Samsung SM-T515 User manual

SM-T515/T510/T517

Common

Mobile Device

CONTENTS

1. Safety Precautions

2. Specification

3. Product Function

4. Exploded View and Parts list

5. MAIN Electrical Parts List

6. Level 1 Repair

7. Level 2 Repair

8. Level 3 Repair

9. Reference Abbreviation

Notice: All functionality, features, specifications,

and other product information provided in this

document, including but not limited to, benefits,

design, pricing, components, performance,

availability, and capabiliti-es of the product are

subject to change without notice. Samsung

reserves the right to alter this doc-ument or the

product described herein at anytime, without

obligation to provide notification of such

changes.

This Service Manual is a property of Samsung Electronics Co.,Ltd.

Any unauthorized use of Manual can be punished under applicable

International and/or domestic law.

Samsung Electronics Co.,Ltd

2019. 03. Rev 1.0

ⓒ

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

1. Safety Precautions

1-1. Repair Precaution

Before attempting any repair or detailed tuning, shield the device from RF noise or static

electricity discharges.

Use only demagnetized tools that are specifically designed for small electronic repairs,

as most electronic parts are sensitive to electromagnetic forces.

Use only high quality screwdrivers when servicing products. Low quality screwdrivers can

easily damage the heads of screws.

Use only conductor wire of the properly gauge and insulation for low resistance, because of the low margin

of error of most testing equipment.

We recommend 22-gauge twisted copper wire.

Hand-soldering is not recommended, because printed circuit boards (PCBs) can be easily

damaged, even with relatively low heat. Never use a soldering iron with a power rating of

more than 100 watts and use only lead-free solder with a melting point below 250°C (482°F).

Prior to disassembling the battery charger for repair, ensure that the AC power is disconnected.

Always use the replacement parts that are registered in the SEC system. Third-party replacement parts

may not function properly.

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

1. Safety Precautions

1-2. ESD(Electrostatically Sensitive Devices) Precaution

Many semiconductors and ESDs in electronic devices are particularly sensitive to static discharge and can

be easily damaged by it. We recommend protecting these components with conductive anti-static bags

when you store or transport them.

Always use an anti-static strap or wristband and remove electrostatic buildup or dissipate

static electricity from your body before repairing ESDs.

Ensure that soldering irons have AC adapter with ground wires and that the ground wires are properly

connected.

Use only desoldering tools with plastic tips to prevent static discharge.

Properly shield the work environment from accidental electrostatic discharge before opening

packages containing ESDs.

The potential for static electricity discharge may be increased in low humidity environments,

such as air-conditioned rooms. Increase the airflow to the working area to decrease the

chance of accidental static electricity discharges.

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

2. Specification

[SM-T515/T517]

2-1. GSM General Specification

Item

GSM 850

EGSM 900

DCS1800

PCS1900

Freq. Band[MHz]

Uplink/Downlink

824~849

869~894

880~915

925~960

1710~1785

1805~1880

1850~1910

1930~1990

ARFCN range

128~251

0~124 & 975~1023

512~885

512~810

Tx/Rx spacing

45MHz

95MHz

80MHz

Mod. Bit rate/

Bit Period

270.833kbps

3.692us

270.833kbps

3.692us

270.833kbps

3.692us

270.833kbps

3.692us

Time Slot Period/

Frame Period

576.9us

4.615ms

576.9us

4.615ms

576.9us

4.615ms

576.9us

4.615ms

Modulation

0.3GMSK

GMSK/

8PSK

MS Power

33dBm~5dBm

30dBm~0dBm

Power Class

5pcl ~ 19pcl

0pcl ~ 15pcl

Sensitivity

-102dBm

-100dBm

TDMA Mux

Cell Radius

35Km

2Km

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

2. Specification

2-2. WCDMA General Specification

Item

WCDMA

2100

WCDMA

900

WCMDA

850

WCDMA

1900

WCDMA

AWS-1

Freq. Band[MHz]

Uplink/Downlink

1922~1977

2112~2167

880~915

925~960

824~849

869~894

1852~1907

1932~1987

1712~1752

2112~2152

ARFCN range

UL:

9612~9888

DL:

10562~10838

UL:

2712~2863

DL:

2937~3088

UL:

4132~4233

DL:

4357~4458

UL:

