Samsung R100 User manual

Quick-Start Guide

pms226pms1235pms2603 pms298

Your Samsung R100

Earpiece

Volume

Display

Navigation Key

Left Select Key

Send Key

Microphone

Headphone

Jack

Power

Connector

OK/Select Key

Right Select Key

End Key

Clear Key

Installing and removing the battery

Your phone comes packaged with a partially-

charged rechargeable Lithium-Ion battery

and travel adapter.

You must fully charge the battery the rst

time you use your phone, otherwise you

could damage the battery.

Battery cover

Remove the battery cover to access the battery.

•To remove the battery cover,

press on the arrow while

sliding the cover, then lift the

battery cover slightly and slide

the cover off.

•To replace the battery cover,

press the top end of the

battery cover down lightly,

and slide it over the battery

until it clicks into place.

•Match the gold

contacts on the

battery to those on

the phone, then press

the battery down into

the phone.

Remove the battery

Before removing the battery, turn off the phone by

pressing and holding down the END key .

•Lift the end of the battery up and out of

the phone.

Install the battery

Charging the battery

Your phone is powered by a rechargeable standard

Lithium-Ion battery. Only use Samsung-approved

charging devices and batteries. Samsung accessories

are designed to maximize battery life. Use of other

accessories may invalidate your warranty and may

cause damage.

Using the travel charger

The travel charger included with your phone is a

convenient, lightweight charger that rapidly charges

your phone from any 120/220 VAC outlet.

1. Plug the large end of the travel charger into a

standard 120 VAC or 220 VAC wall outlet.

incorrect

correct

2. Insert the small end of the travel charger into the

charger/accessory connector on the side of your

phone. You must unplug the adapter before

removing the battery from the phone during

charging to avoid damage.

Low battery indicator

The battery indicator in the upper-right corner of the

display indicates power level. Monitor the battery

strength and ensure your battery is adequately

charged. If you continue to use your phone without

charging its battery, the phone will shut down.

•Five bars indicate a full charge.

•An empty battery icon indicates a near-

empty battery.

•A blinking empty battery icon and an audible

tone indicate you have two to three minutes

before the battery is too low to operate the phone.

Call functions

Turning your phone on

 • Press and hold the END key until the display

becomes lit. The phone searches for a network

signal, and the time, date, and day appear on

the display.

Making a call

There are 3 ways to make a call:

1. From the main display, enter the telephone number

you wish to call using the keypad and press the

SEND key to place the call.

2. Go to your contacts and scroll to the number you

want to call, then press the SEND key .

3. Press the SEND key to easily access your call

history. Scroll to the number you want to call and

press the SEND key .

Answering a call

Incoming

To answer a call, simply press the SEND key . To

silence an incoming call simply press the END key .

When you receive a call, the phone displays one of

the following:

• If the caller can be identied, the caller’s number (or

name if it’s in your contacts) appears in the display.

• If the caller cannot be identied, Call from

unavailable #, Call from restricted #, or no

number appears in the display.

Ending a call

 • To end any call, simply press the END key

while on the call.

Turning your phone off

 • Press and hold the END key for two or

more seconds. Your phone powers off.

Your contact list

Your Samsung R100 will come with 2 phone numbers

in your contact list. These numbers will easily help you

reach Operator Assistance and Customer Service.

Up to 500 contacts can be stored, and each entry can

have up to ve phone numbers and one e-mail address.

Adding a new contact

Dial method

1. Using the keypad, enter the number you wish to

add to Contacts.

2. Press Save and enter the contact information.

Menu method

1. Press MENUgContacts gAdd New Entry.

2. Enter the contact info of the new entry, then

press Save.

Finding a contact

Shortcut key/menu method

If you’ve stored a name entry in Contacts, Find allows

you to nd it quickly.

1. From the main display, select MENU

gContacts

gFind, or press the Right Select key . The Find

screen appears in the display with the Go To eld

and the rst contacts entry highlighted.

2. Press key(s) to show contacts matching the key

sequence, using the abc text entry method.

Deleting a contact

1. Find and select the contact to be deleted.

See “Finding a contact” on the previous page.

2. Press Options gErase.

Editing a contact

1. Find and select the contact to be changed.

See “Finding a contact” on the previous page.

2. Press Edit and make the desired changes.

GreatCall’s Operator Assistance only

deducts 5 minutes plus airtime for Directory

Assistance calls. To use this service, simply

go to your contact list and call “Operator”.
