Russell Hobbs 19006 User manual

instructions

£10,000 prize draw

EXTRA year guarantee

FREE rewards gallery

www.productregister.co.uk/rhobbs

See back for

details

Read the instructions, keep them safe, pass them on if you pass the

appliance on. Remove all packaging before use.

AIMPORTANT SAFEGUARDS

Follow basic safety precautions, including:

1 This appliance can be used by persons with

reduced physical, sensory or mental capabilities

or lack of experience and knowledge if they

have been supervised/instructed and

understand the hazards involved.

•Keep the appliance and cable out of reach of

children; they must not use or play with it.

sTo avoid injury, take care handling the blades,

emptying the jug, and cleaning.

uDon’t add hot liquid (over 40°C), as it may be

ejected due to sudden steaming.

cMisuse of the appliance may cause injury.

2 Don’t leave it unattended while plugged in.

3 Unplug before assembling, dismantling or

cleaning.

4 If the cable is damaged, return the appliance,

to avoid hazard.

LDon’t put the motor unit in liquid.

5 Don’t use the blender unless the lid and cap are ﬁtted.

6 Don’t put utensils into the jug while the appliance is plugged in.

7 Switch oﬀ (0) before ﬁtting the jug to the motor unit.

8 Switch oﬀ (0), and wait till the blades stop before removing the

lid from the jug, or removing the jug from the motor unit.

9 Don’t use accessories or attachments other than those we supply.

10 Don’t use the appliance for any purpose other than those

described in these instructions.

11 Don’t operate the appliance if it’s damaged or malfunctions.

12 You may use the processor and disc for cutting/grating for up to

2 minutes. Any other use should be restricted to 1½ minutes.

After this, let the motor rest for 2 minutes.

household use only

CIN BRIEF

1 Sit the motor unit on a dry, ﬁrm, level surface.

2 Route the cable so it doesn’t overhang, and won’t trip or catch.

3 Lower the jug on to the motor unit, then turn the jug clockwise,

to lock it in place.

4 Remove the lid.

5 Put the ingredients into the jug – don’t ﬁll past the max mark.

6 Put the lid on the jug.

CPOWER UP

7 Check that the speed control is set to 0.

8 Put the plug into the power socket (switch it on, if it’s switchable).

CSPEED CONTROL

9 Turn the speed control clockwise (1 = low, 2 = high).

10 Turn it back to 0 to turn the motor oﬀ.

11 Use low speed (1) for lighter applications, using mainly liquid

ingredients, and high speed (2) for heavier applications, using

mainly solid ingredients.

12 Turning it anti-clockwise to Ywill give you a short burst at high

speed, for more precise control. In this direction, the control is

spring-loaded. When you let go, it’ll return to 0.

NUSING THE BLENDER

13 Lower the jug on to the motor unit, then turn the jug clockwise,

to lock it in place.

14 Pull the lid up and oﬀ the jug – it’s stiﬀ, because of the seal.

15 Put the ingredients into the jug – don’t ﬁll past the max mark.

16 Put the lid on the jug, and push it down to seal it.

17 Align the pips on the cap with the slots in the hole, ﬁt the cap in

the hole, and turn clockwise.

,Don’t run the blender without the cap.

18 To add ingredients while the motor is running:

a) turn the cap clockwise to unlock it, and lift it oﬀ

b) add the ingredients via the hole

c) replace the cap, and turn it anti-clockwise to lock it

19 Turn the jug anti-clockwise to unlock, and lift it oﬀ the motor unit.

NCRUSHING ICE

20 Start with half to threequarters of a cup of ice, or 4 to 6 cubes,

and add 15ml (1 tbsp) of water.

21 Put the lid on the blender, then turn the speed control to Yfor a

second or so, check the state of the ice, and repeat till the ice is

the consistency that you need

NCARE AND MAINTENANCE

22 Switch oﬀ (0) and unplug before cleaning.

23 Wipe the outside of the motor unit with a clean damp cloth.

24 Handwash the removable parts.

` You may wash these parts in a dishwasher.

25 If you use a dishwasher, the harsh environment inside the

dishwasher will aﬀect the surface ﬁnishes.

26 The damage should be cosmetic only, and should not aﬀect the

operation of the appliance.

NBLADE UNIT

27 You may remove the blade unit for cleaning.

28 This is best done with the jug upside down.

29 Grip the jug handle with one hand.

30 Grip the bottom of the blade unit with the other hand.

31 Turn the blade unit clockwise till it comes loose from the jug base.

32 Carefully, pull it up and out of the bottom of the jug.

33 Wash the seal and blade unit in warm soapy water, rinse, and air

dry.