9612~9888

DL:

10562~10838

UL:

1312~1513

DL:

1537~1738

Tx/Rx spacing

190MHz

45MHz

80MHz

400MHz

Mod. Bit rate/

Bit Period

3.84Mcps

3.8Mcps

Time Slot Period/

Frame Period

FrameLength:

10ms

Slotlength:

0.667ms

FrameLength:

10ms

Slotlength:

0.667ms

FrameLength:

10ms

Slotlength:

0.667ms

FrameLength:

10ms

Slotlength:

0.667ms

FrameLength:

10ms

Slotlength:

0.667ms

Modulation

QPSKHQPSK

MS Power

(dBm)

24dBm~

-50dBm

24dBm~

-50dBm

24dBm~

-50dBm

24dBm~

-50dBm

24dBm~

-50dBm

Power Class

3(max+24dBm)

Sensitivity

-106.7dBm

TDMA Mux

Cell Radius

2Km

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

2. Specification

2-3. LTE General Specification

Item

LTE Band1

LTE

Band2

LTE Band3

LTE

Band4

LTE Band5

Freq. Band[MHz]

Uplink/Downlink

1920~1980

2110~2170

1850~1910/

1930~1990

1710~1785

1805~1880

1710~1755/

2110~2155

824~849

869~894

ARFCN range

UL:

18000~18599

DL:

0~599

UL:

18600~19199

DL:

600~1199

UL:

19200~19950

DL:

1805~1880

UL:

19950~20399

DL:

1950~2399

UL:

20400~20649

DL:

2400~2649

Tx/Rx spacing

(MHz)

190MHz

80MHz

95MHz

400MHz

45MHz

Channel Bandwidth

(MHz)

5/10/15/20 MHz

1.4/3/5/10/15/20

MHz

1.4/3/5/10/15/20

MHz

1.4/3/5/10/15/20

MHz

1.4/3/5/10 MHz

Modulation

QPSK,16/64QAM

MS Power

(dBm)

-35~25.7 dBm

-35~25.7 dB

-35~25.7 dBm

-35~25.7 dB

-35~25.7 dBm

Sensitivity

(QPSK, BW 10MHz)

(dBm)

-96.3 dBm

-94.3dBm

93.3 dBm

-96.3dBm

-94.3 dBm

Cell Radius

>5Km

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

2. Specification

Item

LTE Band7

LTE Band8

LTE Band12

LTE Band17

LTE Band20

Freq. Band[MHz]

Uplink/Downlink

2500~2570

1805~1880

880~914.9

925~959.9

699~716/

729~746

704~716/

734~746

832~862

791~821

ARFCN range

UL:

2500~2570

DL:

2620~2690

UL:

21450-21799

DL:

3450-3799

UL:

23010~23179

DL:

5010~5179

UL:

23730~23849

DL:

5730~5849

UL:

24150~24450

DL:

6150~6450

Tx/Rx spacing

(MHz)

120MHz

45MHZ

30MHz

-41MHz

Channel Bandwidth

(MHz)

5/10/15/20 MHz

1.4/3/5/10MHz

1.4/3/5/10 MHz

5/10MHz

5/10/15/20 MHz

Modulation

QPSK,16/64QAM

MS Power

(dBm)

-35~25.7 dBm

Sensitivity

(QPSK, BW 10MHz)

(dBm)

-94.3dBm

-93.3dBm

Cell Radius

>5Km

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

2. Specification

Item

LTE Band28

LTE Band66

LTE Band38

LTE Band40

Freq. Band[MHz]

Uplink/Downlink

703~748/

758~803

1710~1780/

2110~2200

2570~2620

2300~2400

ARFCN range

UL:

27210~27659

DL:

9210~9659

UL:

131972~132671

DL:

66436~67335

37750~38249

38650~39649

Tx/Rx spacing (MHz)

55MHz

400MHz

Channel Bandwidth

(MHz)

3/5/10/15/20 MHz

1.4/3/5/10/15/20

MHz

5/10/15/20 MHz

Modulation

QPSK,16/64QAM

MS Power

(dBm)

-35~25.7 dBm

Sensitivity

(QPSK, BW 10MHz)

(dBm)

-93.3dBm

Cell Radius

>5Km

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

2. Specification

[SM-T510]

Not applicable
