Sam4s 110 Series User manual
Table of Contents
System Introduction
System Installation
Part 1
Part 2
Part 3 System Utilization
Part 4 System Extension & Disassemble
Appendix A UEFI BIOS Set Up
Appendix B System Configuration
1. Safety Notices Before Installation or Use
2. System Introduction
3. General Specifications
4. Optional Specifications
5. Name and Function of each component (Front View)
6. Name and Function of each component (Rear view)
7. Name and Function of each component (I/O)
8. Name and Function of each component (I/O - Option)
1. Checking the Location for Installation
2. Before Connecting Peripherals
• Interface cover remove
• Cable arrange cover remove
3. Connecting DC power supply cable
1. Touch Screen Usage
2. POS Driver and Utility Introduction
3. Dual Monitor Usage
4. Dual Monitor Touch Screen Usage
5. How to control Direct I/O in order to use drawer
1. Power Adaptro
2. 2 Line Display
3. Dual Display
4. IC Card Reader
5. 2.5” SDD/HDD
6. Basic I/O Module
7. M.2 / M.2 RAID
8. Memory
9. Expansion I/O Module
10. Main Board
11. Main Display
12. Touch Panel & LCD
•15 inch Main Display
•15.6 inch Main Display
1. Understanding BIOS
• Understanding BIOS Set up
2. Serial voltage change & Using Keyboard shortcut
1. System Block Diagram
• J1900
•i3 / i5
2. Main Chipset & Connector
• J1900
•i3 / i5
•I/O Board
3. Main Jumper Setting
•J1900
•i3 / i5
4. IO Pin Map
•COM1/2 RS-232 Serial Port
(DSUB9 MALE)
•COM4 RS-232 Serial Port (RJ45)
• USB Port (TYPE A)
•COM1 RS-422/485 Serial Port (DS
UB9 MALE)
•Cash Drawer Port (RJ11)
•COM3 RS-232 Serial Port (RJ45)
•LAN Port (RJ45)
•Parallel Port (D-SUB25 FEMALE)
1. Part List
•MAIN
•38.1cm(15”) Main Display
•39.62cm(15.6”) Main Display
•Main Body
•I/O Module
•Expansion I/O Module
•I/O Cover
•MSR
•MSR+SCR
•Dallas/Finger Printer
•9.7inch Dual Display
•15inch Dual Display
•10.1inch Dual Display
1. Cautions for safety before installation and use
• Use the following safety guidelines to help ensure your own personal safety and to help protect
your equipment and working environment from potential damage
System should use compatible peripherals.
Devices other than peripherals provided by us may
experience compatibility issues.
Please install the product in a dry and clean place. Dust
and moisture can adversely affect the performance and
stability of the system.
Please back up important data frequently. We do not
warrant data on storage devices.
Turn on the peripherals first when turning on system, turn
off the system first other than peripherals when turning off
system.
Do not block the ventilation hole of the product, and install
in a well ventilated area. The system may overheat causing
performance degradation and stability problems.
Install the product in a flat, non-slip location that is easily
operated by the user.
Use rated voltages to prevent fire hazard and product
damage.
1
1. Cautions for safety before installation and use
• Use the following safety guidelines to help ensure your own personal safety and to help protect
your equipment and working environment from potential damage
Connect the AC code to the grounded outlet. Do not
use the damaged power cable as there may be fire and
electric shock hazard of electric shock. Never touch AC
power with wet hands. May be electrocuted.
When disassembling or upgrading a product, make sure to
turn off the power and remove the power cables and
peripherals to avoid the risk of electric shock and damage
to the product.
Use a computer-only cleaner. Do not use benzene, excited
or alcohol. The product may be deformed.
Do not touch the modem, telephone lines, and exposed
terminals when thunder and lightning strike. Risk of electric
shock and fire.
Keep the product away from the heat appliance (heater,
etc.). There is a risk of product deformation or fire.
Keep plastic wrap out of reach of children.
The manufacturer does not warrant product failure due to
user arbitrary disassembly, repair or modification. Please
use the designated service center for warranty and repair.
2
System Introduction Part 1
• The exterior design and specifications of product can be changed without prior notice in order to
improve quality.
