video sharing websites

ST5500_QSM_EUR1.indb 10 2010-03-04 오전 9:19:43
