Samsung SGH-S300 User manual
SGH-S300
WAP Browser
User’s Manual
ELECTRONICS
* Some of the contents in this manual may differ from your phone,
depending on the software installed or your service provider.
Printed in Korea
Code No.: GH68-03352A
English. 12/2002. Rev. 1.0
World Wide Web
http://www.samsungmobile.com
2
What is WAP?
WAP (Wireless Application Protocol) is the
gateway to a new world of mobile data. It
provides a universal standard, enabling you
to access Web-based interactive information
services and applications directly from your
mobile phone.
3
Contents
About the WAP Browser............................ 4
Setting Up the WAP Browser..................... 5
Accessing the WAP Browser ...................... 5
Configuring the WAP Browser.................... 7
Getting Started ......................................... 10
Starting the WAP Browser......................... 10
Exiting the WAP Browser .......................... 10
Using the WAP Browser ............................ 11
Using the Soft Keys.................................. 11
Navigating the WAP Browser ..................... 11
Entering Text, Numbers or Symbols ........... 12
Using the WAP Browser Menus ................. 13
Using and Selecting Menu Options ............. 13
Reload ................................................... 13
Home..................................................... 14
Go to URL............................................... 14
Show URL............................................... 14
Edit Home .............................................. 15
4
About the
WAP Browser
Your phone comes equipped with a WAP (Wireless
Application Protocol) Browser which makes it
possible for you to access the Wireless Web.
The WAP Browser allows you to:
• access up-to-the-minute information via your
phone
• view specially designed text versions of popular
Internet sites including Yahoo!
®
, CNN Mobile
SM
and the Weather Channel
®
Browsing the Wireless Web using your phone is
unlike using your computer, in that site providers
have:
• selected only the critical aspects of their site for
wireless phone users
• removed most graphics
Each time you start the WAP Browser, the phone
connects to the Wireless Web and the service
indicator icon ( or ) appears on the display
to inform you that you are:
• are connected to the Wireless Web
• will be billed accordingly (rates vary according to
your service option)
The WAP Browser ends the network connection
after a certain period of inactivity and automatically
reconnects as necessary. For this reason, you may
find that you are billed for several network
connections within a single session. This is normal
and is designed to minimise your bill.
5
Setting Up the
WAP Browser
Before using the WAP Browser, you must set the
parameters for the proxy server used by your
service provider.
Accessing the WAP Browser
To access the WAP Browser menu:
1. When the idle screen displays, press the
Menu
soft key to enter menu mode.
2. Press the or key one or more times until
the
Funbox
menu option displays, and then
press the
Select
soft key. You can also press
the key directly.
Service Provider
07:30
Wed 06 Mar
Menu Name
7
Organiser
Network
Services
Funbox
Select
Setting Up the WAP Browser
6
3. Press the or key one or more times to
highlight
WAP Browser
, and then press the
Select
soft key. You can also press the key
directly.
4. Press the or key one or more times to
highlight the required option and then press the
Select
soft key.
.
Option Description
Home Connects the phone to the
network and loads the homepage
of the Wireless Web service
provider.
Favorite Allows you to store the URL
addresses of your favourite Web
sites. You can access this menu
directly by pressing and holding
down the
key while using the
WAP Browser.
7.2
Select
Funbox
Games
WAP Browser
Downloads
7.2.1
WAP Browser
Home
Favorite
http://
Clear Cache
Select
Settings
Setting Up the WAP Browser
7
Configuring the WAP Browser
To configure the WAP Browser:
1. In the WAP Browser menu, highlight
Settings
using the and keys, and then press the
Select
soft key. You can also press the key
directly.
Favorite
(continued)
To store a URL address, select an
empty location and enter the
address. Three submenus are
available. Select Goto URL to
access the site quickly, Edit to
edit the selected address and
Erase to delete the selected
address.
http:// Allows you to manually enter a
URL address of the Web site that
you wish to access.
Settings Allows you to set up five proxy
servers for the WAP Browser.
Clear
Cache Clears the information stored in
the cache (the phone’s temporary
memory used to store the most
recently accessed Web pages).
Push
Message
Allows you to set whether or not
you will receive Web messages
from the server, and read or
delete the messages received.
Option Description
Setting Up the WAP Browser
8
2. Select a proxy server and enter the parameters
required. Contact your service provider for
details.
The remaining options depend on the
Bearer
setting, as indicated below.
When the bearer is set to
Data
Parameter
Description
Profile
Name
Name that you wish to assign to
the HTTP proxy server.
Homepage
URL
Address of your startup
homepage. When the default
homepage displays, you can
delete it using the key and
enter your own choice.
Security
Data transmission mode. Choose
Secure
to protect your data
against unauthorised access;
otherwise, choose
Non-Secure
.
IP Address
WAP gateway address required to
connect to the Internet.
Bearer
Bearer to be used for each type of
network address accessed:
GPRS
or
Data
.
Parameter Description
Login
Name
PPP server login ID.
Password
PPP server password.