2. System Introduction
3
Keybord
Mouse, Pad Manual Adapter, Cable
System Introduction Part 1
3. General Specifications
4
Processor
Intel Celeron J1900 2.0GHz(2M Cache, up to 2.42GHz)
Intel Core-i3 7100U 2.40GHz(3M Cache)
Intel Core-i5 7200U 2.5GHz(3M Cache, up to 3.10GHz)
Chipset SOC
Graphic Integrated Intel HD Graphics
Data Storage SATA-III 2.5” SSD/HDD, m.2 2280 SSD
RAID Supported (Option)
Memory J1900 : DDR3 1600MHz 1 Slot (up to 8GB)
i3 / i5 : DDR4 2133MHz 2 Slot (up to 32GB)
BIOS AMI UEFI BIOS
Display
38.1cm (15” )
Resolution : 1024 x 768(4:3)
Color : 16.2M Colors supported
Contrast Ratio : 500:1
Backlight : 350cd/㎡, 50,000 hours
39.62cm (15.6”)
Resolution : 1366 x 768(16:9)
Color : 262K Colors supported
Contrast Ratio : 400:1
Backlight : 220cd/㎡, 15,000 hours
Touch Panel
Type : True flat PCT(Projective Capacitive Touch)
Interface : USB
Transparency : 85%
Surface Hardness : 7H
Hitting Life : 100,000,000 times
OS POSReady7 / Window 10
I/O Interface
COM(Serial) : D-SUB 9P x 3 Ports / RJ-45 x 1Port
5V / 12V or RI outputs through BIOS setup
USB Port
- J1900: Front x 2Ports(V2.0) / IO x 4Ports(V2.0)
- Core i3/i5: Front x 2Ports(V2.0) / IO x 4Ports(V3.0)
Ethernet Port : 10M/100M/1Gb RJ-45 x 1Port
DP(Display Port) : DP x 1port
HDMI : (i3 / i5 model only) HDMI x 1port
Audio Port : Line-out x 1port
DC-Output Port : 12V DC-OUT 2.5Φ x 1Port
Booting Device HDD, SSD ,M.2, External CD / DVD-ROM, USB Memory etc.
Power Supply AC INPUT : AC 100~240V /50~60Hz, 2A , DC OUTPUT : 12V / 5A (60W)
Dimensions / Weight
38.1cm (15”) 355 x 215 x 432 (W x D x H, mm) / 5.5kg
39.62cm (15.6”) 394 x 215 x 415 (W x D x H, mm) / 4.8kg
System Introduction Part 1
4. Optional Specifications
5
External I/O Interface
Option 1 ) SERIAL 1+1 D-SUB 9P x 1Port / RJ-45 x 1Port
Option 2) USB 2x2 USB 2.0 x 4Ports
Option 3 ) Parallel Parallel x 1Port
Magnetic Swipe Reader(MSR)
Read Track : ISO track 1, 2, 3
Interface : Internal USB Performance : 10~150 cm/sec
Head Reliability : 500,000 times
Error rate : Less than 0.5%
Customer Display
1) 2 Line LCD: 20 x 2(8 x 16 dot) Characters LCD
2) 24.64cm(9.7”) 1024 x 768, 4:3 LCD Monitor
3) 38.10cm(15”) 1024 x 768, 4:3 LCD Monitor
4) 25.65cm(10.1”) 1024 x 600, 16:9 LCD Monitor
5) 39.62cm(15.6”) 1366 x 768, 16:9 LCD Monitor
System Introduction Part 1
5. Name and Function of each component Front View
4
3
2
1
5
6
6
1. USB 2.0 Port
USB Devices can be used through this port, i.e. USB Scanner, USB Keyboard, USB Printer, etc.
2. Power button System power on and off through this button.
3. Indicating LED Lamp
The lights shows the system status and storage operation, i.e. system power on is green light,
HDD operation is red light.
4. Display Main Display, PCAP touch.
5. Magnetic Card Reader Can read 3 track magnetic card.
6. Stand & Plate
System Introduction Part 1
4
3
2
1
7
1. Screw Hole Fix a card reader.
2. Push Button for detachable Main Display
3. Upper Cover of Stand
Remove this cover, you can replace storage or install customer display.
4. System Cover Remove this cover, you can connect peripheral devices.
6. Name and Function of each component Rear View
System Introduction Part 1
3
2
1
5
4
8
1. System Main Board
2. 2.5” SATAIII Storage (SSD/HDD)
3. Bridge board Connecting Main board and I/O module
4. I/O Module Connection peripheral devices
5. LVDS or eDP Cable Display cable for Main display
7. Name and Function of each component
This manual suits for next models
1
