Ryobi LFP-1802S Operation manual
LFP-1802S
CORDLESS FLASHLIGHT
OWNER’S OPERATING MANUAL
LFP-1802S_SAA-D2_961067036-05.indd A1LFP-1802S_SAA-D2_961067036-05.indd A1 9/2/2010 12:43:48 PM9/2/2010 12:43:48 PM
Fig.1
Fig.2
Fig.3
1
2
34
5
1. Battery Pack(Not Included)
2. Depress Both Latches To Release
3. 180ORotating Head
4. Switch Trigger
5. Bulb Storage Area
DESCRIPTION
LFP-1802S_SAA-D2_961067036-05.indd A2LFP-1802S_SAA-D2_961067036-05.indd A2 9/2/2010 12:44:11 PM9/2/2010 12:44:11 PM
Important!
It is essential that you read the instructions in this manual before
operating this machine.
Subject to technical modifications.
LFP-1802S_SAA-D2_961067036-05.indd A3LFP-1802S_SAA-D2_961067036-05.indd A3 9/2/2010 12:44:38 PM9/2/2010 12:44:38 PM
1
English
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
When using battery operated tools, basic safety
precautions should always be followed to reduce
the risk of fire, leaking batteries and personal
injury, including the following: Read all these
instructions before operating this product and
save these instructions.
Know your flashlight. Read user’s manual carefully.
Learn its applications and limitations as well as the
specific potential hazards related to this flashlight.
Use only with recommended battery pack
and charger. Any attempt to use another battery
pack will cause damage to your light and could
possibly explode, cause a fire, or personal injury.
Remove battery pack from flashlight before
replacing bulb or performing any routine
maintenance or cleaning.
Do not disassemble your flashlight.
Do not place flashlight or battery pack near fire
or heat. This will reduce the risk of explosion and
possibly injury.
Do not dispose of a worn out battery pack by
incinerating. Do not incinerate the battery,
even if it is severely damaged or completely worn out.
The battery may explode in fire.
Do not store your flashlight in a damp or
wet location. Also, do not store in location
where the temperature may reach or exceed
40°C (104°F). For example, inside sheds, vehicles,
or metal buildings in the summer.
Do not permit children to use flashlight
unsupervised. It is not a toy. The temperature of the
bulb can become hot after being on for an extended
period of time. This hot temperature may cause burn
injury if touched.
Keep work area clean. Cluttered areas and benches
invite accidents.
Avoid dangerous environments.
Keep light dry, clean, and free from oil and
grease. Always use a clean cloth when cleaning.
Never use brake fluids, gasoline, petroleum-based
products or any strong solvent to clean your light.
Stay alert. Watch what you are doing and use
common sense. Do not rush.
Check damaged parts. Before further use of this
light, a part that is damaged should be carefully
checked to determine that it will operate properly and
perform its intended function. Do not use flashlight if it
does not function properly.
Have your light repaired by a qualified person.
This tool is in accordance with the relevant safety
requirements. Repairs should only be carried out by
qualified person using original spare parts, otherwise
this may result in considerable danger to the user.
WARNING
Do not operate flashlight or charger near
flammable liquids or in gaseous or explosive
atmosphere. Internal sparks may ignite fumes.
WARNING
Lens and bulb become hot during use.
During or immediately after use, don’t lay
flashlight flat on lens surface.
Handle flashlight with care around any
flammable surface.
If bulb has been lit, let flashlight cool for several
minutes before changing bulb.
Do not use or permit use of flashlight in bed or
sleeping bags. A burn injury could result.
Battery tools do not have to be plugged into an
electrical outlet; therefore, they are always in
operating condition. Be aware of possible hazards
when not using your battery tool or when changing
accessories. Following this rule will reduce the risk of
electric shock, fire, or serious personal injury.
If under abusive conditions, liquid is ejected
from the battery, avoid contact. If this accidentally
occurs, flush with water. If liquid contacts eyes
additionally, seek medical help. This will reduce the
risk of explosion and possibly injury.
WARNING
Batteries vent hydrogen gas and can explode in
the presence of a source of ignition, such as a
pilot light. To reduce the risk of serious personal
injury, never use any cordless product in the
presence of open flame. An exploded battery can
propel debris and chemicals. If exposed, flush
with water immediately.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervi-
sion or instruction concerning use of the appliance
by a person responsible for their safety. Children
should be supervised to ensure that they do not
play with the appliance.