34 Take great care with the blades – don’t handle them directly, use

a nylon washing-up brush.

35 Replace the seal round the blade unit.

36 Turn the blade unit upside down, and replace it in the bottom of

the jug base.

37 Turn the blade unit anti-clockwise to tighten it.

PRECIPES

coriander pesto (dip, topping or sauce)

4 handfuls fresh leaf coriander

4 cloves fresh garlic

120g pine nuts

250ml olive oil

120g freshly grated Parmesan

salt and pepper

Put the coriander, garlic, pine nuts, and a bit more than half the oil

into the jug. Fit the lid, and process at moderate speed till it looks

smooth. To adjust the thickness, add a little oil, give it a short burst,

and repeat till it’s right. Transfer to a bowl, stir in the Parmesan, taste,

and adjust the seasoning. Serve as a dip (fairly thick), as a topping

for soup (not too thick, but not runny), or tossed through warm

pasta (fairly runny).

recipes are available on our website:

blender – http://www.russellhobbs.com/ifu/550931

smoothies – http://www.russellhobbs.com/ifu/550941

OUSING THE PROCESSOR

38 Unplug the appliance.

39 Fit the spindle to the top of the motor unit.

40 Lower the jug on to the motor unit, then turn the jug clockwise,

to lock it in place.

41 Choose the attachment you need.

OWITH THE SUPPORT

42 Use the chopper for pulverizing ingredients.

43 Use the mixer to mix ingredients together.

44 Use the creamer to thicken cream, to beat eggs, and to cream

eggs and sugar together.

45 Fit the attachment over the support, and slide it to the bottom.

46 Lower the support into the centre of the jug, over the spindle.

47 Put the ingredients into the jug – don’t ﬁll it past the max mark.

48 Hold the lid with the tube slightly behind the jug handle, set it on

the jug, then turn it clockwise, to lock the tab into the top of the

handle.

49 To add ingredients while the motor is running:

a) lift the pushed out of the tube

b) add the ingredients via the tube

c) replace the pusher

50 To remove the lid, turn it anti-clockwise to unlock, then lift it oﬀ.

OWITH THE DISC

51 Fit the slicer or one of the graters into the disc.

52 Lower the disc over the top of the spindle.

53 Hold the lid with the tube slightly behind the jug handle, set it on

the jug, then turn it clockwise, to lock the tab into the top of the

handle.

54 Remove the pusher, and drop the ingredients down the tube.

55 Replace the pusher, and use it to push the ingredients gently

down the tube.

,Don’t use ﬁngers or cutlery to push food down the tube – only

the pusher.

56 The blade(s) on top of the disc will slice or grate the food into the

bowl.

57 Don’t let the bowl get more than about half full – stop and empty

it.

58 To remove the lid, turn it anti-clockwise to unlock, then lift it oﬀ.

59 Turn the disc over, and press one of the metal ends in and down,

to remove the slicer/grater.

OCARE AND MAINTENANCE

60 Switch oﬀ (0) and unplug before cleaning.

61 Wipe the outside of the motor unit with a clean damp cloth.

62 Handwash the removable parts.

` You may wash these parts in a dishwasher.

63 If you use a dishwasher, the harsh environment inside the

dishwasher will aﬀect the surface ﬁnishes.

64 The damage should be cosmetic only, and should not aﬀect the

operation of the appliance.

QRECIPES

quick cheese & tomato pizzas (2 medium pizzas)

2 sachets active dried yeast

2 tsp sugar

240ml lukewarm water

440g strong white ﬂour

2 tbsp olive oil

1 tsp salt

1x300g jar pizza sauce

200g mozzarella cheese

Mix the water, yeast, and sugar in a bowl, and leave it for 5 minutes.

Fit the mixer. Process the ﬂour and salt at low speed. Add the water,

yeast, and sugar mixture via the tube. Add the oil, and process at

high speed till a dough ball forms, then reduce speed. Run for 20

seconds, and rest for 2 minutes. Do this twice more, then let the

dough rest for 10 minutes.

Divide the dough into 2 balls, and stretch or roll each ball to ﬁt a

lightly oiled baking tray. Top with the pizza sauce. Use the coarse

grater to grate the mozzarella cheese. Spread the cheese over the

pizzas and add other toppings if desired. Bake in a pre-heated oven

at 190°C/gas mark 5 for 15-20 minutes.

recipes are available on our website:

http://www.russellhobbs.com/ifu/551078
