Samsung BLACKJACK II User manual

Getting Started Guide

BJ2_GSG_combinedFINAL_readerSpreads.indd 1 10/29/07 2:09:08 PM

Set up Your BlackJack™ II 4

What’s in the Box? 4

Insert Battery 5

Charge Battery 5

Insert microSD™ Card 5

Get to Know Your BlackJack™ II 6

Learn to Navigate the Screen 8

Using the Keyboard 9

Use the Phone 10

Make a Call 10

Answer a Call 10

Set Up Voicemail 11

Check Voicemail 11

Use Text/Multimedia Messaging & IM 12

Send a Text/Multimedia Message 12

Instant Messaging 13

Use the Camera 14

Take & Send a Picture 14

Take & Send a Video 15

Video Share™ 16

Make a Call Using Video Share™ 16

Browse the Web & Shop Online 18

Go to Web Pages 18

Use MEdia™ Net 18

AT&T Mall 19

Table of Contents

BJ2_GSG_combinedFINAL_readerSpreads.indd 2 10/29/07 2:09:08 PM

Set Up Your Email 20

Personal Email Setup With Xpress Mail 20

Send and Receive Personal Email 23

Corporate Email Setup 24

IT Managed 25

Sync Your Device to Your PC 26

Set up Bluetooth® 27

Set up TeleNav GPS Navigator™ 28

TeleNav GPS Navigator™ 28

Download and Installation Instructions 28

Generate A Route 29

Exiting TeleNav GPS Navigator™ 29

Listen to Music & Watch TV & Video 30

AT&T Mobile Music 30

Transfer Music & Video to Your Device 31

Play Music 32

Stream Music (XM Radio®) 32

Watch CV 33

Watch MobiTV® 33

Office Mobile 34

View Your Documents 34

Manage Contacts & Appointments 35

Add a Contact 35

Schedule an Appointment 35

Troubleshooting 36

Tips & Tricks 42

BJ2_GSG_combinedFINAL_readerSpreads.indd 3 10/29/07 2:09:09 PM

What’s in the Box?

To get started, we recommend the following:

Carefully follow the step-by-step instructions in this guide to set up•

your device.

Review the User Manual• (by clicking the proper link) on the Getting

Started CD to learn about the full power of the BlackJack™ II.

Take note of the following components included in the box:

Set up Your BlackJack™ II

Standard Battery

Getting Started CD

Travel Charger

Data Cable

BlackJack™ II

BJ2_GSG_combinedFINAL_readerSpreads.indd 4 10/29/07 2:09:10 PM

Insert Battery

1. Remove the battery cover.

2. Align the contacts on the battery with the

contacts in the back of the device.

3. Push the battery down until it locks into place.

4. Replace the battery cover.

Charge Battery

1. Plug the AC Travel Charger into a standard AC

wall outlet.

2. Plug the travel charger into the jack on the left side of

the phone. The indicator light at the top of the device

is red while charging, and green when fully charged.

Note: When charging is complete, unplug the charger

from the power outlet.

Insert microSD™ Card

A microSD™ Card is a removable memory card that will

increase data storage capacity of the device.

1. Remove the cover on the right side of the device,

that reads microSD™.

2. Insert the narrow end of the microSD™ Card into the

slot, then replace the cover.

Note: microSD™ Card sold separately.

BJ2_GSG_combinedFINAL_readerSpreads.indd 5 10/29/07 2:09:26 PM

Get to Know Your BlackJack™ II

Open the back flap of the Getting Started Guide to review diagram

of key locations and functions. We recommend that you keep this

diagram open for reference while working through the guide.

Turn On/Off Your Device

Press and hold the Power ON/OFF Button located on the top of

the device.

Lock/Unlock Your Device Keypad

To Lock the device, press and hold the END key. To unlock the device,

press the Power ON/OFF Button then the LEFT SOFT key, followed

by the *key. If the device is locked, and backlight is off, quick press the

Power key.