LFP-1802S_SAA-D2_961067036-05.indd 1LFP-1802S_SAA-D2_961067036-05.indd 1 9/2/2010 12:44:38 PM9/2/2010 12:44:38 PM
2
English
This applianceisnotintended foruse byyoung children
or infirm persons unless they have been adequately
supervisedbya responsibleperson toensurethat they
do not play with the appliance.
Keep children and visitors away. Visitors should
wear safety glasses and be kept a safe distance from
the work area. Do not let visitors contact the tool or
extension cord.
Complies with AS/NZS 60335.
SPECIFICATIONS
Model LFP1802S
Rating of Blub 18V 0.6A
Weight 0.32 kg
Light Time (Min)
120 minutes --- 1.4Ah Li-ion
132 minutes --- 1.5Ah Ni-cd
150 minutes --- 1.7Ah Ni-cd
200 minutes --- 2.4Ah Li-ion
Battery Pack
(not included) BPL-1820
BPL-1815 ABP1801
ABP-1815
Compatible
Charger
(not included)
BCL-1800
BCS618
BCL1418
BCL-1800
BCS618
BCL1418
ACR1800
260022029
ACC1800
OPERATION
TO INSTALL BATTERY PACK (NOT INCLUDED)
Place battery pack in your flashlight.Align raised rib on
battery pack with groove inside. See Figure 1.
Make sure the latches on battery pack snap in place
and battery pack is secured in flashlight before
beginning operation.
TO REMOVE BATTERY PACK (NOT INCLUDED)
Switch off your flashlight.
Locate latches of battery pack and depress to release
battery pack from your flashlight.
Remove battery pack from your flashlight.
BATTERY PROTECTION FEATURES
RYOBI 18 V lithium-ion batteries are designed with
features that protect the lithium-ion cells and maximise
battery life. Under some operating conditions, these
built-in features may cause the battery and the tool it is
powering to act differently from nickel-cadmium batteries.
During some applications, the battery electronics may
signal the battery to shut down, and cause the tool to
stop running. To reset the battery and tool, release the
trigger and resume normal operation.
NOTE: To prevent further shut down of the battery, avoid
forcing the tool.
If releasing the trigger does not reset the battery and
tool, the battery pack is depleted. If depleted, the battery
pack will begin charging when placed on the lithium-ion
charger.
ROTATING HEAD
OPERATION
See Figure 2.
Your flashlight has the feature of rotating the head 180° in
either direction.
BULB REPLACEMENT
TO REPLACE BULB
Remove battery pack from worklight. See section “To
install/remove battery pack”.
Depress button located on top of lens covers then pull
lens cover to remove.
Remove old bulb from spring by twisting bulb.
Insert new bulb in spring by twisting bulb.
Replace lens cover aligning tabs inside lens cover with
slots on housing and let the bulb aligning to the hole
canter of the reflector, then snap into place.
Replace battery pack.
Note: For your convenience, your flashlight has a
spare bulb storage area. It is located behind the lens
cover. See Figure 3.
When purchasing replacement bulb, request to RYOBI
after-sales service for recommended part number
780287001.Always use bulb with same characteristics
and size.
WARNING
Do not attempt to disassemble the battery pack.
Fire or injury may result.
LFP-1802S_SAA-D2_961067036-05.indd 2LFP-1802S_SAA-D2_961067036-05.indd 2 9/2/2010 12:44:38 PM9/2/2010 12:44:38 PM
3
English
MAINTENANCE
WARNING
When servicing, use only identical replacement
parts. Use of any other part may create a hazard
or cause product damage.
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use clean cloths to remove dirt, dust, oil grease, etc.
WARNING
Do not at any time let brake fluids, gasoline,
petroleum-based products, penetrating oils, etc.
come in contact with plastic parts.They contain
chemicals that can damage, weaken or destroy
plastic.
Do not abuse power tools. Abusive practices can damage
tool as well as workpiece.
WARNING
Do not attempt to modify this tool or create
accessories not recommended for use with
this tool. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.
LFP-1802S_SAA-D2_961067036-05.indd 3LFP-1802S_SAA-D2_961067036-05.indd 3 9/2/2010 12:44:39 PM9/2/2010 12:44:39 PM
TECHTRONIC INDUSTRIES (AUSTRALIA) PTY. LTD.
Level 1. 666 Doncaster Road,
Doncaster, Victoria 3108
Australia.
Tel: 61 3 9840 3226 Fax No.: 613 9840 6133 www.ryobi.com.au
LFP-1802S_SAA-D2_961067036-05.indd 4LFP-1802S_SAA-D2_961067036-05.indd 4 9/2/2010 12:44:39 PM9/2/2010 12:44:39 PM