Dial-up
Number
PPP server phone number.
Data Call
Type
Data call type:
Analogue
or
ISDN
.
Setting Up the WAP Browser
9
When the bearer is set to
GPRS
Note
: The WAP Browser settings may vary,
depending on the service provider. Contact
your service provider for further information.
3. After selecting each of these settings, a dialog
box displays; you can either enter the
information required or choose between given
options. When you are satisfied with your input,
press the
OK
soft key.
4. When you have finished configuring the WAP
Browser, press the key or the right soft
key.
Parameter Description
User Name
User ID required to connect to the
GPRS network.
Password
Password required to connect to
the GPRS network.
APN
Access point name used for the
address of the GPRS network
gateway.
10
Getting
Started
Starting the WAP Browser
To start the WAP Browser when the idle screen
displays, press the key or press the
Menu
soft
key, followed by the , and keys.
A connection is established with your service
provider and the corresponding homepage displays.
The content of the WAP Browser startup homepage
depends on your Wireless Web service provider. To
scroll through the screen, use the and keys.
Note
: To access the startup homepage from any
other screen in the WAP Browser, use the
Home
option. For more information on the
WAP Browser menus, refer to page 13.
Exiting the WAP Browser
To exit the browser at any time, simply press
the key or press and hold down the key.
11
Using the
WAP Browser
Using the Soft Keys
A bar containing browser commands is located at
the bottom of the WAP Browser display. The soft
keys below the bar are used to execute these
commands. The two keys are called soft keys
because their function changes depending on the
WAP Browser application in use.
Navigating the WAP Browser
To... Then...
scroll through and
select browser
items
press the or key
until the symbol points to
the required item, and then
press the
OK
soft key to
confirm the selection.
select a numbered
item press the corresponding
numeric key.
return to the
previous page press the
Back
soft key or
the key.
return to the
startup homepage select the
Home
menu
option; for more information
on this option, refer to
page 14.
Using the WAP Browser
12
Entering Text, Numbers or Symbols
When you are prompted to enter text, the current
text entry mode is indicated on the screen. The
following modes are available.
Note:
To enter symbols, press the key until the
required symbol displays.
Mode Description
Allows you to enter letters in the
alphabet. Press the corresponding
key until the required letter displays.
Allows you to enter numbers.
To... Then...
change
modes
press the key one or more
times.
enter a space
press the key.
edit text
• set the cursor to the right of
the character(s) to be
corrected.
• press the key as required.
• enter the correct character(s).
13
Using the WAP
Browser Menus
Using and Selecting Menu Options
Various menu options are available when you are
using the WAP Browser to navigate the Wireless
Web.
To access a menu option:
1. Press and hold down the key.
A menu displays.
2. Highlight the required menu option by using the
and keys.
3. Select the option by pressing the
Select
soft
key.
4. If necessary, select the secondary option using
the and keys, and press the
Select
soft
key to confirm.
Note:
The menus may vary, depending on your
version of the WAP Browser.
Reload
This option reloads the current page.
Using the WAP Browser Menus
14
Home
This option takes you back at any time to the
homepage of the Wireless Web service provider.
Go to URL
This option allows you to manually enter the URL
address of the required Web page.
After entering an address, press the
OK
soft key to
go there directly.
Show URL
This feature displays the URL address of the site to
which you are currently connected. It also enables
you to declare the current site as the startup
homepage.
To... Press the...
declare the current
page as your
startup homepage
Option
soft key, select the
Save to Home
option and
press
Select
.
set a bookmark for
the current page
Option
soft key, select the
Save to Bookmark
option
and press
Select
.
cancel your setting
Back
soft key.
Using the WAP Browser Menus
15
Edit Home
With this feature, you can change the startup
homepage manually.
To change the homepage, enter the required URL
and press the
OK
soft key.
For more information on entering text, numbers or
symbols, refer to page 12.
Other manuals for SGH-S300
5
This manual suits for next models
2
Table of contents
Other Samsung Cell Phone manuals
Samsung
Samsung SGH-P270 User manual
Samsung
Samsung SGH-T599N User manual
Samsung
Samsung SGH-X168 User manual
Samsung
Samsung Galaxy Note II Specification sheet
Samsung
Samsung SGH-G800 User manual
Samsung
Samsung Sprint Vision M300 User manual
Samsung
Samsung SM-F731U1 User manual
Samsung
Samsung GH68-60614A User manual
Samsung
Samsung GT-E1085L User manual
Samsung
Samsung SM-G9500 User manual
Samsung
Samsung Factor SPH-M260 User manual
Samsung
Samsung GT-S5270K User manual
Samsung
Samsung SGH-T959V User manual
Samsung
Samsung M2710 User manual
Samsung
Samsung GT-C3300 User manual
Samsung
Samsung SM-T560 User manual
Samsung
Samsung SCH-W531 User manual
Samsung
Samsung 2.0040414141623e16 User manual
Samsung
Samsung Galaxy S 5 Active User manual
Samsung
Samsung GT-E2250 User manual