Backlight

In the unlock mode, after 30 seconds the screen will dim to save battery

power. It will finally power off after 40 seconds. To turn your screen on,

press any key.

Change Backlight Settings

Press the LEFT SOFT key to enter the Start menu.

Select Settings, then select Power Management.

Scroll down to Display time out, or Backlight time

out on battery, Press the LEFT or RIGHT side of

the NAVIGATION key to change the Display Time

Out settings.

Get to Know Your BlackJack™ II

BJ2_GSG_combinedFINAL_readerSpreads.indd 6 10/29/07 2:09:27 PM

Check Your Wireless AT&T Connection

On the top right corner of the home screen, you will find the network

coverage indicator.

Full wireless 3G data coverage

Full wireless coverage (no data connection)

No wireless coverage

Wireless is turned off

Status Indicators

Battery level 3G network

Low battery Signal strength

Battery charging New email or text message

Bluetooth on New voice mail

BJ2_GSG_combinedFINAL_readerSpreads.indd 7 10/29/07 2:09:28 PM

Learn to Navigate the Screen

To move around the screen, press the NAVIGATION key up, down, left or

right. Press the center of the CENTER NAVIGATION key to select.

Or, to move around the screen spin the FRONT JOG WHEEL (black disc

around the CENTER NAVIGATION key). The FRONT JOG WHEEL can

also be used to enlarge or reduce images on screen when in ZOOM mode.

To select the bottom left

and right items on the

screen, use the LEFT

and RIGHT SOFT keys.

Get to Know Your BlackJack™ II

NAVIGATION KEY &

FRONT JOG WHEEL

RIGHT SOFT KEY

activates menu

above

LEFT SOFT KEY

activates menu

above

For more information visit att.com/DeviceSupport or for Quick Tips go

to Start<Settings<QuickTips

BJ2_GSG_combinedFINAL_readerSpreads.indd 8 10/29/07 2:09:30 PM

MEdia™ Net

CV symbol/

space camera/zoom

mailsilent

Using the Keyboard

Your BlackJack™ II is equipped with an innovative keyboard. You can easily and

accurately type words with the keypad. When you select a field that requires

text or numbers, the phone automatically selects the appropriate input mode.

However, if you need to switch between modes, press one of the keys listed in

the following illustration. See the indicator at the top of the Home Screen to

identify the current text mode setting.

Creating Text

To type a single uppercase letter, press

CAPS/SHIFT key, and then press the

corresponding key. To enter all CAPS, press

the CAPS/SHIFT key twice.

To enter a number or symbol, press the

FUNCTION key, and then press the

corresponding key. To enter all numbers or

symbols, press the FUNCTION key twice.

Task Keys

MEdia™ Net - direct access to

MEdia™ Net. See pg. 18 for details.

CV - direct access to Cellular

Video. See pg. 33 for details.

SYMBOL/SPACE - short press

inserts a space/long press brings

up additional symbols.

SILENT - turn ringtone on or off.

CAMERA/ZOOM - short press activates camera/long press enters Zoom

mode. For a full description of camera features see page 14.

MAIL - direct access to email and text messaging. See page 12 for details.

BJ2_GSG_combinedFINAL_readerSpreads.indd 9 10/29/07 2:09:31 PM

Navigation Panel

Left Soft Key Right Soft Key

Navigation Key

Note: Please see back flap for a full diagram of key functions.

Make a Call

1. From the Home screen, you can access the Phone screen

by pressing the SEND (green phone) key or by directly

entering a phone number by pressing the numeric keys

on the keypad.

2. Press the SEND key.

3. To end the call, press the END (red phone) key.

Answer a Call

1. Press the SEND key.

Note: To activate speakerphone, press and hold the SEND key

for 2 seconds. To place a call on hold or unhold, press quickly on

the SEND key.

Use the Phone

Steps

Takes

2 minutes

BJ2_GSG_combinedFINAL_readerSpreads.indd 10 10/29/07 2:09:32 PM
